Lian Li V3000 Plus Bruksanvisning
Les nedenfor 📖 manual på norsk for Lian Li V3000 Plus (23 sider) i kategorien dataeske. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/23
Remove the Top Cover and Front Panel
卸下上蓋及 前⾯板 / Retirer le capot supérieur et le
panneau avant / Entfernen Sie die obere Abdeckung und
die Frontplatte / Retire la cubierta superior y el panel
frontal / トップカバーとフロントパネルを取り外す
1
Remove the Side Panel
卸下側板 / Retirer le panneau latéral / Entfernen Sie die Seitenwand / Retire el panel lateral/サイドパネルを取り外す
3
2
此 螺 絲 在 平 時 不 ⽤ 鎖 。
No need to screw normally.
2
2
1
- 1 -
另 ⼀側 同 樣 步 驟 。
Do the same steps on the other side.
2
1
4
Be sure to press the middle of the glass.
請 務 必 按 壓 玻 璃 中 間 位 置 。
If the push-pull mechanism is
harsh, please manually push
the spring so that they are at
the same status.
如 發 ⽣ 開 合 不 順 暢 或 機 構 未
彈 起 的 問 題 ， 請 ⼿ 動 按 壓 讓
機 構 回 到 ⼀ 致 的 狀 態 。
Standard Mode Specifications
標準模式規格 / Spécifications du mode standard / Spezifikationen des Standardmodus /
Especificaciones del modo estándar / 通常モードの仕様
要 安 裝 此 模 式 ， 請 參 閱 第 1 - 1 4 , 2 1 -2 3⾴
Refer to page 1-14, 21-23 to install this mode
Power Button, Reset Button, 2 x USB 3.0,
1 x USB 3.1 Type C, 1 x AUDIO / Microphone
Combo Jack, C button for color control,
M button for lighting mode control.
Power Button, Reset Button, 2 x USB 3.0,
1 x USB 3.1 Type C,
1 x AUDIO / Microphone Combo Jack.
Supporting 120 mm fan x 4 or 140 mm fan x 3
or 200 mm fan x 2
or 480 mm radiator x 1 or 420 radiator x 1.
Supporting 120 mm fan x 4 or 140 mm fan x 3
or 480 mm radiator x 1 or 420 radiator x 1.
Supporting 120 mm fan x 3 or 140 mm fan x 3
or 360 mm radiator x 1 or 420 radiator x 1.
Supporting 120 mm fan x 4 or 140 mm fan x 3
or 480 mm radiator x 1 or 420 radiator x 1
(Remove the J ).
Supporting 120 mm fan x 1 or 140 mm fan x 1.
Supporting 2.5” SSD x 4.
Removable HDD cage,
Supporting 2.5” SSD x 8 or 3.5" HDD x 8.
Supporting 2.5” SSD x 4.
要 安 裝 此 模 式 ， 請 參 閱 第 1 - 5 , 1 5 -1 7, 2 1 -2 3⾴
Refer to page 1-5, 15-17, 21-23 to install this mode
Dual System
Dual System Mode Specifications
雙系統模式規格 / Spécifications du mode système double / Spezifikationen des
Dualsystemmodus / Especificaciones del modo de sistema dual /
デュアルシステムモードの仕様
A1
A2
A1
A2
Power Button, Reset Button, 2 x USB 3.0,
1 x USB 3.1 Type C, 1 x AUDIO / Microphone
Combo Jack, C button for color control,
M button for lighting mode control.
Power Button, Reset Button, 2 x USB 3.0,
1 x USB 3.1 Type C,
1 x AUDIO / Microphone Combo Jack.
Supporting 120 mm fan x 4 or 140 mm fan x 3
or 200 mm fan x 2 or 480 mm radiator x 1 or
420 radiator x 1.
Supporting 120 mm fan x 4 or 140 mm fan x 3
or 480 mm radiator x 1 or 420 radiator x 1.
Supporting 120 mm fan x 2 or 140 mm fan x 2
or 240 mm radiator x 1 or 280 radiator x 1.
Supporting 120 mm fan x 4 or 140 mm fan x 3
or 480 mm radiator x 1 or 420 radiator x 1
(Without the J and the GPU of ITX system).
Supporting 120 mm fan x 1 or 140 mm fan x 1,
Supporting 2.5” SSD x 4
Removable HDD tray,
Supporting 2.5” SSD x 8 or 3.5" HDD x 8
Supporting 2.5” SSD x 4
A1
A2
A1
A2
Standard
- 2 -
J
+ J
J
+ J
要 安 裝 此 模 式 ， 請 參 閱 第 1 - 5 , 1 8 -2 3⾴
Refer to page 1-5, 18-23 to install this mode
Rotated
Rotated Mode Specifications
轉置模式規格 / Spécifications du mode pivoté / Spezifikationen des gedrehten Modus/
Especificaciones del modo rotado / 回転モード仕様
Power Button, Reset Button, 2 x USB 3.0,
1 x USB 3.1 Type C, 1 x AUDIO / Microphone
Combo Jack, C button for color control,
M button for lighting mode control.
Power Button, Reset Button, 2 x USB 3.0,
1 x USB 3.1 Type C,
1 x AUDIO / Microphone Combo Jack,
Supporting 120 mm fan x 4 or 140 mm fan x 3
or 200 mm fan x 2 or 480 mm radiator x 1 or
420 radiator x 1.
Supporting 120 mm fan x 4 or 140 mm fan x 3
or 480 mm radiator x 1 or 420 radiator x 1.
Supporting 120 mm fan x 1 or 140 mm fan x 1
Supporting 120 mm fan x 4 or 140 mm fan x 3
or 480 mm radiator x 1 or 420 radiator x 1
(Remove the J ) .
Supporting 120 mm fan x 3 or 140 mm fan x 2,
or 360 mm radiator x 1 or 280 radiator x 1
Supporting 2.5” SSD x 4
Removable HDD tray,
Supporting 2.5” SSD x 8 or 3.5" HDD x 8
Supporting 2.5” SSD x 4
A1
A2
A1
A2
Remove the Dust Filters
灰塵濾網拆卸 / Retirer les filtres à poussière / Entfernen Sie die Staubfilter / Retire los filtros de polvo /
ダストフィルタを取り外す
- 3 -
J
+ J
Produkspesifikasjoner
| Merke: | Lian Li |
| Kategori: | dataeske |
| Modell: | V3000 Plus |
| Bredde: | 279 mm |
| Dybde: | 678.5 mm |
| Høyde: | 674 mm |
| Materiale: | Aluminium, Steel, Tempered glass |
| Støttede HDD-størrelser: | 2.5, 3.5 " |
| Antall utvidelsesspor: | 8 |
| Produktfarge: | Sort |
| Formfaktor: | Full Tower |
| tilbakestillingsknapp: | Ja |
| Modell/Type: | PC |
| Støttet systemdisk formfaktorer: | ATX, EATX, EEB, Micro ATX, Mini-ITX |
| Lydkontakter: | Ja |
| Antall 3.5" bays: | 8 |
| Antall 2.5" bays: | 8 |
| Siderute: | Ja |
| Av/på-knapp: | Ja |
| Maksimal høyde CPU-kjøler: | 198 mm |
| Maksimal lengde PSU: | 220 mm |
| Støttede formfaktorer strømforsyning: | ATX, SFX, SFX-L |
| Maksimale frontvifter: | 4 |
| Frontviftediameter som støttes: | 120,140 mm |
| Antall bakvifter som støttes (maks.): | 3 |
| Bakre viftediametere som støttes: | 120,140 mm |
| Antall toppvifter som støttes (maks.): | 4 |
| Toppviftediametere som støttes: | 120,140,200 mm |
| Støttede radiatorstørrelser foran: | 420,480 mm |
| Støttede radiatorstørrelser bak: | 280,360 mm |
| Støttede radiatorstørrelser øverst: | 420,480 mm |
| Antall USB 3.2 Gen 2 (3.1 Gen 2)Type-C-porter: | 1 |
| Antall bunnvifter som støttes (maks.): | 4 |
| Støttede diametere på bunnvifter: | 120,140 mm |
