Model No. & MS-1818 MS-2424
Floor Mounted
Mop Sink
Installation Instructions
Instructions
1. Install Mounting Bracket to wall with mounting holes
on the bottom with the bottom edge of the bracket at
oor level as shown in the drawing to the right.
2. Install Drain Assembly to Mop Sink without installing
the Rubber Gland, Compression Nut, or Strainer
Plate yet
3. Fit Mop Sink over 2” IPS pipe stub while tting rear
strap onto Mounting Bracket. 2” IPS pipe stub must
protrude 3” from oor and x” from the wall
4. Insert Rubber Gland over 2” IPS pipe stub (may use
liquid soap for easier installation)
5. Thread Compression Nut over Rubber Gland into drain
body. Use Drain Key and at screw driver to tighten
Compression Nut to tightly seal Rubber Gland and IPS
pipe stub.
6. Remove Drain Key and install Strainer Plate to the top
of the drain
Strainer Plate
Fiber Washer
Drain Locknut
Compression Nut
Drain Key
Drain Body
Rubber Gland
Rubber Washer
Model x = Inch’s from the Wall
MS-1818 9”
MS-2424 12”
Krowne 100 Haul Rd. Wayne, NJ 07470 krowne.com
Due to our commitment to continued product improvement, specications are subject to change without notice.
IncludesDetail
Floor Mounted Mop Sink
Mounting Bracket
Drain Assembly
20 gauge 304 stainless steel construction
Easy Installation
Rev. 04/2021
