Part no.:
| DESCRIPTION
43366
USB Type C and Type A Hybrid Laptop Docking Station - 4K HDMI, 2x4K
(DP or HDMI), PD 3.0 100W, USB 3.2 Gen 2, Gigabit Ethernet, Audio
Connect up to 3 displays and peripherals to Windows and Apple computers
Connects up to three 4K displays (DisplayPort and HDMI)* and many peripherals over a single cable
Supports all common operating systems and host computers with USB Type A and C interface
Integrated 5 port USB Type A and Type C Hub (2x 10 Gbps, 3x 5Gbps)
Supports Power Delivery 3.0 up to 100W (requires USB Type C/TB3/4 host connection)
2-year warranty
The Lindy USB Type C and Type A Hybrid Laptop Docking Station is a professional, multifunctional solution for connecting literally
any host computer (laptop, Macbook, tablet, smartphone) with USB Type C and USB Type A port to a range of interfaces including
three displays, using a single cable. It simultaneously provides triple monitor capabilities, power, Gigabit Ethernet, Audio and a
USB 3.2 SuperSpeed hub with data transfer rates up to 10Gbps.
This Docking Station combines DisplayLink and DisplayPort Alternate Mode technology and enables the connection of two or three
monitors via HDMI and/or DisplayPort, no matter whether you connect a Windows or Mac computer. When using a single monitor,
resolutions up to Ultra HD 4K 60Hz can be displayed. Alternatively, when using a triple monitor set up the maximum resolutions
are 2x 4K 60Hz and 1x 4K 30Hz. Thanks to DisplayLink technology, it also supports dual extended displays on MacBooks with both
the Intel processor or Apple M1 chip.
The included high capacity 130W PSU powers the Docking Station and at the same time allows the Dock to use USB Power Delivery
via USB-C to power the connected laptop and charge it extremely fast with up to 100W. The Docking Station features a high-speed
•
•
•
•
•
| TECHNICAL DATA SHEET
LAN port for fast connection to the corporate network, an integrated USB 3.2 hub that provides three Type A ports and two Type C
ports for a variety of USB devices and an Audio combo port for headsets or a microphone. The power button enables power saving
and the Kensington lock provides protection in shared offices.
* HDMI port Nr. 3 requires connection to a host computer with DisplayPort Alternate Mode support (USB Type C or Thunderbolt
3/4)
Information about USB 3.0, 3.1 & 3.2
USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB
Type C host interface.
USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5 Gbps.
USB 3.1 Gen 2 and USB 3.2 Gen 2 both support data transfer rates up to 10 Gbps.
Speci cationsfi
Interface: USB Type C to 3x USB Type A, 2x USB Type C, 1x RJ45, 3x HDMI, 2x DP, 1x 3.5mm Audio
Interface Standard:USB 3.2 / 3.1 Gen 2 & Gen 1 / USB 3.0, HDMI 1.4, DP 1.2, Gigabit LAN, Audio
Supported Bandwidth: 10Gbps, 5Gbps, 10/100/1000Mbps
Maximum Input Resolution: 3840x2160 60Hz
Maximum Output Resolution:
Single Display: 3840x2160@60Hz
Dual Display: 3840x2160@60Hz; HDMI3: 4K30Hz (DP Alt Mode)
Triple display: 2x 4K 60Hz, 1x 4K 30Hz (on HDMI 3)
Chipset:DL6950, PS8822, PS176, VL103R, VL162, VL162, VL817, VL822, RTL8211F
Compatibility: USB Type C/A or Thunderbolt 3/4 equipped computers; Windows, macOS, Linux, Android, Chrome OS
Power Delivery:PD 3.0 up to 100W (20V 5A)
HDCP Support: Supports HDCP2.2 (only on HDMI port Nr. 3）
Supported Audio: Supports 16bit/48K Audio Sampling Rate
Separate Audio Ports: 1x Audio combo port 3.5mm
Special Features: Supports DisplayLink (MST on USB A devices, Apple incl. M1), DisplayPort Alternate mode, Kensington
lock, Power button, Battery Charging 1.2
Connectors
Inputs:1 x USB Type C (Female)
Outputs: 3x USB Type A (Female), 2x USB Type C (Female), 1x RJ45 (Female), 3x HDMI (Female), 2x DisplayPort (Female),
1x 3.5mm Audio (Female)
Power: 5.5/2.1mm DC socket
Physical Properties
Dimensions WxDxH:190x85x30mm (7.48x3.3x1.18in)
Housing Material: Plastic
Net Weight: 0.396kg (0.837lb)
Operating Temperature: -20°C - 40°C (-4°F - 104°F)
Storage Temperature: -40 °C - 80°C (-40°F - 176°F)
•
•
•
•
•
◦
◦
◦
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
| TECHNICAL DATA SHEET
Humidity: 5 - 90% RH ( non-condensing)
Power Requirements: 30W
Colour: Black
Miscellaneous
Packaging Type: Carton Box
Packaging Dimensions: 323x205x50mm (12.72x8.07x1.97in)
Gross Weight:1.2kg (2.69lb)
Warranty (Years): 2
Product Compliance: CE, FCC, REACH & RoHS, CP65
Package Contents
USB Type C and Type A Hybrid Laptop Docking Station
External power supply 24V 5.41A with DC cable
IEC C13 power cable (UK, Schuko, US, AUS)
1m USB Type C to C cable with C/A adapter
Lindy Manual
Purchasing Information
No.: 43366
EAN: 4002888433662
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
| TECHNICAL DATA SHEET
