Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 11/19/18 INST99-7393B
INSTALLATION INSTRUCTIONS
99-7393B
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8” Phillips screws
A B C D
Hyundai Accent 2018 up*
KIT FEATURES
• ISO DIN radio provision with pocket
• Painted matte black
*Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................2
Kit Assembly ..........................................................3
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring harness: Please visit metraonline.com
for wiring harness options
Antenna adapter: 40-KI11
1.800.221.0932
|
MetraOnline.com
2
DASH DISASSEMBLY KIT PREPARATION
1. Unclip and remove the a/c vent trim
panel surrounding the radio. (Figure A)
2. Remove (4) Phillips screws securing the
radio. Slide the radio out, then unplug
and remove the radio. (Figure B)
Continue to Kit Preparation
(Figure B) (Figure B)
(Figure A) (Figure A)
From the factory a/c vent trim panel:
1. Unclip and remove the a/c vents.
2. Remove just (4) panel clips. (Figure A)
To the 99-7393B radio trim panel:
1. Clip in the factory a/c vents. (Figure B)
2. Attach the factory (4) panel clips.
(Figure B)
Continue to Kit Assembly
