Side 1/8
METRA. The World’s best kits.
™
metraonline.com
© COPYRIGHT 2016 METRA ELECTRONICS CORPORATION
REV. 1/6/2016 INST99-5831
CAUTION: Metra recommends disconnecting the negative battery
terminal before beginning any installation, unless the vehicle
manufacturer recommends against so. Please check with your
local Dealership for more information. All accessories, switches,
climate controls panels, and especially air bag indicator lights
must be connected before reconnecting the battery or cycling
the ignition. Also, do not remove the factory radio with the key
in the on position, or the vehicle running. It would be best to
remove the key from the ignition and then wait a few seconds
before removing the factory radio.
Installation instructions for part 99-5831
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Passenger airbag indicator
• Painted black (99-5831B) or
charcoal gray and black (99-5831G)
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (4) Panel clips • E) (4) #8 x 3/8” Phillips screws
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • XSVI-5524-NAV or AX-ADBOX2 & AX-ADFD02 Antenna Adapter: • 40-EU10
• Panel removal tool • Phillips screwdriver
• T15 Torx driver • T20 Torx driver
TOOLS REQUIRED
Ford Transit Connect 2014-up
(With factory 4.2” display)
99-5831
A
C D
E
B
Dash Disassembly ................................................. 2
Kit Assembly
– ISO DIN radio provision with pocket ...................... 3
– ISO DDIN radio provision ...................................... 3
Table of Contents
NOTE: This installation kit is intended to be used in
conjunction with an AXXESS radio replacement interface.
Models with steering wheel controls will require an
AXXESS radio replacement interface and the AXXESS
ASWC-1 steering wheel control interface for all features
to work properly.
99-5831
2
Dash Disassembly
1. Remove the top panel above the
display. (Figure A)
2. Remove (2) T-15 Torx screws
above the display/radio panel.
(Figure B)
3. Unplug and remove the display/
radio panel. (Figure C)
4. Remove the A/C vents and hazard
switch from the panel and set
aside for kit assembly.
5. Remove (2) T-20 Torx screws
from the top of the radio, and then
unplug and remove from the dash
cavity. (Figure D)
Continue to kit assembly.
(Figure A) (Figure C)
(Figure B) (Figure D)
