Side 1/20
EWT 91 / EWT 92 / EWP.. 94.. / EWP.. 96..
7085 999-01
Installation instructions
Multi-temperature wine cabinet Page 20
EN
20
Please read and follow these instructions.
These instructions contain Danger, Warning and Caution notes.
This information is important for safe and efficient installation
and operation.
Always read and comply with all Danger, Warning and Caution
notes!
DANGER!
Danger indicates an imminent hazard
which will cause serious injury or death if
precautions are not followed.
WARNING!
Warning indicates a hazardous situation
which, if not avoided, could result in death
or serious injury.
CAUTION!
Caution indicates a potentially hazardous
situation which, if not avoided, may result
in minor or moderate injury.
IMPORTANT
This indicates information that is especially relevant to a
problem-free installation and operation.
Content
Please read and follow these instructions. .............................20
Note to the installer.................................................................21
Mounting the anti-tipping device ............................................21
Setting up ...............................................................................21
Electrical connection ..............................................................21
Appliance dimensions ............................................................22
Door swing clearance (top view) ............................................22
Installation dimensions ...........................................................23
Panel dimensions ................................................................... 24
Unpacking ..............................................................................25
Supplied accessories .............................................................27
Anti-tipping device ..................................................................28
Appliance installation .............................................................29
SmartDeviceBox (not supplied in all countries) .....................36
Please note in case of removing appliance from the recess ..37
Important note for changing over door hinges or limiting the door
opening angle to 90° ..............................................................37
21
EN
Setting up
• Do not place the appliance in direct sunlight or
near cookers, radiators and similar sources of
heat.
• The floor on which the appliance stands should
be horizontal and level.
•
Do not cover ventilation openings or
grilles.
• The door front must finish at least 102 mm above
the floor to guarantee adequate ventilation and
air extraction.
• The more refrigerant there is in the appliance, the larger the
room in which the appliance is installed must be. If the room is
too small, any leak may create a flammable mixture of gas and
air. For each 8 g of refrigerant, the installation space must be
at least 1 m
3
. Information on the refrigerant can be found on the
type plate inside the appliance.
Electrical connection
Only operate the appliance with alternating current (AC).
The permissible voltage and frequency are indicated on the
type plate. The position of the type plate is shown in the section
entitled Description of the appliance (Operating instructions).
The socket must be properly earthed and protected by a fuse.
The tripping current of the fuse must be between 10 A and 16 A.
Do not connect the appliance using an extension cable or exten-
sion socket.
Do not use stand-alone inverters (conversion
of direct current to alternating current/three-
phase current) or energy-saving plugs. Risk
of damage to the electronic control system!
Note to the installer
It is very important to follow the instructions in the manual to
ensure proper installation and operation of the appliance.
Before installing the appliance, be sure to thoroughly read and
understand all of the information in this manual.
WARNING!
Risk of electric shock.
Do not connect to the socket before the
installation is completed.
Mounting the anti-tipping device
WARNING!
To avoid a hazard due to instability of the
appliance, it must be secured in accordance
with the instructions.
