Nintendo Wii Zapper Bruksanvisning
Les nedenfor 📖 manual på norsk for Nintendo Wii Zapper (6 sider) i kategorien Konsoll. Denne guiden var nyttig for 9 personer og ble vurdert med 4.8 stjerner i gjennomsnitt av 5 brukere
Side 1/6
Configuration 1: Zapper – Nunchuk Attached
Both the Wii Remote and Nunchuk
are attached to the Wii Zapper.
See pages 4-5 for details.
You can use this setup either right
or left handed.
Configuration 2: Zapper – Nunchuk Separate
The Wii Remote is attached to the Wii Zapper
while the Nunchuk is held in your other hand.
See page 6 for details.
You can use this setup either
right or left handed.
2 3
Please review the instruction booklet for the game you are playing for information on which Wii
Zapper configuration to use for that game.
Wii Remote
compartment
B Button
Grip
NOTE: Always hold
the Wii Zapper with
a firm grip.
Nunchuk
compartment
Cable storage compartment
and cover
Nunchuk lock
Wii Remote lock
release
Wii Zapper Components
Wii Zapper Configurations
Please carefully and completely read the Wii™ Operations Manual - System Setup before using this
accessory. This manual contains important health and safety information. Be sure to read the sections on:
• Health and Safety
• Setup of the Wii Remote™
• Setup of the Nunchuk™
• the Wii Console Usage Precautions in the System Setup section
The Wii Zapper must be used with a Wii Remote or with a Wii Remote and Nunchuk (sold separately).
Additionally, you must use a Wii game disc (sold separately) that supports Wii Zapper
game play. Look for this icon on game packaging for games that are designed to be used
with the Wii Zapper.
Unlicensed Accessories: Do not attach unlicensed accessories to the Wii Remote, as the use of unlicensed
accessories may lead to injury to yourself or others and may cause performance issues and/or damage to the
system. Use of any such unlicensed accessories will invalidate your Nintendo product warranty.
TM,
®
and the Wii logo are trademarks of Nintendo. © 2007 Nintendo. All Rights Reserved. Nintendo of Canada Ltd., Authorized User in Canada.
PRINTED IN CHINA
NINTENDO OF AMERICA INC.
P.O. BOX 957, REDMOND, WA
98073-0957 U.S.A.
64559A
NEED HELP WITH INSTALLATION,
MAINTENANCE OR SERVICE?
Nintendo Customer Service
SUPPORT.NINTENDO.COM
or call 1-800-255-3700
BESOIN D’AIDE POUR L’INSTALLATION,
L’ENTRETIEN OU LA RÉPARATION?
Service à la Clientèle de Nintendo
SUPPORT.NINTENDO.COM
ou appelez le
1-800-255-3700
¿
NECESITAS AYUDA DE INSTALACION,
MANTENIMIENTO O SERVICIO?
Servicio al Cliente de Nintendo
SUPPORT.NINTENDO.COM
o llame al 1-800-255-3700
Wii Zapper
Operations Manual
Mode d’emploi – page 9
Manual de Operaciones – página 17
C/RVL–A–ZA–USZ
4
5
Screw
holes
6
7
Make sure that the
Wii Remote is securely
locked in place.
Press
NOTE: If your Wii Remote has the Wii Remote Jacket, remove it before attaching the remote to the
Wii Zapper. Replace the jacket when you remove the remote from the Wii Zapper.
IMPORTANT: Wear the wrist strap and tighten the strap lock for this configuration. Review the Wii
Operations Manual - System Setup for more information on wrist strap usage.
Configuration 2: Zapper – Nunchuk Separate Removing the Wii Remote and Nunchuk
1. Thread the wrist strap cord through the connector hook
on the bottom of the connector plug.
Insert the plug into the External Extension Connector on
the bottom of the Wii Remote.
1. Press and hold the Wii Remote lock release and remove
the Wii Remote from the compartment, bottom end first.
Unplug the connector from the bottom of the remote and
remove the wrist strap cord from the connector hook.
2. Remove the cable storage cover by pressing and sliding it
towards the bottom of the Wii Zapper.
Unwind and remove the cable and replace the cover.
3. Open the Nunchuk lock and remove the Nunchuk from the
compartment.
Replace the Nunchuk lock.
2. Place the remote into the compartment, front end first,
while pressing the Wii Remote lock release.
Let go of the lock release when the remote is fully
inserted into the compartment. The tabs on the lock
should be inserted into the two holes on the bottom of
the remote.
Press
Press
NOTE: If your Wii Remote has the Wii Remote Jacket, remove it before attaching the remote to the
Wii Zapper. Replace the jacket when you remove the remote from the Wii Zapper.
Configuration 1: Zapper – Nunchuk Attached
1. Remove the cable storage cover by pressing and sliding it
towards the bottom of the Wii Zapper.
4. Replace the cable storage cover, feeding the cable through
the slot at the top of the compartment.
5. Thread the wrist strap cord through the connector hook
on the bottom of the connector plug.
Insert the plug into the External Extension Connector on
the bottom of the Wii Remote.
6. Place the remote into the compartment, front end first,
while pressing the Wii Remote lock release.
Let go of the lock release when the remote is fully
inserted into the compartment. The tabs on the lock
should be inserted into the two holes on the bottom of
the remote.
NOTE: Extra cable can be tucked back into the cable
storage compartment.
2. Open the Nunchuk lock. Place the Nunchuk into the
compartment, aligning the projections with the screw
holes on the underside of the Nunchuk.
Close the Nunchuk lock over the base of the Nunchuk.
3. Feed the cable along the underside of the Wii Zapper,
pressing it into the slot.
Wrap the cable around the projections inside the
compartment 3-1/2 times, leaving some extra cable to
connect to the remote.
Make sure that the
Wii Remote is securely
locked in place.
Produkspesifikasjoner
| Merke: | Nintendo |
| Kategori: | Konsoll |
| Modell: | Wii Zapper |
