Side 1/26
User manual
Installation Guide
BX-CTA16 Ultra Short Throw Lens
2
TABLE OF CONTENTS
Safety precautions ........................................................................................................................................................................ 3
Identifying product versions ..................................................................................................................................................... 4
List of components ....................................................................................................................................................................... 5
Required tools ................................................................................................................................................................................. 6
Setting the projector start mode ............................................................................................................................................ 6
Removing the non-UST boresight plate ............................................................................................................................ 8
Installing the UST lens boresight plate (LSM 1) ............................................................................................................ 9
Installing the UST lens pogo pin adapter (LSM 2 ONLY) ...................................................................................... 10
Mounting the UST lens support system.......................................................................................................................... 12
Initially adjusting the boresight screws ............................................................................................................................ 16
Installing the UST lens ............................................................................................................................................................ 17
Adjusting the image position and focus .......................................................................................................................... 19
Adjusting the boresight ............................................................................................................................................................ 21
Finalizing the image adjustment ......................................................................................................................................... 22
Removing the UST lens .......................................................................................................................................................... 23
Installing an non-UST lens .................................................................................................................................................... 24
UST Lens specifications ......................................................................................................................................................... 25
3
Ultra short throw (UST) lens installation
The ultra short throw (UST) lens enables large screen projection from a short distance, which significantly
increases the flexibility of projector installation. This installation guide provides detailed steps on mounting
the UST lens to your projector. Before the installation, please read through this guide in full to ensure the
installation steps are made correctly.
Safety precautions
• Installation and adjustments should be performed by qualified Technicians or authorized service
dealers.
• Make sure the projector is turned off when installing and removing the UST lens.
• Do not look into straight into the projector lens when the projector is operating. The bright light may
cause permanent eye injury.
• Make sure no personnel or object is in the light path of the projector when It is running.
• Do not place the projector on an unstable surface to prevent product damage and personal injury.
• Failure to follow the control, adjustment or operation procedures may cause damage by the exposure
of laser radiation.
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no
representations or warranties with respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of the
manufacturer to notify any person of such revision or changes
Trademarks
Optoma and its logo is a registered trademark of Optoma Corporation. Optoma Europe Ltd is the licensee of
the registered trademark.
