IdeaPad 5 2-in-1 14IAL10 83KR001HUS

PERFORMANCE

Processor

Intel® Core™ Ultra 5 225U, 12C (2P + 8E + 2LPE) / 14T, Max

Turbo up to 4.8GHz, 12MB

AI PC Category

[1]

Non-AI PC

NPU

Integrated Intel® AI Boost, up to 12 TOPS

Graphics

Integrated Intel® Graphics

Chipset

Intel® SoC Platform

Memory

8GB Soldered LPDDR5x-8000

Memory Slots

Memory soldered to systemboard, no slots, single-channel

(8GB models)

Max Memory

8GB soldered memory, not upgradable

Storage

256GB SSD M.2 2242 PCIe® 4.0x4 NVMe®

Storage Support

[2]

One drive, up to 1TB M.2 2242 SSD

Storage Slot

One M.2 2242 PCIe® 4.0 p1-x4 slot

Card Reader

microSD Card Reader

Audio Chip

High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers

Stereo speakers, 2W x2, optimized with Dolby Audio™

Camera

FHD 1080p + IR with Privacy Shutter

Microphone

2x, Array

Battery

57Wh

Power Adapter

65W USB-C® (3-pin)

DESIGN

Display

[3]

14" WUXGA (1920x1200) IPS 300nits Glossy, 45% NTSC,

60Hz, TÜV Low Blue Light, Glass, Touch

Touchscreen

10-point Multi-touch

Color Calibration

None

Keyboard

Backlit, English

Touchpad

Buttonless Mylar® surface multi-touch touchpad, supports

Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)

Case Color

Cosmic Blue

Surface Treatment

Aluminium Stamping (Anodized with Sandblasting)

Case Material

Aluminium (Top), PC-ABS + 40% GF (Bottom)

Pen

Pen Upgradable (Purchase Separately)

Dimensions (WxDxH)

[4]

313 x 227 x 17.5 mm (12.32 x 8.94 x 0.69 inches)

Weight

[5]

Starting at 1.6 kg (3.53 lbs)

SOFTWARE

Operating System

Windows® 11 Home, English

Bundled Software

Office Trial

CONNECTIVITY

WLAN + Bluetooth®

[6]

Wi-Fi® 6, 802.11ax 2x2 + BT5.2

WWAN

Non-WWAN

Ethernet

No Onboard Ethernet

Standard Ports

1x USB-A (USB 5Gbps / USB 3.2 Gen 1)•

1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On•

2x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD

3.0 and DisplayPort™ 1.4

•

1x HDMI® 1.4b•

1x Headphone / microphone combo jack (3.5mm)•

1x microSD card reader•

Docking

Various docking solutions are supported via USB-C®.

For more compatible docking solutions, please visit Docking

for IdeaPad® 5 2-in-1 14IAL10

SECURITY & PRIVACY

Security Chip

Firmware TPM 2.0

Fingerprint Reader

None

Other Security

Camera privacy shutter•

IR camera for Windows® Hello (facial recognition)•

SERVICE

Base Warranty

1-year, Courier or Carry-in

Included Upgrade

None

ACCESSORIES

Bundled Accessories

None

CERTIFICATIONS

Green Certifications

[7]

ENERGY STAR® 8.0•

EPEAT™ Gold Registered•

ErP Lot 6/26•

RoHS compliant•

Other Certifications

Models with IPS panel:

TÜV Rheinland® Low Blue Light (Software Solution)

Mil-Spec Test

MIL-STD-810H military test passed (21 test items)

MODEL

TopSeller Announce Date: No : 2025-03-04

EAN / UPC / JAN End of Support: 198156626318 : 2031-04-11

Product image is a sample, it may not match the real color of this model

Note:

[1] AI PCs have a NPU capable of 10+ TOPs to run the Copilot......

· Lenovo reserves the right to change specifications without notice.

· California Electronic Waste Recycling Fee In California, per state law,

Lenovo charges an electronic waste recycling fee on this covered device at

the time of sale of the product. For more information, go to:

https://www.calrecycle.ca.gov/Electronics/Consumer

To see more note information, please link to

https://psref.lenovo.com/Detail/2638?M=83KR001HUS
