Side 1/2
43REDP
BUILT TO RUN 24 X 7 X 365 CONTINUOUSLY
The ORION PREMIUM WIDE Series is our high performance, feature rich monitor line with
an All Metal Cabinet, PIP / PBP, Dual Analog In, Auto Source Sequencing (up to 7
sources), Trigger Alarm / Sensor, 3D Comb Filter, Deinterlace, Noise Reduction. This
series has the versatility and configuration options you need to support your security
surveillance applications.
OVERVIEW
FEATURES
Metal Chassis
3D Comb Filter / Deinterlace, Noise Reduction, Advanced Auto Power Recovery,
Auto Source Sequencing, Trigger Source Switching, Auto Pixel Shift
Multi-Language Support
BNC Video 2 In / 2 Out, S-Video 1 In / 1 Out, VG
A 1 In,
DVI-D 1 In, HDMI 2 In, Audio 2 In, PC Stereo 1 In
Built-In Speakers
Wall and Rack Mount Kit
Industrial
Interface
Flexible
PREMIUM WIDE
1920 x 1080p FULL HD / LED BLU
PIP / PBP Multi Display Function
Contract No. GS-03F-0152X
FULL HD
FILTER TYPE DISPLAY COLORCONTRAST
1300:1
METAL CHASSIS
Comb Filter
Million Color
PIP / PBP
16.7
BACKLIGHT UNIT
THE ULTIMATE WINDOWS TO THE WORLD
43REDP
PREMIUM WIDE LCD MONITOR
SPECIFICATIONS
ADVANTAGES
INPUT INTERFACE
DIMENSIONS
OPTIONAL MOUNTS
3D Comb Filter, Noise Reduction and Deinterlacing provides high quality color producing the best color sense
Auto Pixel ShiftDual Screen Display / Dual Signal In
Picture-in-Picture (PIP) mode allows an image from an AV source to be displayed as a
picture with in the image from a PC source (or vice-versa). Picture-by-Picture (PBP)
mode permits images from an AV and PC source to be displayed side by side for split-
screen viewing.
Minutely moves pixels diagonally to prevent after-image / static image burn in
WALL
WB-2642
CEILING
CMH-01
HDMI1 / HDMI2 In
A
DVI-D In
B
VGA In
C
PC Stereo In
D
Audio (CVBS-2)
E
S-Video In / Out
G
Trigger
J
AC Power
K
Video1 In / Out
H
Video2 In / Out
I
Audio (CVBS-1)
F
A B C D E F G H I J K
37.95”
3.19”
9.45”
24.57”
42.51”
Pixel Shift (2 hours)
Analog & Digital
42.51 Inch
1920 x 1080 @ 60Hz
1 In
1 In / 2 In
2 Left & Right
1 In
1 In / 1 Out
2 In / 2 Out
NTSC / PAL
< 12ms (Gray to Gray)
NTSC / PAL
8bits / 16.7 Million
16 : 9
1300 : 1
0.4902 x 0.4902mm
450cd/m
2
178 / 178
Screen Size
Electronic galvanized iron / Black
< 107W
AC100 ~ 240V(50/60Hz)
400 x 300mm
WB-2642
CMH-01
3year / 3year
3D Comb Filter
PIP / PBP
Yes
Yes
Yes
Yes
Yes (NO / NC)
Yes
English, Spanish, French, German, Italian
Yes
Max. Resolution
Pixel Pitch
Brightness
Contrast Ratio
Aspect Ratio
Viewing Angle (H/V)
Display Color
Response Time
Video System
Video In / Out (BNC Type)
S-Video In / Out
VGA In (15Pin D-Sub)
DVI-D In / HDMI In
Audio In (RCA Type)
PC Stereo In
Remote Control
Built-in Speakers
Filter Type
Multi Display Function
Deinterlacing
Yes
Advanced Auto Power Recovery
Noise Reduction Control (NR)
LCD Protection Glass
Yes
Auto Pixel Shift
Trigger Sensor
Auto Source Sequencing
Multi Language
Outline Dimension (w/ stand)
Net Weight
Material / Color
Desk Top Stand
Part / Labor
Consumption: < On
Operating Temperature
Storage Temperature
VESA
TM
Mount Size
Wall
Ceiling
0
o
~ 40
o
C / 32
o
~ 104
o
F
-20
o
~ 60
o
C / -4
o
~ 140
o
F
37.95” x 24.57” x 9.45”
21.8 Kg (48.06 lbs)
Yes (10W x 2)
43REDP
*Design and specifications are subject to change without notice
Display
Interface
Transmitter
Audio
Features
General
Mounts
PBP
PIP
7300 Bolsa Avenue, Westminster, CA 92683
Tel. 714.766.6300 / Fax. 714.766.6310 / sales@orionimages.com / www.orionimages.com
Contract No. GS-03F-0152X
