Side 1/8
Model Numbers:
MH-03-240-GH / MH-05-240-GH
CONSUMER: READ AND SAVE THESE INSTRUCTIONS
USE THIS HEATER ONLY AS DESCRIBED IN THIS MANUAL. ANY
OTHER USE NOT RECOMMENDED BY THE MANUFACTURER
MAY CAUSE FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.
4003787
WARNING
Safety Information
FIRE OR EXPLOSION MAY OCCUR! Heater has hot arching or
sparking parts inside. Do not use it in areas where gasoline, paint
or flammable liquids are used or stored.
RISK OF FIRE. To prevent a possible fire, Do not block intakes
or exhaust in any manner. Do not use on soft surfaces, like a bed
where openings may become blocked. Heater must be kept clear
of all obstructions. Maintain a 3 foot minimum clearance from front and 12 inches from sides
and rear. Heaters must be kept clean of lint, dirt, and debris (see maintenance instructions
Page 5).
RISK OF FIRE. DO NOT use heater with extension cord. Plug the
heater directly into a 208-240VAC receptacle.
OVERHEATING OR FIRE MAY OCCUR. Do not place heater
behind doors.
BURN HAZARD. This heater is hot when in use. To avoid burns,
do not let bare skin touch hot surfaces. If provided, use handles
when moving the heater
RISK OF ELECTRIC SHOCK OR INJURY. Do not run cord under
carpeting, Do not cover cord with throw rugs, runners or similar
coverings. Do not route cord under furniture or appliances. Arrange
cord away form the traffic area where it will not cause a tripping hazard. Do not operate
any heater with a damaged cord or plug, or after heater malfunctions, or has been dropped
or damaged in any manner. Discard heater, or return to authorized service facility for
examination and / or repair.
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
RISK OF ELECTRICAL SHOCK. Connect to properly
grounded outlets only. Do not insert or allow foreign
objects to enter any ventilation or exhaust opening as
this may cause an electric shock or fire, or damage the heater. Unplug heater
before performing any maintenance or when not in use, To disconnect heater,
turn control to low, then remove plug from outlet.
WARNING
1 Industrial Blvd #101, Sauk Rapids, MN 56379 USA • Toll Free (800) 779-3267
Fax: 320-251-2922 • Web: www.masterindustrialproducts.com • Email: info@pinnacleclimate.com
© 2017 Pinnacle Climate Technologies, Inc. MAEA-401
User’s Manual &
Operating Instructions
ELECTRIC GARAGE HEATER
NEVER LEAVE HEATER UNATTENDED WHILE CONNECTED TO A POWER SOURCE
© 2017, Pinnacle Climate Technologies, Inc. Electric Garage Heater User’s Manual1
CAUTION – RISK OF ELECTRIC SHOCK
DO NOT OPEN HEATER SHELL
NO USER-SERVICEABLE S INSIDEPART
NEVER SUSPEND ANY OBJECTS FROM MOUNTED HEATER
CALIFORNIA RESIDENTS: This product contains chemicals, including
lead, known to the State of California to cause birth defects or other
reproductive harm. Wash hands after handling.
Safety Information
WARNING
WARNING
Turn the electrical power off at the electrical panel board
(circuit breaker or fuse box) and lock or tag the panel board
door to prevent someone from turning on the power while
you are working on the heater. When using electrical appliances, basic precautions
should always be followed to reduce the risk of fire, electric shock and injury to
persons, including the following:
Read all
instructions before
using this heater.
RISK OF ELECTRIC
SHOCK!
WARNING
WARNING
WARNING
– Extreme caution is necessary when any heater is
used by or near children or invalids.
– Do not use outdoors.
– This heater is not intended for use in bathrooms,
laundry areas and similar indoor locations. Never
locate heater where it may fall into a bathtub or
other water container.
– Do not use heater in wet or moist locations.
– Always locate heater on a stable and level
surface.
– Do not place the heater against paperboard or
low-density berboard surfaces.
– Avoid using an extension cord because the
extension cord may overheat and cause a risk of
re.
– ALWAYS use only the electrical power (voltage
and frequency) specified on the model plate of the
heater.
– ALWAYS use only three-prong, grounded outlet
and extension cord.
– ALWAYS unplug the heater when not in use.
– ALWAYS install the heater so that it is not directly
exposed to water spray, rain, dripping water, or
wind.
– Keep all combustible materials away from
this heater
CAUTION!
HOT WHILE IN
OPERATION.
DO NOT TOUCH. KEEP CHILDREN,
ANIMALS, CLOTHING AND
COMBUSTIBLES AWAY FROM HEATER.
Minimum Clearance From Combustibles
MH-03-240-GH MH-05-240-GH
Front 3 ft. 3 ft.
Top 1 ft. 1 ft.
Sides 1 ft. 1 ft.
Rear 1 ft. 1 ft.
WARNING
Look for this icon throughout the manual for helpful tips on how to
assemble, use and clean your Electric Fan Heater.
NEVER LEAVE HEATER UNATTENDED WHILE CONNECTED TO A POWER SOURCE
© 2017, Pinnacle Climate Technologies, Inc. Electric Garage Heater User’s Manual
Specications
Model # MH-03-240-GH MH-05-240-GH
BTU 10,200 17,000
Watts 3,000 5,000
Heating Area (ft2) 320 540
Power (Volts) 240V~60Hz 240V~60Hz
Amps 15 30
Heat Settings 1 2
Specications subject to change without notice.
Features
MH-03-240-GH / MH-05-240-GH
2
Figure 1
Adjustment Knob
Front Guard
Fan
Heater Coil
Swivel Bracket
Thermostat Knob
Function Selector
Power Light
Caution Light
Troubleshooting
Locating Your Serial Number:
Your serial number can be found on the heater’s rating label. It will begin with the letters FH followed
by 9 digits. For Example: FH120900170. Have your Serial Number ready before calling customer
service at 800-779-3267.
