Side 1/20
P/N: 2900-301861 Rev 1 www.kramerav.com
USER MANUAL
MODEL - CL-4P
High-Performance 4” in-ceiling, two-way
Passive Speaker
Kramer Electronics Ltd.
CL-4P – Contents
i
Contents
Introduction 1
Safety First! 1
Recycling Kramer Products 1
Included in the box 1
Overview 2
Models 3
Typical Applications 3
Installation Guide 4
Achieving Best Performance 4
Choosing the Best Location 4
Unpacking 4
Mounting the Speaker 5
Wiring the Speakers – best practice 6
Defining and calculating speaker’s sound pressure levels (SPL) 13
Technical Specifications 15
Kramer Electronics Ltd.
CL-4P – Introduction
1
Introduction
Thank you for purchasing the Kramer CL-4P Speaker. This high-performance, 4” in-ceiling,
two-way passive speaker delivers premium sound performance for commercial audio
installations. Designed for both 8Ω and 70V/100V systems, it is ideal for speech applications
such as meeting rooms as well as for paging and low ceiling applications.
Please read this manual carefully before installation to ensure optimal performance and
safety.
Safety First!
• Installations must be performed by a qualified professional following local regulations.
• Ensure that the ceiling surface on which the speaker is installed can support the weight of the
speaker.
• For installation in suspended acoustic ceiling grid, use the C-Ring that is supplied with the
speaker together with the mounting rails (CSMR) which should be ordered separately.
• This speaker is intended for indoor installations, do not expose the speaker to excessive
moisture or extreme temperatures.
• Always power off the amplifier before changing transformer tap settings or connecting the
cable to the speaker.
• Always check amplifier compatibility before connecting (impedance setup, power ratings).
• Do not open the speaker housing, as this may affect the sound quality and will void the
warranty.
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular
country go to our recycling pages at www.kramerav.com/il/quality/environment.
Included in the box
• 1 CL-4P speaker (single unit)
• 2 magnetic grills (1 white and 1 black)
• 4-pin pluggable Euroblock connector, 28-12AWG
• Cutout template
• Accessories (C-ring, bracket bolts, UL cable passthrough, Silicon cable passthrough,
zip tie for securing the speaker cable)
