USER’S GUIDE
MBP33, MBP33/2, MBP33/3, MBP33/4,
MBP33P, MBP33P/2, MBP33P/3, MBP33P/4
BABY MONITOR
USER’S GUIDE
The features described in user's guide are subject to
modifications without prior notice.
This User's Guide provides you with all the information you need
to get the most from your product.
Before you can use the baby monitor, we recommend you insert
and fully charge the battery in the parent unit, so that it continues
to work if you disconnect it from the power supply to carry it to
another location. Please read the Safety Instructions on page 6
before you install the units.
Got everything?
• 1 x Parent unit
• 1 x Baby unit
• 1 x Rechargeable Ni-MH battery pack for the parent unit
• 1 x Power adapter for the Parent unit
• 1 x Power adapter for the Baby unit
Welcome...
to your new Motorola Baby Monitor!
Thank you for purchasing the MBP33, MBP33/2, MBP33/3,
MBP33/4, MBP33P, MBP33P/2, MBP33P/3, MBP33P/4. Now you
can see and hear your baby sleeping in another room or you can
monitor your older children in their playroom.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola product, you will need to provide
a copy of your dated sales receipt to confirm warranty status.
Registration is not required for warranty coverage.
For product related questions, please call:
US and Canada 1-888-331-3383
On the Web: www.motorola.com
1. Display (LCD screen)
2. Vol + Key
)
Normal Mode: Vol Up
Menu Mode: Up
3. Vol - Key
(
Normal Mode: Vol Down
Menu Mode: Down
4. Brightness + Key
]
Normal Mode: Brightness up
Menu Mode: Right
5. Brightness - Key
[
Normal Mode: Brightness down
Menu Mode: Left
6. Menu Key
M
Press to open the Menu options
7. OK Key O
8. Video ON/OFF Key
V
Press to turn OFF the LCD
display
Press again to turn ON the
LCD display
9. Talk Key
T
Press and hold to speak to
your baby
10. Power Adapter / Battery LED
BLUE when mains adapter
power on.
RED when battery low.
11. Unit ON/OFF LED (Green)
12. Audio Level LED (Green,
Orange, Red, Red)
13. Microphone
14. Power Key
P
Press and Hold to turn the unit
ON/OFF
15. Antenna
Lift the antenna for optimal
reception
16. Battery cover
17. Stand
18. Speaker
19. USB connector
Connection to AV output
* AV Cable (Optional accessory,
to be purchased separately)
20. Power Adapter connector
Overview of the Parent Unit
18
15
11
14
13
16
17
19
20
6
7
8
9
2
3
4
5
10 12
1
Parent unit menu icons
1
Signal Level (5 Levels)
N
Night Vision Mode (Screen changes to Black/White)
T
Talk Mode
Battery Level Control (4 Levels)
B
Produkspesifikasjoner
| Merke: | Motorola |
| Kategori: | baby monitor |
| Modell: | MBP33 |
| LED-indikatorer: | Ja |
| Strømkildetype: | AC, Battery |
| LED-type: | IR |
| Pakkevekt: | 920 g |
| Innebygde høyttalere: | Ja |
| Volumkontroll: | Digitalt |
| Digital zoom: | 2 x |
| Innebygd mikrofon: | Ja |
| Nattmodus: | Ja |
| USB-tilkobling: | Ja |
| Maksimal rekkevidde: | 300 m |
| AC-inngangsspenning: | 100-240 V |
| AC-inngangsfrekvens: | 50 - 60 Hz |
| Batteriteknologi: | Nikkelmetallhydrid (NiMH) |
| Batteritype: | AAA |
| Senderbredde: | 90 mm |
| Senderdybde: | 81 mm |
| Senderhøyde: | 95 mm |
| Mottakervekt: | 160 g |
| Temperatursensor: | Ja |
| Skjermoppløsning: | 320 x 240 piksler |
| Mottakerbredde: | 25 mm |
| Mottakerhøyde: | 80 mm |
| Sensortype: | CMOS |
| Produktfarge: | Black, White |
| Pakkedybde: | 256 mm |
| Pakkehøyde: | 126 mm |
| Pakkebredde: | 217 mm |
| Antall støttede batterier: | 3 |
| Skjermdiagonal: | 2.8 " |
| Batterispenning: | 1.2 V |
| Innebygd kortleser: | Nei |
| Indikator for lavt batterinivå: | Ja |
| Videoopptaksgrensesnitt: | FHSS |
| Batterier medfølger: | Ja |
| Display antall farger: | 16.78 million farger |
| AC-adapter bunt: | Ja |
| Strøm-LED: | Ja |
| Frekvensbånd og driftskanaler: | 2.4 - 2.48 GHz |
| Fast fokalobjektiv: | 2.5 mm |
| DC inngående spenning: | 6 V |
| Lysstyrkejustering: | Ja |
| Sendervekt: | 140 g |
| Antall lysende LED: | 8 |
| Mottakerdybde: | 120 mm |
| Indikator for batteriopplading: | Ja |
| Smarttelefon support: | Nei |
| Vuggesanger: | Ja |
| Antall vuggesanger: | 5 |
| Mottakerstrøm: | 0.5 A |
| Senderstrøm: | 1 A |
| Digital zoom-kapasitet: | Ja |
