Side 1/2
marvelrefrigeration.com | 800.223.3900
Performance
• Tested to hold up to 200 lbs of frozen goods
• Dynamic Cooling Technology
™
delivers rapid cool down, frost-free
operation and the industry’s best temperature stability
• Adjustable FreshFlo
™
stainless steel shelf helps efciently circulate
cold air and ensures even temperature stability
• Now even quieter operation thanks to exclusive design
enhancements to buffer and minimize sound
Storage Capabilities
• 4.7 total cu. ft.
• Keep items organized and within easy reach with two commercial-
grade chrome wire freezer bins on the fully extendable Smooth
Glide
™
ball bearing system
• Also includes (1) full-width adjustable cantilevered FreshFlo
™
stainless steel shelf (removable)
Touchpad Controls
• Multifunction Marvel Intuit
™
Integrated Controls allow you to select
a precise cabinet temperature from -10° F to 10° F to keep contents
evenly frozen
• Vacation mode conserves energy during times when unit
is not in use
Aesthetics
• Pristine white interior easily wipes clean
• Efcient arctic white LED lighting illuminates interior
for better viewing
• Easy-to-install panel overlay option features soft-close integrated
hinge for a truly ush t with cabinetry
• Finish options: stainless steel or overlay (panel ready)
Additional Convenience
• Close Door Assist System
™
gently and automatically draws door to a
close, ensuring door is never accidentally left ajar
• Black toe kick adjustable to 4” with leveling legs
• 1-year parts and labor warranty, 5-year sealed system parts warranty
24” Marvel All Freezer
Model # ML24FA
23
7
/
8
" W
33
3
/
4
" H
25
5
/
8”
D
including
handle
Built in the USA
Stainless Steel
Solid Overlay
(Panel Ready)*
Finish Options
Ordering Options
Solid Stainless Steel Door, Right Hinge,
Stainless Designer Handle
ML24FAS1RS
Solid Stainless Steel Door, Left Hinge,
Stainless Designer Handle
ML24FAS1LS
Panel-Ready Solid Overlay Door,
Integrated Right Hinge (Handle Not Included)*
ML24FAP2RP
Panel-Ready Solid Overlay Door,
Integrated Left Hinge (Handle Not Included)*
ML24FAP2LP
*Easy installation! No panel kit required. Consult your cabinet maker for overlay
panel and handle options.
marvelrefrigeration.com | 800.223.3900
Left Hand Hinged Door
24" (61 cm) wide appliance
Right Hand Hinged Door
24" (61 cm) wide appliance
23
3
⁄4"
(60.3 cm)
1" (2.5 cm) diameter
x
1
⁄4" (6 mm) deep
4 places
4
7
⁄8"
(12.4 cm)
1
3
⁄16"
(3 cm)
14"
(35.6 cm)
1
⁄4" (6 mm)
radius is
permissible
3
1
⁄
8
"
(7.9 cm)
1
3
⁄4"
(4.4 cm)
2"
(5.1 cm)
3
11
⁄16"
(9.4 cm)
1
1
⁄2"
(3.8 cm)
typical
1
⁄4"
(6 mm)
Deep
1
11
⁄16"
(4.3 cm)
Hinge side of door
Top of door
Clearance for hinge
at top and bottom
Clearance for hinge
at top and bottom
Clearance for
screw head,
4 places
Left Hand Hinged Door
24" (61 cm) wide appliance
23
3
⁄4"
(60.3 cm)
1" (2.5 cm) diameter
x
1
⁄4" (6 mm) deep
4 places
4
7
⁄8"
(12.4 cm)
1
3
⁄
16
"
(3 cm)
14"
(35.6 cm)
1
⁄4" (6 mm)
radius is
permissible
3
1
⁄8"
(7.9 cm)
1
3
⁄4"
(4.4 cm)
2"
(5.1 cm)
3
11
⁄16"
(9.4 cm)
1
1
⁄2"
(3.8 cm)
typical
1
⁄4"
(6 mm)
Deep
1
11
⁄16"
(4.3 cm)
Hinge side of door
Top of door
Clearance for
screw head,
4 places
Right Hand Hinged Door
24" (61 cm) wide appliance
This side
facing interior
This side
facing interior
1
5
⁄32"
(2.9 cm)
1
5
⁄32"
(2.9 cm)
30
11
⁄32"
(77.1 cm)
30
11
⁄32"
(77.1 cm)
Panel Overlay Dimensions
Rough-In Dimensions
A. Rough-In Width 24”
B. Rough-In Height
Solid Door 34” to 35”
Overlay Door
34” 1/4 to
35” 1/4
C. Rough-In Depth 24”
Product Dimensions
D. Width 23 7/8”
E. Height
Solid Door
33 3/4” to
34 3/4”
Overlay Door 34” to 35”
F. Depth 21 1/2
G. Depth to Front of Door
Solid Door 23 23/32”
Overlay Door
22 7/8”
Without
Handle
H. Depth to Handle 25 21/32” (Stainless Steel)
I. Depth with door at 90˚
Solid Door 46 13/32”
Overlay Door 46 1/2”
Product Features
Interior Cabinet Finish White
Capacity Up to 200 lbs of frozen food
Shelving System Cantilever
Shelf Fronts Stainless Steel
Other Storage 2 Chrome Wire Freezer Bins
Interior Lighting White LED
Toe Grill Finish Black
Hinge Classic Hinge
Handle
Slim Designer Handle
(Panel Overlay Does
Not Include Handle)
Control Type Intuit
™
Temperature Range -10° to 10° F
Lock No
Electrical Requirements 120V / 60Hz / 15A
Length of Power Cord 6’
Shipping Weight 160 lbs
Finishes Stainless Steel, Overlay
Vacation Mode Yes
Agency Approvals CSA, ENERGY STAR
"A"
"B"
"C"
"D"
"E"
"A"
"B"
"C"
"D"
"E"
"I"
"G"
"H"
"I"
"G"
"H"
"F"
"F"
"A"
"B"
"C"
"D"
"E"
"A"
"B"
"C"
"D"
"E"
"I"
"G"
"H"
"I"
"G"
"H"
"F"
"F"
Product Dimensions
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the owner’s guide.
