marvelrefrigeration.com | 800.223.3900
Storage Capabilities
• Stores 15 lbs of crescent ice
Aesthetics
• Easy-to-install panel overlay option
• Finish options: stainless steel, black or overlay (panel ready)
Additional Convenience
• No pump or drain required
• Close Door Assist System
™
gently and automatically draws door to a
close, ensuring door is never accidentally left ajar
• Black toe kick adjustable to 4” with leveling legs
• Filler kit available for 18” wide opening
• 1-year parts and labor warranty, 5-year sealed system parts warranty
15” Marvel Crescent Ice Machine
Model # ML15CR
Built in the USA
Ordering Options
Solid Stainless Steel Door, Right Hinge,
Stainless Designer Handle
ML15CRS1RS
Solid Stainless Steel Door, Left Hinge,
Stainless Designer Handle
ML15CRS1LS
Solid Smooth Black Door, Right Hinge,
Black Designer Handle
ML15CRS1RB
Solid Smooth Black Door, Left Hinge,
Black Designer Handle
ML15CRS1LB
Panel-Ready Solid Overlay Door,
Right Hinge (Handle Not Included)*
ML15CRP1RP
Panel-Ready Solid Overlay Door,
Left Hinge (Handle Not Included)*
ML15CRP1LP
*Easy installation! No panel kit required. Consult your cabinet maker for overlay
panel and handle options.
14
7
/
8
" W
33
3
/
4
" H
25
5
/
8”
D
including
handle
Solid Overlay
(Panel Ready)*
BlackStainless Steel
Finish Options
marvelrefrigeration.com | 800.223.3900
Clearance for
screw head,
4 places
Clearance
for hinge
2 places
Right Hand Hinged Door
15" (38.1 cm) wide appliance
Right Hand Hinged Door
15" (38.1 cm) wide appliance
Clearance for
screw head,
4 places
Clearance
for hinge
2 places
Left Hand Hinged Door
15" (38.1 cm) wide appliance
Left Hand Hinged Door
15" (38.1 cm) wide appliance
4
7
⁄8"
(12.4 cm)
1
3
⁄
16
"
(3 cm)
3
1
⁄8"
(7.9 cm)
1
1
⁄2"
(3.8 cm)
typical
Hinge side of door
Top of door
14
3
⁄4"
(37.5 cm)
1
⁄4" (6 mm)
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore
1
⁄4" (6 mm)
deep 4 places.
1
3
⁄4"
(4.4 cm)
2"
(5.1 cm)
3
11
⁄16"
(9.4 cm)
1
⁄4" (6 mm)
radius is
permissible
1
11
⁄16"
(4.3 cm)
4
7
⁄8"
(12.4 cm)
1
3
⁄16"
(3 cm)
3
1
⁄8"
(7.9 cm)
1
1
⁄2"
(3.8 cm)
typical
1
11
⁄16"
(4.3 cm)
Hinge side of door
14
3
⁄4"
(37.5 cm)
1
⁄4" (6 mm)
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore
1
⁄4" (6 mm)
deep 4 places.
1
3
⁄4"
(4.4 cm)
2"
(5.1 cm)
3
11
⁄16"
(9.4 cm)
This side
facing interior
This side
facing interior
1
⁄4" (6 mm)
radius is
permissible
1
5
⁄32"
(2.9 cm)
1
5
⁄32"
(2.9 cm)
30
11
⁄32"
(77.1 cm)
30
11
⁄32"
(77.1 cm)
Panel Overlay Dimensions
Rough-In Dimensions
A. Rough-In Width 15”
B. Rough-In Height 34” to 35”
C. Rough-In Depth 24”
Product Dimensions
D. Width 14 7/8”
E. Height 33 3/4” to 34 3/4”
F. Depth 19 23/32”
G. Depth to Front of Door
Solid Door 21 25/32”
Overlay Door 21 1/32
H. Depth to Handle 25 7/32” (Stainless Steel)
I. Depth with door at 90˚
Solid Door 35 5/8”
Overlay Door 35 5/8”
Product Features
Interior Cabinet Finish White
Capacity 15 lbs of Ice Storage
Shelving System NA
Shelf Fronts NA
Other Storage Ice Bin
Interior Lighting NA
Toe Grill Finish Black
Hinge Classic Hinge
Handle
Slim Designer Handle
(Panel Overlay Does
Not Include Handle)
Control Type NA
Temperature Range NA
Lock No
Electrical Requirements 120V / 60Hz / 15A
Length of Power Cord 6’
Shipping Weight 127 lbs
Finishes Stainless Steel, Overlay, Black
Vacation Mode No
Agency Approvals CSA
"A"
"B"
"C"
"D"
"E"
"A"
"B"
"C"
"D"
"E"
"G"
"H"
"I"
"G"
"H"
"I"
"A"
"B"
"C"
"D"
"E"
"A"
"B"
"C"
"D"
"E"
"G"
"H"
"I"
"G"
"H"
"I"
Product Dimensions
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the owner’s guide.
