感谢您选购尼康产品。该
AF
鱼眼尼克尔
16
mm f/
2
.
8
D
镜头可为照相机机身提供距离
信息以进行即时
3
D
矩阵测光或
3
D
多传感器均衡补充闪光的闪光控制。它具有
180
°
对角线视角以获取真实的鱼眼效果，但是与其他尼克尔鱼眼镜头不同，它被设计为一
款能够拍摄出充满整个画面图像的镜头，其效果类似于常规镜头。除了供平常使用的
L
37
C UV
滤镜外，它还随附
O
56
、
A
2
和
B
2
镜后卡口型滤镜（因具备卡口，滤镜可快
速安装和取下）。在使用本产品前，请仔细阅读这些指南和照相机说明书，以便您在现
在和今后都能充分利用您的镜头。
使用产品前请仔细阅读本使用说明书。
安全须知
请在使用前仔细阅读“安全须知”，并以正确的方法使用。本“安全须知”中记载了重
要的内容，可使您能够安全、正确地使用产品，并预防对您或他人造成人身伤害或财
产损失。请在阅读之后妥善保管，以便本产品的所有使用者可以随时查阅。
有关指示
本节中标注的指示和含义如下。
A
警告
表示若不遵守该项指示或操作不当，则有可能造成人员死亡或负重伤的内容。
A
注意
表示若不遵守该项指示或操作不当，则有可能造成人员伤害、以及有可能
造成物品损害的内容。
本节使用以下图示和符号对必须遵守的内容作分类和说明。
图示和符号的实例
I
L
符号表示唤起注意（包括警告）的内容。
在图示中或图示附近标有具体的注意内容（左图之例为当心触电）。
E
F
符号表示禁止（不允许进行的）的行为。
在图示中或图示附近标有具体的禁止内容（左图之例为禁止拆解）。
K
D
符号表示强制执行（必需进行）的行为。
在图示中或图示附近标有具体的强制执行内容（左图之例为取出电池）。
A
警告
E
禁止拆解
切勿自行拆解、修理或改装。
否则将会造成触电、发生故障并导致受伤。
G
C
禁止触碰
立即委托修理
当产品由于跌落而破损使得内部外露时，切勿用手触碰外露部分。
否则将会造成触电、或由于破损部分而导致受伤。取出照相机电
池，并委托经销商或尼康授权的维修服务中心进行修理。
K
C
取出电池
立即委托修理
当发现产品变热、冒烟或发出焦味等异常时，请立刻取出照相机电池。
若在此情况下继续使用，将会导致火灾或灼伤。取出电池时，请小心勿
被烫伤。取出电池，并委托经销商或尼康授权的维修服务中心进行修理。
J
禁止接触水
切勿浸入水中或接触到水，或被雨水淋湿。
否则将会导致起火或触电。
F
禁止使用
切勿在有可能起火、爆炸的场所使用。
在有丙烷气、汽油、可燃性
喷雾剂等易燃性气体、粉尘的场所使用产品，将会导致爆炸或火灾。
F
禁止观看
切勿用镜头或照相机直接观看太阳或强光。
否则将会导致失明或视觉损伤。
A
注意
I
当心触电 切勿用湿手触碰。
否则将有可能导致触电。
F
禁止放置 切勿在婴幼儿伸手可及之处保管产品。
否则将有可能导致受伤。
A
小心使用
进行逆光拍摄时，务必使太阳充分偏离视角。
阳光会在照相机内部
聚焦，并有可能导致火灾。
太阳偏离视角的距离微小时，也有可能会导致火灾。
A
妥善保存
不使用时请盖上镜头盖，或保存在没有阳光照射处。
阳光会聚焦，并有可能导致火灾。
A
小心移动
进行移动时，切勿将照相机或镜头安装在三脚架上。
摔倒、碰撞时将有可能导致受伤。
F
禁止放置
切勿放置于封闭的车辆中、直射阳光下或其它异常高温之处。
否则将对内部零件造成不良影响，并导致火灾。
■
镜头部件
q
镜头镜筒
w
最小光圈锁定杆
e
镜头遮光罩
r
对焦距离指示
t
焦距
/
光圈
/
镜头安装标记
y
红外线补偿标记（白色）
u
对焦距离指示窗口
i
对焦环
o
光圈刻度
!0
光圈传递杆
!1
光圈直读刻度
!2
CPU
接点
!3
景深指示
!4
测光耦合脊
!5
光圈环
■
注意事项
•
请保持
CPU
镜头接点清洁并小心不要损坏
CPU
接点。
•
不要将以下配件直接安装至本镜头：
PK-
1
或
PK-
11
自动延伸环、
K
1
环或
BR-
4
自动环
（
PK-
11
A
和
BR-
8
可分别代替
PK-
11
和
BR-
4
使用）。若不遵守此注意事项，可能会导致
损坏本镜头的
CPU
接点或其他部件。其他镜头配件可能与照相机不兼容；请务必在
使用前先查阅照相机的说明书。
•
本镜头无法与用于尼康
F
3
AF
照相机的
DX-
1
取景器一起使用。
■
对焦
自动对焦适用于尼康自动对焦照相机 ；若要手动对焦，请旋转对焦环直至取景器中的
图像清楚鲜明。
■
对焦屏
“对焦屏”表格中所列照相机支持用于不同镜头或不同情况下的多种对焦屏。表格中所
列对焦屏均适用于本镜头。
当将
B
2
/B
3
、
E
2
/E
3
或
K
2
/K
3
对焦屏用于非此表格中所列照相机时，请分别参考
B
、
E
或
K
列。
对焦屏
照相机
EC-B/
EC-B/
EC-B/
EC-B/EC-B/
EC-E
EC-E
EC-E
EC-EEC-E
A/L
A/L
A/L
A/LA/L
B
B
B
BB
C
C
C
CC
D
D
D
DD
E
E
E
EE
G1
G1
G1
G1G1
G2
G2
G2
G2G2
G3
G3
G3
G3G3
G4
G4
G4
G4G4
H1
H1
H1
H1H1
H2
H2
H2
H2H2
H3
H3
H3
H3H3
H4
H4
H4
H4H4
J
J
J
JJ
K
K
K
KK
P
P
P
PP
M
M
M
MM
R
R
R
RR
T
T
T
TT
U
U
U
UU
F
F
F
FF
F6
F5+ DP-30
F5+ DA-30
(+0.5)
(+0.5)
(+0.5)
(-1)
(+0.5)
F4+ DP-20/
F4+ DA-20
(-1)
(-1)
F3
：
推荐使用。
：
在取景器中可见渐晕（照片不会受到影响）。
：
分屏显示不会提高对焦准确度。
( )
：
括号中的数据是指用于中央重点测光的曝光补偿值。当调整
F
6
的曝光
补偿时，请在自定义设定
b
6
（“对焦屏补偿”）中选择“其他对焦屏”；请
注意，使用
B
或
E
以外的对焦屏时，即使曝光补偿值为
0
，也必须选择
“其他对焦屏”。
F
5
和
F
4
的用户可分别使用自定义设定
18
和对焦屏曝光
补偿拨盘调整曝光补偿；有关详细信息，请参阅照相机的说明书。
空白单元格：
不适用于本镜头。请注意，在放大倍率为
1
:
1
或更高时，
M
型对焦屏仍可
用于显微拍摄和微距拍摄。
■
滤镜
本镜头随附
4
种滤镜：
L
37
C
（
UV
滤镜）、
A
2
、
B
2
和
O
56
。任何时候都必须安装有滤
镜；请根据拍摄环境选择滤镜。由于具备卡口，因此更换这些镜后卡口型滤镜变得轻
而易举。
■
更换滤镜
1
逆时针旋转当前滤镜并将其取下。
2
将替换滤镜安放在镜头上，同时保持其外部边缘的点与镜头卡口安装销旁的导槽
对齐，然后顺时针旋转滤镜。
■
非
TTL
测光
使用镜后（
TTL
）测光时不需要曝光补偿，因为照相机会根据穿过镜头的光线量测定
曝光。当使用不提供
TTL
测光的照相机时，请如下表所示调整曝光。括号中的数据指
的是以
f
档为单位的曝光补偿。
胶卷
滤镜滤光系数（曝光补偿）
名称 类型 日光 白炽灯灯光
黑白
/
彩色
L
37
C
紫外
1 1
仅彩色
A
2
淡琥珀色
1
.
2
(
⁄
)
1
.
2
(
⁄
)
B
2
淡蓝色
1
.
2
(
⁄
)
1
.
2
(
⁄
)
仅黑白
O
56
橙色
3
.
5
(
1
⁄
)
2
(
1
)
■
最小光圈锁定杆（图
A
）
在程序自动或快门优先自动模式下进行拍摄时将光圈锁定为
f/
22
。
1
.
将光圈环旋转至最小光圈设定（
f/
22
）。
2
.
朝光圈环滑动锁定杆，以便锁定杆上的白点与橙点对齐。
若要解除锁定，请按相反方向滑动锁定杆。
■
构图（图
B
）
与常规镜头相比，使用鱼眼镜头构图时需要花费更多的精力和考虑。鱼眼镜头不仅会
由于它的宽视角而容易产生失真，还会将物体挤压进一个受限的区域 ：靠近中央的物
体比边缘的物体显得更大且失真更少。整个场景变得更为深远，空间关系也发生变化，
只需稍微改变照相机的位置即可产生全新的构图。您需特别注意避免不相干的物体
（如三脚架的支脚或拍摄者的手和脚等）出现在画面中。
■
镜头保养
•
用吹气球去除镜头表面的灰尘和浮屑。若要去除污点和指纹，可使用一块滴有少许
乙醇或镜头清洁剂的干净软棉布或镜头清洁纸，以圆周运动方式从里向外进行清洁。
注意不要留下污渍，也不要用手指触碰玻璃。
•
切勿使用涂料稀释剂或苯等有机溶剂清洁镜头。
•
不使用镜头时，请盖上镜头前后盖。
•
保持镜头干燥。内部构造生锈将导致无法挽回的损坏。
•
若在较长时间内不使用镜头，请将其存放在阴凉干燥的地方以防止发霉和生锈。切
不可存放在直射阳光下，也不可与石脑油或樟脑丸一起存放。
•
将镜头放置在过于炎热的地方将会使强化塑料部件受损或变形。
•
运输产品时，请在包装箱内装入足够多的缓冲材料，以减少（避免）由于冲击导致产
品损坏。
■
兼容的配件
•
半软镜头袋
CL-
0715
■
技术规格
焦距
16
mm
最大光圈
f/
2
.
8
镜头结构
5
组
8
片
视角
180
°
对焦距离指示
从
0
.
25
m
至无穷远（∞），以米和英尺为单位
距离信息
输出到照相机
光圈刻度
标准和光圈直读刻度上均为
f/
2
.
8
至
f/
22
光圈
全自动
测光
全开光圈测光
卡口
尼康
F
卡口
滤镜
L
37
C
、
O
56
、
A
2
和
B
2
（镜后卡口型）
尺寸
约
63
mm
（最大直径）×
57
mm
（从照相机镜头卡口边缘开始的距离）；
总体长度约为
68
mm
重量
约
290
g
尼康公司保留可随时更改说明书内载之硬件技术规格的权利，而无须事先通知。
■
关于广角和超广角镜头的注解
下列情况下若使用广角和超广角镜头，自动对焦可能无法达到预期效果：
1
拍摄对象未填满对焦包围中的区域（图
C
）。
若对焦点包含前景和背景两者中的物体，照相机可能对焦于背景，从而使拍摄对象
不清晰。
2
拍摄对象包含很多细节性景物（图
D
）。
照相机可能难以对焦于包含很多细节性景物或缺少对比度的拍摄对象。
在这些情况下，请使用手动对焦，或使用对焦锁定对焦于相同距离的其他拍摄对象后
再重新构图。有关详细信息，请参阅照相机说明书中的“利用自动对焦获取良好拍摄
效果”。
图
A
图
B
图
C
与背景有一段距离的较远人物拍摄
对象
图
D
一片开满鲜花的田地
Sc
使用说明书
随附配件
插入式镜头前盖
镜头后盖
卡口型滤镜（
L
37
C
、
A
2
、
B
2
和
O
56
）
滤镜套
CA-
2
