KitchenAid KESK901SSS Bruksanvisning

KitchenAid ovn KESK901SSS

Les nedenfor 📖 manual på norsk for KitchenAid KESK901SSS (28 sider) i kategorien ovn. Denne guiden var nyttig for 9 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/28

INSTALLATION INSTRUCTIONS

30" (76.2 CM) FREESTANDING AND SLIDE-IN

ELECTRIC RANGES

INSTRUCTIONS D'INSTALLATION DE

CUISINIÈRES ÉLECTRIQUES AUTOPORTANTES

ET COULISSANTES DE 30" (76,2 CM)

Table of Contents/Table des matières.............................................................................2

W10440541A

IMPORTANT:

Save for local electrical inspector's use.

IMPORTANT :

À conserver pour consultation par l'inspecteur local des installations électriques.

TABLE OF CONTENTS

RANGE SAFETY .............................................................................3

INSTALLATION REQUIREMENTS................................................4

Tools and Parts ............................................................................4

Location Requirements................................................................4

Electrical Requirements - U.S.A. Only.........................................6

Electrical Requirements - Canada Only.......................................7

Countertop Preparation ...............................................................8

INSTALLATION INSTRUCTIONS..................................................8

Unpack Range..............................................................................8

Measure for Proper Height...........................................................8

Adjust Leveling Legs....................................................................9

Install Anti-Tip Bracket.................................................................9

Electrical Connection - U.S.A. Only...........................................10

Verify Anti-Tip Bracket Is Installed and Engaged ......................15

Level Range................................................................................16

Complete Installation .................................................................16

Moving the Range......................................................................16

TABLE DES MATIÈRES

SÉCURITÉ DE LA CUISINIÈRE ...................................................18

EXIGENCES D'INSTALLATION...................................................19

Outillage et pièces......................................................................19

Exigences d'emplacement.........................................................19

Spécifications électriques ..........................................................22

Préparation du plan de travail ...................................................22

INSTRUCTIONS D'INSTALLATION.............................................23

Déballage de la cuisinière ..........................................................23

Mesures pour une hauteur appropriée ......................................23

Ajuster les pieds de nivellement.................................................24

Installation de la bride antibasculement ....................................24

Vérifier que la bride anti-basculement

est bien installée et engagée......................................................25

Réglage de l'aplomb de la cuisinière.........................................25

Achever l’installation ..................................................................26

Déplacement de la cuisinière.....................................................26

RANGE SAFETY

You can be killed or seriously injured if you don't immediately

You

can be killed or seriously injured if you don't

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can

happen if the instructions are not followed.

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety

messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you and others.

All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”

These words mean:

follow instructions.

instructions.

DANGER

WARNING

Tip Over Hazard

A child or adult can tip the range and be killed.

Install anti-tip bracket to floor or wall per installation instructions.

Slide range back so rear range foot is engaged in the slot of the anti-tip bracket.

Re-engage anti-tip bracket if range is moved.

Do not operate range without anti-tip bracket installed and engaged.

Failure to follow these instructions can result in death or serious burns to children and adults.

Anti-Tip

Bracket

To verify the anti-tip bracket is installed and engaged:

• Slide range forward.

• Look for the anti-tip bracket securely attached to floor or wall.

• Slide range back so rear range foot is under anti-tip bracket.

• See installation instructions for details.

Range Foot

WARNING

Produkspesifikasjoner

Merke:	KitchenAid
Kategori:	ovn
Modell:	KESK901SSS
Produkttype:	Frittstående komfyr
Innebygd skjerm:	Ja
Bredde:	762 mm
Dybde:	685.8 mm
Høyde:	914.4 mm
Konveksjon matlaging:	Ja
Antall brennere/kokesoner:	4
Ovn strømkilde:	Elektrisk
Antall ovner:	1
Kontrollposisjon:	Front
Selvrensende:	Ja
Produktfarge:	Rustfritt stål
Kontrolltype:	Buttons, Rotary
Antall elektriske kokesoner:	4
Kroppsmateriale:	Metall
Ovn størrelse:	Medium
Benke type:	Keramisk
Brenner / kokeområde 1 type:	Liten (fingerbøl)
Brenner / kokeområde 1 strøm:	1200 W
Brenner / kokeområde 2 type:	Medium
Brenner / kokeområde 2 strøm:	1500 W
Brenner / kokeområde 3 type:	Stor
Brenner / kokeområde 3 strøm:	1800 W
Type med topp overflate:	Glass
Samlet innvendig ovn kapasitet:	- l
Samlet ovn strøm:	3250 W
Brenner / kokeområde 4 type:	Ekstra stor
Brenner / kokeområde 4 strøm:	2200 W
Ovn samlet kapasitet:	- l
Brenner / kokesone 4 diameter:	203.2 mm
Brenner / kokesone 3 diameter:	177.8 mm
Brenner / kokesone 1 diameter:	127 mm
Brenner / kokesone 2 diameter:	152.4 mm
