Metra 88-00-9007 Bruksanvisning
Les nedenfor 📖 manual på norsk for Metra 88-00-9007 (4 sider) i kategorien Bilsett. Denne guiden var nyttig for 2 personer og ble vurdert med 5.0 stjerner i gjennomsnitt av 1.5 brukere
Side 1/4
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 1/23/18 INST88-00-9007
INSTALLATION INSTRUCTIONS
88-00-9007
KIT FEATURES
• Pocket provision for ISO DIN installations
• Holds (3) CD jewel cases
• Includes USB charging adapter
KIT COMPONENTS
• A) Pocket • B) Nissan/Infiniti/Mercury trim • C) Mitsubishi trim • D) Subaru trim • E) Toyota/Lexus trim • F) (4) # 8 x 1/4” Phillips screws
• G) USB charging socket/cable
TOOLS REQUIRED
• Phillips screwdriver
TABLE OF CONTENTS
Applications............................................................2
Kit Assembly .......................................................2-3
WIRING & ANTENNA CONNECTIONS
(sold separately)
• Please use the vehicle fit guide available
at metraonline.com
A B DC
ISO-DIN pocket 1981-2012
E
F G
Infiniti, Lexus, Mercury, Mitsubishi, Nissan, Subaru, Toyota
(see applications on page 2)
1.800.221.0932
|
MetraOnline.com
2
APPLICATIONS KIT ASSEMBLY
(Figure B)
(Figure A)
1. Remove the fuse holder cover and
pigtail from the USB charging socket
fuse holder, then remove the fuse.
2. Insert and click in the socket to the
appropriate faceplate, lining up the
keyway in the socket with the groove in
the faceplate. Reference the legend to
locate the appropriate faceplate.
(Figure A)
3. Knock out the rear of the pocket to
allow the socket wiring to go through,
then route the wiring through the hole.
(Figure B)
Continued on the next page
Infiniti
G20 ........................................1999-2002
I30 ......................................... 1996-1999
J30 .......................................... 1993-1997
M30 .........................................1990-1992
Q45 ........................................ 1990-1996
Lexus
ES 250 ....................................1990-1991
LX 450 ....................................1996-1997
Mercury
Villager .................................1993-2002
Mitsubishi
3000 GT ..................................1991-1999
Diamante ..............................1992-2004
Diamante Wagon .................1993-1995
Eclipse ...................................1995-2005
Eclipse Spyder ......................1995-2005
Galant (w/ separate a/c) .....2004-2012
Galant ....................................1994-1998
Mirage ................................... 1997-2002
Montero ................................1997-2006
Montero Sport .................... 2000-2004
Outlander ............................2003-2006
Nissan
200SX .....................................1995-1998
240SX .....................................1989-1998
Altima ....................................1993-2001
Frontier .................................1998-2004
Hardbody Pickup ..................1994-1997
Maxima
(w/o wrap around radio) ...2000-2003
Maxima ..................................1995-1999
Maxima ...................................1987-1991
Pathfinder SE ......................2003-2004
Pathfinder (w/o nav) ..........2001-2002
Pathfinder ........................... 1994-2000
Pulsar .....................................1987-1990
Quest .....................................1993-2003
Sentra ....................................1995-1999
Stanza .................................... 1987-1992
Xterra .................................. 2000-2004
Subaru
Baja ......................................2003-2006
Forester .................................1998-2008
Impreza ................................1993-2007
Legacy ...................................1995-2004
Outback ................................1998-2004
Outback Sport .....................2005-2006
Toyota
4-Runner ..............................1984-2002
Avalon ....................................1995-1999
Camry .....................................1983-1991
Camry ....................................1992-2001
Camry Solara ........................1999-2003
Celica ......................................1982-1993
Celica ..................................... 1994-1999
Corolla (coupe/hatchback) .. 1982-1983
Corolla ....................................1984-1997
Cressida ..................................1981-1992
Land Cruiser (without nav) 2000-2002
Land Cruiser ..........................1993-1999
Land Cruiser ..........................1988-1992
MR2 ........................................1985-1995
Paseo ..................................... 1992-1997
Pickup ....................................1984-1995
Previa ......................................1991-1997
Rav-4 ....................................2001-2002
Sequoia .................................2001-2002
Sienna ...................................1996-2003
Supra ......................................1983-1992
Supra ......................................1994-1998
T-100 .......................................1993-1998
Tacoma .................................1995-2004
Tercel ......................................1983-1986
Tercel ...................................... 1987-1998
Tundra ..................................2000-2002
Van ........................................ 1984-1990
Legend
Refer to the letter on the back of the
faceplate to locate the appropriate faceplate.
N- Nissan/Infiniti/Mercury trim
M - Mitsubishi trim
S- Subaru trim
T - Toyota/Lexus
