Mtx Audio RT1000-1D Bruksanvisning
Les nedenfor 📖 manual på norsk for Mtx Audio RT1000-1D (48 sider) i kategorien Mottaker. Denne guiden var nyttig for 3 personer og ble vurdert med 4.4 stjerner i gjennomsnitt av 2 brukere
Side 1/48
RT1000.1D
Mono-Block Class-D Power Amplifier
1000W
RMS
Designed by MTX in the USA
www.mtxaudio.com
www.mtxaudio.eu
SPEAKER
+ +
- -
GNDREM+12V
POWER
INPUT OUTPUT
GAIN
LP
X-OVER
SUB
SONIC
EBC Port
R
R
LL
40Hz 180Hz6V 0,1V OFF 50Hz
www.mtxaudio.com - www.mtxaudio.eu
Introduction
Thank you for purchasing an MTX Audio Hi-Performance amplifier. Proper installation matched with MTX speak-
ers and subwoofers provide superior sound and performance for endless hours of waking the neighbors, slam-
min' your friends or flat out stomping wanna-be players. Congrats and enjoy the ultimate audio experience with
MTX !
Specifications
• 1-Channel Mono Block Class-D Power Amplier
• CEA2006 certied Power Output :
- 1000 watts RMS x 1-channel at 2Ω and THD+N ≤1%
- 600 watts RMS x 1-channel at 4Ω and THD+N ≤1%
• Crossover :
- Low pass 12dB/oct variable from 40Hz to 400Hz
- Subsonic lter 12dB/oct variable from 0 to 50Hz
• Signal-to-Noise Ratio (1 watt) : > 80dB
• THD+Noise (Distortion) (1 watt) : ≤ 1%
• Frequency Response (±1dB) : 20Hz-30000Hz
• Maximum Input Signal : 6V
• Maximum Sensitivity : 100mV
• Dimensions : 456mm x 180mm x 55mm
• EBC (External Bass Control) remote included
Control Panel
Owner’s Manual - RT1000.1D
Produkspesifikasjoner
| Merke: | Mtx Audio |
| Kategori: | Mottaker |
| Modell: | RT1000-1D |
