Side 1/8
DIRTY WATER
SUBMERSIBLE
PUMP
750W
INSTRUCTION MANUAL
SPECIFICATIONS
Motor: 750W
Max. Flow Rate: 15,000l/h
Max. Head 8m
Max. Immersion: 8m
Min. Suction Depth 50mm
Max Particle Size: Ø35mm
Water Temp.: 1°C - 35°C
Weight: 5.2kg
PSDW-750
WHAT’S IN THE BOX
Submersible Pump
Universal Adaptor
ozito.com.au
L-Shape Connector
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
9. L-Shape Connector
10. Universal Adaptor
ACCESSORIES
2. It is now ready to be tted with a
25mm (1’’) screw on tap adaptor
(not included).
To t a 32mm (1¼’’)
rigid pipe or exible tubing
(temporary or permanent application)
. Cut the universal adaptor using
a hack saw. It is now ready to be
tted with a 32mm (1¼’’) rigid pipe
or exible tubing (not included).
10
NOTE: TO USE THE PUMP IN PERMANENT
INSTALLATIONS WITH RIGID PIPES, INSTALL A
NON-RETURN VALVE TO AVOID THE FLUID BEING
RE-CIRCULATED ONCE THE PUMP HAS STOPPED.
3. When the oat switch is
about 30° higher than
horizontal (start up level) or
above the handle, the pump
will turn ‘on’ and operate
(water depth of 500mm)
4. When the oat switch is 30°
lower than the horizontal or
below the handle, the pump
will turn ‘off’. (water depth of
approximately 150mm)
NOTE. The hose/tube/
tap adaptor should not be
connected at this stage.
4. Securely attach the hose/
tube/tap adaptor to the
universal adaptor, t hose
clamps if you are using
exible hose or tube, and
tighten well.
30°
30°
