Side 1/4
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 9/30/20 INST99-5856B
INSTALLATION INSTRUCTIONS
99-5856B
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Passenger airbag indicator
• Painted scratch resistant matte black
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Sub-dash bracket • D) ISO-DIN pocket • E) (4) Panel clips • F) (4) #8 x 3/8” Phillips screws • G) Upper pocket
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• T-15 Torx driver • T-20 Torx driver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly
–ISO DIN radio provision with pocket ..................3
–ISO DDIN radio provision .....................................3
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-5524
Antenna Adapter: 40-EU10
Ford Transit Connect (with AM/FM only radio)
2014-2018
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
A B C D
G
E
F
2
386.257.1187
|
MetraOnline.com
DASH DISASSEMBLY
1. Remove the top panel above the
storage pocket. (Figure A)
2. Remove (2) T-15 Torx screws above the
display/radio panel. (Figure B)
3. Unplug and remove the display/radio
panel. (Figure C)
4. Remove the A/C vents and hazard switch
from the panel and set aside for kit
assembly.
5. Remove (4) T-20 Torx screws and remove
the shaded factory sub-dash bracket.
(Figure D)
Continue to Kit Assembly
(Figure A) (Figure C)
(Figure B) (Figure D)
