Max KM01G Bruksanvisning

Max Mikrofon KM01G

Les nedenfor 📖 manual på norsk for Max KM01G (2 sider) i kategorien Mikrofon. Denne guiden var nyttig for 24 personer og ble vurdert med 4.8 stjerner i gjennomsnitt av 12.5 brukere

Last ned PDF

Side 1/2

Tronios.com Bedrijvenpark Twente 415 7602KM Almelo The Netherlands

ENGLISH

Congratulations to the purchase of this Max product. Please read this manual thoroughly prior to using the product in order to

benefit fully from all features.

BUTTONS

ON/OFF: Hold for ON/OFF, press to switch modes.

PREV/UP: Press to go to previous song. Press in selfie-

mode to take a photo with your mobile phone.

NEXT/DOWN: Press to go to next song. Press in selfie-

mode to take a photo with your mobile phone.

PLAY/PAUSE: Press to change between play and pause.

REC: Press and hold shortly to change voice style.

The voice transformer allows to change between 4

different voice styles.

+: Increase volume.

-: Decrease volume.

OPERATION

1. Supply power: hold the “ON/OFF” button to power up the device.

2. BT connection: enable BT on your smartphone and connect with the microphone. The microphone emits a specific

tone to indicate that the connection has been successful.

3. Adjust volume: adjust the microphone volume to a suitable level.

4. Start your Karaoke session!

RECORDING WITH SMARTPHONE

1. Connect the “recording” cable (micro-USB to 3.5mm jack). Insert the micro-USB end of the cable in the micro-USB slot

on the bottom interface of the microphone. Plug the 3.5mm jack end of the cable in the 3.5mm jack on your

smartphone.

2. Open your favourite Karaoke or other recording app and record your Karaoke adventures.

3. Save the song: operate according to the instructions of your favourite Karaoke or recording software.

SELFIE FUNCTION

1. Press the “ON/OFF” button to switch from wireless- to selfie mode.

2. Enable BT on your smartphone. Search for “shutter” and make connection.*

3. Open the photo interface of your smartphone, press “up” or “down” buttons on the microphone to take shots.

*Only for iOS version 6.0 and Android version 4.2.2 or higher. This function is not supported on smartphones that have an

independent and dedicated photo button.

TECHNICAL SPECIFICATIONS

Output power : 5W

Frequency response : 100 Hz-10kHz

SPL max : >115dB

Power supply : Built-in 18650 Li-battery

Battery capacity : 1800mAh DC5V charging

The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can be changed

without prior notice.

The products referred to in this manual conform to the European Community Directives to which they are subject:

• Electromagnetic Compatibility (EMC) 2014/30/EU

• Restriction of Hazardous Substances (RoHS) 2011/65/EU

Produkspesifikasjoner

Merke:	Max
Kategori:	Mikrofon
Modell:	KM01G
Høyde:	226 mm
Strømkilde:	Batteri/USB
Batterikapasitet:	1800 mAh
USB-port:	Ja
USB-kontakttype:	Micro-USB, USB Type-A
Tilkoblingsteknologi:	Trådløs
Diameter:	76 mm
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Volumkontroll:	Knapper
Sertifisering:	CE
Støyreduksjon:	Ja
Driftsspenning:	5 V
Mikrofonfrekvens:	100 - 10000 Hz
Batteriteknologi:	Lithium
Batteritype:	18650
Mikrofonvekt:	350 g
Produktfarge:	Gull
Hodetelefon ut:	Ja
Kabler inkludert:	USB
Modell/Type:	Karaokemikrofon
Antall medfølgende produkter:	1 stykker
Mikrofonsensitivitet/mikrofonfølsomhet:	115 dB
