Marvel Outdoor MO24RF2R Bruksanvisning
Marvel
vinkabinett
Outdoor MO24RF2R
Les nedenfor 📖 manual på norsk for Marvel Outdoor MO24RF2R (2 sider) i kategorien vinkabinett. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/2
marvelrefrigeration.com | 800.223.3900
Performance
• CSA certied for outdoor use to withstand elements like rain,
corrosion, high humidity and heat
• Tested to perform in temperatures as high as 115° F
• Dynamic Cooling Technology
™
delivers the industry’s best
temperature stability and rapid cool down, tested and proven
to cool nearly 2x faster than competitors
• Thermal-efcient insulated cabinet ensures optimum
energy efciency and cooling performance
Storage Capabilities
• Refrigerator’s 3.9 cu. ft. holds up to (72) 12-oz cans
• Interior 1 cu. ft. freezer with self-closing door is large enough
to hold up to 12 pints of ice cream
• Optional ice maker kit available to produce and store up to 13 lbs of
crescent ice (accessory part #S42418151, eld installable)
• (2) partial-width cantilevered, fully adjustable FreshFlo™ commercial-
grade stainless steel shelves, (1) full-width, xed-position stainless-
steel-framed glass shelf, (1) MaxStore
™
bin and (1) stainless-steel
freezer shelf (removable)
• MaxStore
™
smooth-glide clear bin organizes loose, bulky items;
capable of storing 15 lbs of produce, 4 wine bottles
or (22) 12-oz cans
• Adjustable cantilevered shelving allows easy customization to meet
your changing storage needs
Touchpad Controls
• Marvel Intuit
™
controls for precise, frost-free temperature
management between 34° to 42° F and a freezer temperature
between -6° F and 6° F to keep contents evenly frozen throughout
• Audible alarms for door ajar and high/low temperature ensure your
contents stay at optimal temperature
Aesthetics
• Corrosion-resistant stainless steel exterior, commercial grade 6-foot
power cord, sturdy pro-style handle and rugged stainless steel toe
kick
• Pristine white interior is easy to wipe clean, even in the corners
• Efcient arctic white LED lighting brightly illuminates interior for
better viewing of contents
• Finish: stainless steel
Additional Convenience
• Door lock provides added safety and security
• Close Door Assist System
™
gently and automatically draws door to a
close, ensuring door is never accidentally left ajar
• Stainless steel toe kick adjustable to 4” with leveling legs
• 1-year parts and labor warranty, 5-year sealed system parts warranty
24” Marvel Outdoor Refrigerator
and Freezer with Ice Maker Option
Model # MO24RF
Ordering Options
Solid Stainless Steel Door with Lock,
Right Hinge, Professional Handle
MO24RFS2RS
Solid Stainless Steel Door with Lock,
Left Hinge, Professional Handle
MO24RFS2LS
Outdoor Ice Maker Kit, Ice Bin Included
(Field Installable)
S42418151
*Easy installation! No panel kit required. Consult your cabinet maker for overlay
panel and handle options.
Stainless Steel
Finish
23
7
/
8
" W
33
3
/
4
" H
26
7
/
32
" D
including
handle
Built in the USA
US
C
Certied for Outdoor Use
marvelrefrigeration.com | 800.223.3900
"A"
"B"
"C"
"D"
"E"
"A"
"B"
"C"
"D"
"E"
"I"
"G"
"H"
"I"
"G"
"H"
"F"
"F"
"A"
"B"
"C"
"D"
"E"
"A"
"B"
"C"
"D"
"E"
"I"
"G"
"H"
"I"
"G"
"H"
"F"
"F"
Product Dimensions
Rough-In Dimensions
A. Rough-In Width 24”
B. Rough-In Height 34” to 35”
C. Rough-In Depth 24”
Product Dimensions
D. Width 23 7/8”
E. Height 33 3/4” to 34 3/4”
F. Depth 21 1/2”
G. Depth to Front of Door 23 23/32”
H. Depth to Handle 26 7/32”
I. Depth with door at 90˚ 46 13/32”
Product Features
Interior Cabinet Finish White
Capacity
Refrigerator: Up to 72 12-oz cans
Freezer: Up to 72 12-oz cans
Optional 13 lbs of
Crescent Ice Storage:
Shelving System Cantilever
Shelf Fronts Stainless Steel
Other Storage
1 cu ft. Freezer
Interior Lighting White LED
Toe Grill Finish Stainless Steel
Hinge Classic Hinge
Handle Professional
Control Type Prime
™
Temperature Range
Refrigerator: 34° to 42° F
Freezer: -6° to 6° F
Lock Yes
Electrical Requirements 120V / 60Hz / 15A
Length of Power Cord 6’
Shipping Weight 160 lbs
Finishes Stainless Steel
Vacation Mode No
Agency Approvals CSA, ENERGY STAR
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the owner’s guide.
Produkspesifikasjoner
| Merke: | Marvel |
| Kategori: | vinkabinett |
| Modell: | Outdoor MO24RF2R |
