APPLICATIONS
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2014 METRA ELECTRONICS CORPORATION
REV. 2/27/2014 INST95-7805CH
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
Table of Contents
INSTALLATION INSTRUCTIONS FOR PART 95-7805CH
• ISO Double DIN radio provision
• Painted charcoal gray
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-1729 Honda harness 2008-up • 70-1730 Honda amp interface harness 2008-up
Antenna Adapter: • 40-HD10 Acura/Honda antenna adapter 2005-up into car
• 40-HD12 Acura/Honda antenna adapter 2005-up into car
• Panel removal tool • Phillips screwdriver
• Socket wrench
TOOLS REQUIRED
Acura TSX 2009-up
95-7805CH
Dash Disassembly
– Acura TSX 2009-up ...........................................2-5
Kit Assembly
– ISO Double DIN radio provision ............................. 6
• A) Radio Housing • B) Radio Housing Brackets • C) (4) #8 x 3/8” Pan-head Phillips screws
• D) (2) #8 x 1/2” Truss-head Phillips screws
A
B
D
C
95-7805CH
1. Unclip and remove the trim
panel above the glove box on the
passenger side of the dash.
(Figure A)
2. Unclip and remove the driver and
passenger side trim panels from
the console. (Figure B and C)
Continued on next page
Dash Disassembly
(Figure A) (Figure B)
(Figure C)
2
