INSTALLATION GUIDE
for the
SB-GM-CAM6G/12W6v3
SKU# 94632
2016 & Up Chevrolet Camaro Coupe
Thank you for choosing a JL Audio Stealthbox® for your automotive sound system.
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox® installed by your
authorized JL Audio dealer. The installation professionals employed by your
dealer have the necessary tools and experience to disassemble and reassemble
your vehicle properly. If you prefer to perform your own installation, please read
this installation guide completely before beginning the process.
If you choose to perform the installation yourself, it is absolutely
vital that the Stealthbox
®
be properly mounted to the vehicle
according to these instructions. Failure to mount the enclosure
properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the
enclosure caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a
collision or sudden deceleration.
INSTALLATION
DIFFI CULT Y:
ESTIMATED TIME:
1 HOUR
Enclosure Type: Sealed
Driver Type: 12W6v3-D4
Nominal Impedance: 2 ohms
Continuous Power Handling: 600 watts (RMS method)
Continued on Next Page
2
5
OUT
OF
SB-GM-CAM6G/12W6v3 INSTR_SKU# 011464
INCLUDED HARDWARE
Continued on Next Page
Page 2 • JL Audio, Inc., 2016
SB-GM-CAM6G/12W6v3 INSTR_SKU# 011464
BOM ID Qty SKU Description
1 2 151079 3/8 - 16 x 1” Hex Head Bolt
2 2 151081
3/8” Lock Washer
3 1 151140 3/8 - 16 U-Nut
4 5 151126 3/8” Fender Washer
5 1 153777 Rear Bracket
6 3 151123 3/8 - 16 Hex Nut
7 1 153640 3/8 - 16 x 2-1/2” Set Screw
8 2 153775 5/16 - 18 x 1” Carriage Bolt
9 2 153776 3/4” OD x 5/16” ID x 1/4” Aluminum Spacer
10 2 151021 1/4” Flat Washer
11 2 150929 5/16” Lock Washer
12 2 153601 5/16 - 18 Hex Nut
13 1 153778 Top Bracket
14 2 151137 1/4 - 20 x 1” Hex Head Bolt
15 2 151098 1/4” Lock Washer
16 2 153598 5/16” Standard Washer
- 1 151984 Trimming Template (not shown)
