Operating and installation instructions

Rangehood

To prevent the risk of accidents or damage to the appliance, it is

essential to read these instructions before it is installed and used for

the first time.

en-AU, NZ M.-Nr. 11467730

Contents

Warning and Safety instructions.......................................................................... 3

Caring for the environment ................................................................................ 12

Description of the functions............................................................................... 13

Guide to the appliance........................................................................................ 14

Operation.............................................................................................................. 16

Switching the fan on.............................................................................................. 16

Selecting a power setting...................................................................................... 16

Run-on time........................................................................................................... 16

Switching the fan off ............................................................................................. 16

Switching the cooktop lighting on/off ................................................................... 16

Power management .............................................................................................. 16

Switching Power management on/off .............................................................. 17

Safety switch-off ................................................................................................... 17

Energy saving tips ............................................................................................... 18

Cleaning and care ............................................................................................... 19

Housing ................................................................................................................. 19

Grease filters ......................................................................................................... 20

NoSmell active charcoal filters .............................................................................. 22

Disposing of the charcoal filters ....................................................................... 22

Changing a lamp ................................................................................................... 23

Installation............................................................................................................ 24

Before installation.................................................................................................. 24

Installation materials.............................................................................................. 24

Appliance dimensions ........................................................................................... 26

Safety distance (S) ................................................................................................ 27

Installation recommendations ............................................................................... 28

Uneven installation surfaces ................................................................................. 28

Connection for air extraction................................................................................. 29

Silencer............................................................................................................. 30

Electrical connection ............................................................................................. 31

Service.................................................................................................................. 32

Contact in case of fault ......................................................................................... 32

Position of the data plate ...................................................................................... 32

Warranty ................................................................................................................ 32

Technical data...................................................................................................... 33

Warning and Safety instructions

This rangehood complies with all relevant local and national safety

requirements. However, inappropriate use can lead to personal

injury and damage to property.

Read the operating and installation instructions carefully before

using the rangehood. They contain important information on the

safety, installation, use and maintenance of the appliance. This

prevents both personal injury and damage to the rangehood.

In accordance with standard IEC 60335-1, Miele expressly and

strongly advises that you read and follow the instructions in

“Installation” and in the “Warning and Safety instructions”.

Miele cannot be held liable for injury or damage caused by non-

compliance with these instructions.

Keep these instructions in a safe place and pass them on to any

future owner.

Correct application

 This rangehood is designed for domestic use and for use in similar

environments by guests in hotel or motel rooms, bed & breakfasts

and other typical living quarters. This does not include common/

shared facilities or commercial facilities within hotels, motels or bed

& breakfasts.

 The appliance is not suitable for outdoor use.

 It must only be used to extract vapours and remove odours from

cooking.

Any other usage is at the owner's risk. Miele cannot be held liable for

damage resulting from incorrect or improper use or operation.

 The rangehood cannot be used to ventilate the installation room in

recirculation mode above a gas cooktop. Please seek the advice of a

qualified gas fitter for more information if necessary.

Produkspesifikasjoner

Merke:	Miele
Kategori:	eksoshette
Modell:	DA 2390
Innebygd skjerm:	Nei
Vekt:	13000 g
Bredde:	884 mm
Dybde:	297 mm
Høyde:	63 mm
Årlig energiforbruk:	55.3 kWh
Støynivå:	52 dB
Støynivå (lav hastighet):	47 dB
Type fettfilter:	Rustfritt stål
Høyde (min):	450 mm
Antall filtre:	2 stykker
Støynivå (resirkulasjonsmodus):	54 dB
Støynivå (intensiv hastighet):	64 dB
AC-inngangsspenning:	230 V
AC-inngangsfrekvens:	50 Hz
Kabellengde:	1.5 m
Produktfarge:	Rustfritt stål
Kontrolltype:	Berøringskontroll
Modell/Type:	Innebygget
Antall pærer:	4 ampuller
Kroppsmateriale:	Rustfritt stål
Strøm:	10 A
Belysning:	500 lx
Type utvinning:	Ducted/Resirkulerende
Motoreffekt:	220 W
Maksimal utvinningskraft:	600 m³/t
Intensiv hastighet:	Ja
Antall hastighetsnivåer:	3
Lyspæretype:	LED
Lampestyrke:	3 W
Fluid dynamisk effektivitet klasse:	A
Belysning efiktivitets klasse:	A
Fettfiltrering effektivitetsklasse:	A
Støynivå (høy hastighet):	52 dB
Diameter på avtrekkstilkobling:	150 mm
Støynivå (medium hastighet):	48 dB
Maksimum resirkulasjonskraft:	500 m³/t
Støynivå (boost modus):	72 dB
