KIT COMPONENTS
99-3105
INSTALLATION
INSTRUCTIONS
APPLICATIONS
CAR PAGE
SATURN
(All models) 1995-99...............................................1-2
TOOLS REQUIRED
Socket wrench
Phillips screwdriver
KIT FEATURES
DIN head unit
provisions
Pocket (holds 2
jewel cases)
Radio
Housing
(2) Captive Studs
(2) Pal Nuts
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2001 METRA ELECTRONICS CORPORATION
rev. 290601
2
1
ALL VEHICLES
Disconnect the negative battery terminal to prevent an accidental short circuit. Remove (2)
pop-clips from the sides of the radio trim bezel. Unclip the radio trim bezel, disconnect the
switch wiring and remove the bezel. Remove (2) 7mm hex-head screws securing the top of
the factory head unit and disconnect the wiring.
Mount the Radio Housing to the sub-dash with (2) 7mm hex-head screws previously removed
in step #1.
1
2
5
4
Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adaptor and making
connections as shown. (Isolate and
individually tape off the ends of any
unused wires to prevent electrical short
circuit).
A
B
C
D
A) Strip wire ends back ½"
B) Twist ends together
C) Solder
D) Tape
3
Reach through the Radio Housing and mount
the lower Housing tabs to the sub-dash with (2)
Captive Studs and (2) Pal Nuts supplied.
Slide the DIN cage into the kit and secure by bending the metal locking tabs down. Slide the
aftermarket head unit into the cage until secure. Re-connect the battery terminal and test the
unit for proper operation.
