Side 1/13

The Martin Experience

C4.8T, C.6.8T, C8.1T

User’s Guide

Installation Guide

Martin Audio Ceiling Loudspeakers C4.8T, C6.8T, C8.1T

Description

Martin Audio C4.8T, C6.8T and C8.1T ceiling loudspeakers are all 2-way designs using

soft dome tweeters for the widest dispersion and excellent off-axis performance. All

models have perforated steel grilles, UL94 V-0 baffle materials, steel back cans and

feature rising clamp connectors that accept up to 2.5sqm conductors.

Unpacking

Thank you for purchasing a Martin Audio ceiling loudspeaker system. Every Martin

Audio product is built to the highest standard and thoroughly inspected before it leaves

the factory. After unpacking, examine the product carefully. Inform your dealer if transit

damage is found. We suggest that you retain the original packaging so that the system

can be repacked at a future date if necessary. Martin Audio and its distributors cannot

accept responsibility for product damaged through the use of non-approved packaging.

Compliance

These products conform to:

EMC Directive 89/336/EEC

Low Voltage Directive 73/23/EEC

These products comply with UL2043 Fire Tests for

Heat & Visible Smoke Release for Discrete

Products and their Accessories Installed in Air

Handling Spaces.

Listed UL1480 General Signaling Speakers.

SUITABLE FOR USE IN AIR HANDLING SPACES

See page 3 for recommended ceiling hole sizes >>

See appendix for outline dimensions >>

Produkspesifikasjoner

Merke:	Martin Audio
Kategori:	Høyttaler
Modell:	C8.1T
Vekt:	6700 g
Dybde:	258 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Diameter:	354 mm
Antall per pakke:	1 stykker
Anbefalt bruk:	Universell
Impedans:	16 Ω
Høyttalerplassering:	Innbygget Vegg/Tak
Basshøyttaler:	Ja
Peak Music Power Output (PMPO):	500 W
Diskanthøyttaler:	Ja
Høyttalerposisjon:	Senter
Produktfarge:	Hvit
Signal-til-støy-forhold (SNR):	110 dB
Kroppsmateriale:	Stål
Lyd-utgang kanaler:	- kanaler
RMS-rangert strøm/utgangseffekt:	125 W
Monteringsbeslag inkludert:	Ja
Antall drivere:	2
Høyttaler type:	Full rekkevidde
Frekvensrekkevidde:	80 - 18000 Hz
Basshøyttalerens diameter:	200 mm
Diskant diameter:	25 mm
Sensitivitet/følsomhet:	91 dB
Diskanthøyttalerens diameter:	1 "
Basshøyttalerens diameter (imperisk):	8 "
Antall drivere til diskant:	1
Antall basshøyttalerdrivere:	1
Lydtrykksnivå (maks):	116 dB
Transformatortilkoblinger:	60 W
