Side 1/21
Cat. No. / No de cat.
2527-20
M12 FUEL™ HATCHET™ 6" PRUNING SAW
SCIE D'ÉLAGAGE DE 152 mm (6") HATCHET™ DE M12 FUEL™
SIERRA PODADORA DE 152 mm (6") HATCHET™ DE M12 FUEL™
OPERATOR'S MANUAL
MANUEL de L'UTILISATEUR
MANUAL del OPERADOR
WARNING To reduce the risk of injury, user must read and understand operator's manual.
AVERTISSEMENT An de réduire le risque de blessures, l'utilisateur doit lire et bien
comprendre le manuel.
ADVERTENCIA Para reducir el riesgo de lesiones, el usuario debe leer y entender el manual.
WARNING To reduce the risk of injury, user must read and understand operator's manual.
AVERTISSEMENT An de réduire le risque de blessures, l'utilisateur doit lire et bien
comprendre le manuel.
ADVERTENCIA Para reducir el riesgo de lesiones, el usuario debe leer y entender el manual.
2
3
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING
Read all safety warnings, instruc-
tions, illustrations and specica-
tions provided with this power tool. Failure to
follow all instructions listed below may result in
electric shock, re and/or serious injury. Save all
warnings and instructions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-oper-
ated (cordless) power tool.
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
• Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
• Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
•
Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
• Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
• Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock.
• Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
• When operating a power tool outdoors, use an exten-
sion cord suitable for outdoor use. Use of a cord suit-
able for outdoor use reduces the risk of electric shock.
• If operating a power tool in a damp location is
unavoidable, use a ground fault circuit interrupter
(GFCI) protected supply. Use of an GFCI reduces
the risk of electric shock.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
• Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non-skid safety shoes, hard hat or hearing
protection used for appropriate conditions will reduce
personal injuries.
• Prevent unintentional starting. Ensure the switch
is in the o-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your nger on the
switch or energizing power tools that have the switch
on invites accidents.
• Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a ro-
tating part of the power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
• Dress properly. Do not wear loose clothing or
jewelry. Keep your hair and clothing away from
moving parts. Loose clothes, jewelry or long hair can
be caught in moving parts.
• If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
• Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct power tool
for your application. The correct power tool will do the
job better and safer at the rate for which it was designed.
• Do not use the power tool if the switch does not turn
it on and o. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
• Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Pow-
er tools are dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may aect
the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
dierent from those intended could result in a hazardous
situation.
• Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
BATTERY TOOL USE AND CARE
• Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used
with another battery pack.
• Use power tools only with specically designated
battery packs. Use of any other battery packs may
create a risk of injury and re.
• When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together may
cause burns or a re.
• Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact acci-
dentally occurs, ush with water. If liquid contacts
eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
• Do not use a battery pack or tool that is damaged or
modied. Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion or
risk of injury.
• Do not expose a battery pack or tool to re or exces-
sive temperature. Exposure to re or temperature
above 265°F (130°C) may cause explosion.
• Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specied in the instructions. Charging im-
properly or at temperatures outside the specied range
may damage the battery and increase the risk of re.
SERVICE
• Have your power tool serviced by a qualied repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
• Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
SPECIFIC SAFETY RULES FOR
HATCHET PRUNING SAW
General pruning saw safety warnings:
• Keep all parts of the body away from the saw chain
when the pruning saw is operating. Before you
start the pruning saw, make sure the saw chain
is not contacting anything. A moment of inattention
while operating pruning saws may cause entangle-
ment of your clothing or body with the saw chain.
• Hold the pruning saw with your right hand on the
trigger handle and your left hand on the body
grip. Holding the pruning saw with a reversed hand
conguration increases the risk of personal injury.
• Hold the pruning saw by insulated gripping sur-
faces only, because the saw chain may contact
hidden wiring. Saw chains contacting a "live" wire
may make exposed metal parts of the pruning saw
"live" and could give the operator an electric shock.
• Wear eye protection. Further protective equipment
for hearing, head, hands, legs and feet is recom-
mended. Adequate protective equipment will reduce
personal injury from ying debris or accidental contact
with the saw chain.
• Always keep proper footing and operate the prun-
ing saw only when standing on xed, secure and
level surface. Slippery or unstable surfaces may
cause a loss of balance or control of the pruning saw.
• Do not operate a pruning saw in a tree, on a lad-
der, rooftop, or scaold unless properly trained.
To avoid death or serious injury, operator must be
trained in safe climbing techniques and in the use of
all appropriate safety equipment.
• When cutting a limb that is under tension be alert
for spring back. When the tension in the wood bres
is released the spring loaded limb may strike the
operator and/or throw the pruning saw out of control.
• Use extreme caution when cutting brush and sap-
lings. The slender material may catch the saw chain
and be whipped toward you or pull you o balance.
• Carry the pruning saw away from your body and
with your nger o of the trigger. When trans-
porting or storing the pruning saw always t the
scabbard. Proper handling of the pruning saw will
reduce the likelihood of accidental contact with the
moving saw chain.
• Follow instructions for lubricating, chain tension-
ing and changing the bar and chain. Improperly
tensioned or lubricated chain may either break or
increase the chance for kickback.
• Cut wood only. Do not use pruning saw for pur-
poses not intended. For example: do not use
pruning saw for cutting metal, plastic, masonry
or non-wood building materials. Use of the pruning
saw for operations dierent than intended could result
in a hazardous situation.
• Do not attempt to fell a tree until you have an
understanding of the risks and how to avoid
them. Serious injury could occur to the operator or
bystanders while felling a tree.
Causes and operator prevention of kickback:
Kickback may occur when the nose or tip of the guide
bar touches an object, or when the wood closes in and
pinches the saw chain in the cut.
Tip contact in some cases may cause a sudden reverse
reaction, kicking the guide bar up and back towards
the operator.
Pinching the saw chain along the top of the guide bar may
push the guide bar rapidly back towards the operator.
Either of these reactions may cause you to lose con-
trol of the saw which could result in serious personal
injury. Do not rely exclusively upon the safety devices
built into your saw. As a pruning saw user, you should
take several steps to keep your cutting jobs free from
accident or injury.
Kickback is the result of pruning saw misuse and/or in-
correct operating procedures or conditions and can be
avoided by taking proper precautions as given below:
• Maintain a rm grip on the pruning saw and posi-
tion your body and arm(s) to allow you to resist
kickback forces. Kickback forces can be controlled
by the operator, if proper precautions are taken. Do
not let go of the pruning saw.
• Do not overreach and do not cut above shoulder
height. This helps prevent unintended tip contact
and enables better control of the pruning saw in
unexpected situations.
• Make sure that the area in which you are cutting
is free from obstructions. Do not let the nose of the
guide bar contact a log, branch, fence, or any other
obstruction that could be hit while you are operating
the saw.
• Always cut with the unit running at full speed.
Fully squeeze the throttle trigger and maintain a
steady cutting speed.
• Only use replacement guide bars and saw chains
specied by the manufacturer. Incorrect replace-
ment guide bars and saw chains may cause chain
breakage and/or kickback.
• Follow the manufacturer’s sharpening and main-
tenance instructions for the saw chain. Decreas-
ing the depth gauge height can lead to increased
kickback.
• Follow all instructions when clearing jammed
material, storing or servicing the pruning saw.
Make sure the switch is o and the battery pack
is removed. Unexpected actuation of the pruning
saw while clearing jammed material or servicing may
result in serious personal injury.
Other Pruning Saw Safety Rules
• Do not start cutting until you have a clear work area,
secure footing, and a planned retreat path from the
falling workpiece. Cluttered areas invite accidents.
• Keep ALL children, bystanders, visitors, and ani-
mals out of the work area while starting or cutting
with the pruning saw.
4
5
• Store pruning saw when not in use. Pruning saw
should be stored in a dry and high or locked area out
of the reach of children. When storing pruning saw
place the cover on the bar and chain.
• Battery operated units do not have to be plugged
into an electrical outlet; therefore, they are always
in operating condition. Be aware of possible haz-
ards even when unit is not operating.
• Save these instructions. Refer to them frequently
and use them to instruct others who may use this
product. If you loan someone this product, loan them
these instructions also.
• After each use, clean the machine with a soft dry
cloth. Remove any chips, dirt and debris in the
battery bay.
• Follow the manufacturer’s sharpening and main-
tenance instructions for the saw chain. Decreas-
ing the depth gauge height can lead to increased
kickback.
• Keep handles dry, clean, and free from oil and
grease. Greasy, oily handles are slippery causing
loss of control.
• Always use common sense and be cautious when
using tools. It is not possible to anticipate every
situation that could result in a dangerous outcome.
Do not use this tool if you do not understand these
operating instructions or you feel the work is beyond
your capability; contact Milwaukee Tool or a trained
professional for additional information or training.
• Maintain labels and nameplates. These carry
important information. If unreadable or missing, contact
a MILWAUKEE service facility for a free replacement.
•
WARNING
Some dust created by power sanding,
sawing, grinding, drilling, and other
construction activities contains chemicals known to
cause cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• lead from lead-based paint
• crystalline silica from bricks and cement and other
masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to
lter out microscopic particles.
SPECIFICATIONS
Cat. No. ..................................................... 2527-20
Volts.............................................................. 12 DC
Battery Type .................................................M12™
Charger Type................................................M12™
RPM ................................................................2,650
Chain Speed ............................................984 ft/min
Bar Length ........................................................... 6"
Cutting Capacity ............................................... 5.5"
Chain Oil Tank Capacity ................................1.7 oz
Replacement Bar .................................. 49-16-2733
Chain Gauge ................................................ 0.043"
Replacement Chain .............................. 49-16-2732
Chain Type ........................................ Low kickback
Chain Pitch .....................................3/8" Low prole
Chain Teeth .........................................................28
Recommended Ambient
Operating Temperature ......................0°F to 125°F
FUNCTIONAL DESCRIPTION
1
2
3
7
8
9
10
12
11
1. Trigger handle
2. Variable speed trigger
3. Lock-o button
4. Fuel battery indicator
5. Body grip
6. Knuckle guard
7. Chain cover
8. Saw chain
9. Guide bar
10. Scabbard
11. Chain tensioning screw
12. Guide bar nut
13. Oil cap
14. Oil reservoir
6
4
5
13
14
ASSEMBLY
WARNING
Recharge only with the charger
specied for the battery. For spe-
cic charging instructions, read the operator’s
manual supplied with your charger and battery.
Removing/Inserting the Battery
To remove the battery, push in the release buttons
and pull the battery pack away from the tool.
WARNING
Always remove battery pack before
changing or removing accessories.
To insert the battery, slide the pack into the body
of the tool. Make sure it latches securely into place.
WARNING
Only use accessories specically
recommended for this tool. Others
may be hazardous.
Replacing/Adjusting the
Saw Chain and Bar
WARNING
Always remove battery pack before
changing or removing accessories.
CAUTION
Chain is sharp. Always wear protec-
tive gloves when handling the
chain.
Use Low Kickback Saw Chains - The rakers (depth
gauges) ahead of each cutter can minimize the force
of a kickback reaction by preventing the cutters from
digging in too deeply at the kickback zone. Only
use replacement chain that is equivalent to original
chain or has been certied as low kickback chain
per ANSI B175.1.
• Dress Properly - Wear snug tting clothing. Always
wear heavy, long pants, long sleeves, overalls, jeans
or chaps made of cut resistant material or ones that
contain cut resistant inserts. Wear non-slip safety
footwear. Wear non-slip heavy duty gloves to improve
your grip and to protect your hands. Do not wear
jewelry, short pants, sandals, or go barefoot. Do not
wear loose tting clothing, which could be drawn into
the motor or catch the chain or underbrush. Secure
hair so it is above shoulder level.
• Heavy protective clothing may increase operator
fatigue, which could lead to heat stroke. During
weather that is hot and humid, heavy work should be
scheduled for early morning or late afternoon hours
when temperatures are cooler.
• Always wear proper eye protection with side
shields, marked to comply with ANSI Z87.1 when
operating the pruning saw.
• Always be aware of what you are doing when
using the pruning saw. Use common sense. Do
not operate the pruning saw when you are tired, ill, or
under the inuence of alcohol, drugs, or medication.
• Keep all parts of your body away from the saw
chain when the unit is running.
• Never let anyone use your pruning saw who has
not received adequate instructions in its proper
use. This applies to rentals as well as privately owned
saws.
• Before you start the unit, make sure the saw chain
is not contacting any object.
• Stop the pruning saw before setting it down.
• Maintain the unit with care. Keep the cutting edge
sharp and clean for best performance and to reduce
the risk of injury. Follow instructions for lubricating
and changing accessories.
• Maintain a rm grip on the recommended grasp-
ing surfaces. If an operation cannot be performed
safely with two hands on the saw, USE EXTREME
CAUTION.
• During operations where it is necessary to use
one hand, such as to steady or control the work-
piece/branch, guide workpiece away from you, or
provide better visibility to the work area:
• Keep free hand clear of the chain and out of the
cutting path.
• Maintain a rm grip on the branch being cut to avoid
"skating" or "bouncing" of the saw.
• Never cut above shoulder height.
• Do not cross arms or overreach.
• Always cut away from yourself.
• Avoid excess exing or tension on the branch be-
ing cut.
• Do not operate a pruning saw that is damaged, im-
properly adjusted, or not completely and securely
assembled. Chain should slow to a stop when the
switch trigger is released. If the chain continues to
turn after the switch trigger has been released, have
the unit serviced by an authorized service center.
• Do not force the pruning saw. The job can be
performed better and safer at the rate for which it
was intended.
• Always use the right product for your application.
The pruning saw should be used for cutting wood only.
Never use the pruning saw to cut plastic, masonry or
non-wood building materials.
• Use extreme caution when cutting thin branches,
vines or small underbrush. The slender material
may catch the saw chain and be whipped toward you
or pull you o balance. We recommend using hedge
trimmers or brush cutters for these operations.
SYMBOLOGY
Volts
Direct Current
No Load Revolutions per Minute (RPM)
Read operator’s manual
Always wear eye protection and use
proper personal protective equipment.
Wear non-slip safety footwear
Wear protective gloves
Keep bystanders at least 50' away
during use.
Do not expose to rain or use in
damp locations.
Use EXTREME CAUTION during
one-handed operations.
Use pruning saw two-handed
Avoid contact with bar tip
DANGER
Beware of kickback.
Chain Oil Reservoir
Chain Direction
Chain Tension Adjustment
C
US
UL Listing for Canada and U.S.
Produkspesifikasjoner
| Merke: | Milwaukee |
| Kategori: | sag |
| Modell: | M12 Fuel Hatchet 2527-20 |
Trenger du hjelp?
Hvis du trenger hjelp med Milwaukee M12 Fuel Hatchet 2527-20 still et spørsmål nedenfor, og andre brukere vil svare deg
sag Milwaukee Manualer
15 August 2025
15 August 2025
14 August 2025
14 August 2025
14 August 2025
14 August 2025
14 August 2025
14 August 2025
14 August 2025
14 August 2025
sag Manualer
- sag DeWalt
- sag AEG
- sag Rikon
- sag Festo
- sag Flex
- sag Makita
- sag Einhell
- sag Fuxtec
- sag Metabo
- sag Worx
- sag Stanley
- sag Ozito
- sag Fieldmann
- sag Graphite
- sag Sun Joe
- sag Kress
- sag Stiga
- sag Scheppach
- sag Festool
- sag Troy-Bilt
Nyeste sag Manualer
15 August 2025
11 August 2025
11 August 2025
11 August 2025
9 August 2025
9 August 2025
9 August 2025
9 August 2025
8 August 2025
7 August 2025
