Mac Audio Power Star 16.2 Bruksanvisning
Les nedenfor 📖 manual på norsk for Mac Audio Power Star 16.2 (1 sider) i kategorien Høyttaler. Denne guiden var nyttig for 2 personer og ble vurdert med 4.8 stjerner i gjennomsnitt av 1.5 brukere
Side 1/1
POWER STAR 2.16 POWER STAR 2.13
POWER STAR 69.3
POWER STAR 16.2 POWER STAR 13.2 POWER STAR 10.2
HIGHLIGHTS
• Solid steel basket including additional voice-coil ventilation
• Polypropyleneconewithtitaniumhairlinenish
• Long excursion rubber surround
• Titanium-coated tweeter/midrange cone (69.3)
• Mac Audio design magnet protection cover
• SuspensionandmagneticeldoptimisedwithKLIPPEL
®
measurement system
• Solid hexagon protection cover with aluminium diamond-cut logo
• Titanium tweeter (2.16/2.13)/ Titanium-coated tweeter cone
• ExternalXOincludingPTCtweeterprotectioncircuit(2.16/2.13)
MacAudio·Lise-Meitner-Str.9·D-50259Pulheim·www.mac-audio.de·Technicalmodicationsanderrorsexcepted01/16
POWER STAR
SPEAKER SERIES
SPECIFICATIONS
Power Star 2.16 Power Star 2.13 Power Star 69.3 Power Star 16.2 Power Star 13.2 Power Star 10.2
Principle 2-way 2-way 3-way 2-way 2-way 2-way
System compo compo triaxial coaxial coaxial coaxial
Power handling RMS/max. (W) 100/400 80/320 120/480 100/400 80/320 60/240
Impedance (Ω) 4 4 4 4 4 4
Frequency response (Hz) 30-26 000 34-26 000 28-24 000 30-24 000 34-24 000 38-24 000
Crossover frequencies (Hz) 3 800 3 800 2 800/4 200 4 200 4 200 4 200
SPL (dB) 90 90 91 90 90 89
DIN-Ø (mm) 165 W/19 T 130 W/19 T 6x9 /0.5 /2 165 W/13 T 130 W/13 T 100 W/13 T˝ ˝ ˝
Cutting Out (mm) 142 W/38 T 113 W/38 T 221 x 151 142 113 94
Mounting depth (mm) 57 W/ 17 T 51 W/ 17 T 78 57 51 50
Art.No. 110 5726 110 5723 110 5719 110 5716 110 5713 110 5710
EAN. 40 23037 05726 3 40 23037 05723 2 40 23037 05719 5 40 23037 05716 4 40 23037 05713 3 40 23037 05710 2
Produkspesifikasjoner
| Merke: | Mac Audio |
| Kategori: | Høyttaler |
| Modell: | Power Star 16.2 |
