Thank you for purchasing this Panasonic product.
■ This manual is common to all the models regardless of suxes of the Model No.
For details on the Model No., please refer to “Suxes of the Model No.” (
x
page 2).
■ Before operating this product, please read the instructions carefully and save this manual
for future use.
■ Before using this product, be sure to read “Read this rst!” (
x
pages 6 to 17).
DPQP1489ZA/X1
DLP™ Projector
Commercial Use
Operating Instructions
Functional Manual
ENGLISH
Model No.
PT-REQ15
PT-REZ15
* PT‑REQ15 only
Resolution is 3 840 x 2 400 dots
(QUAD PIXEL DRIVE: ON)
2 ‑ ENGLISH
■
Suxes of the Model No.
z
for USA, Canada
B: Black model, the standard zoom lens supplied
LB: Black model, the lens sold separately
z
for United States Government
LBUG: Black model, the lens sold separately
z
for EU, EFTA, UK, Turkey
BEJ: Black model, the standard zoom lens supplied
LBEJ: Black model, the lens sold separately
z
for Korea
B: Black model, the standard zoom lens supplied
z
for Taiwan
B: Black model, the standard zoom lens supplied
z
for India
LBD: Black model, the lens sold separately
z
for other countries or regions
BE: Black model, the standard zoom lens supplied
LBE: Black model, the lens sold separately
ENGLISH - 3
Contents
Contents
Read this rst! 6
Chapter 1 Preparation
Precautions for use 22
Intended use of the product 22
Installation and handling of the laser product
(for USA and Canada) 22
Cautions when transporting 22
Cautions when installing 22
Cautions when setting up the projector 24
Security 25
Notes regarding the wireless LAN 26
QUAD PIXEL DRIVE 26
Slot 27
DIGITAL LINK 27
Art-Net 27
Application software supported by the projector
27
Storing 28
Disposal 28
Cautions on use 28
Accessories 29
Optional accessories 30
About your projector 31
Remote control 31
Projector body 33
Names and functions of the Function Board
(optional) 36
Preparing the remote control 38
Inserting and removing the batteries 38
When using the multiple projectors 38
Connecting the remote control to the projector
with a cable 38
Chapter 2 Getting Started
Setting up 40
Usable outlet 40
Installation mode 40
Parts for installation (optional) 42
Projected image and throw distance 42
Adjusting adjustable feet 48
Removing/attaching the projection lens 49
Removing the projection lens 49
Attaching the projection lens 50
Installing the Function Board 52
Before installing or removing the Function
Board 52
For Intel
®
SDM-S specication Function Board 53
Installing the Function Board 54
Removing the Function Board 54
Installing the SFP module 55
Removing the SFP module 56
Connecting 57
Before connecting 57
Connecting example: AV equipment 58
Connecting example: Computers 60
Connecting example using DIGITAL LINK 61
Connecting example when using the
contrast synchronization function/shutter
synchronization function 63
Chapter 3 Basic Operations
Switching on/o the projector 66
Connecting the power cord 66
Power indicator 67
Switching on the projector 68
When the initial setting screen is displayed 69
When the administrator account setting screen
is displayed 74
Making adjustments and selections 76
Switching o the projector 77
Projecting 78
Selecting the input signal 78
Adjusting the focus, zoom, and lens shift 80
Adjusting the focus balance 81
Executing the lens calibration 81
Moving the projection lens to the home position
82
Lens shift range 83
Using the USB memory 84
Notes on use 84
USB memory that can be used with the
projector 84
Attaching the USB memory 84
Removing the USB memory 84
Operating with the remote control 85
Using the shutter function 85
Using the on-screen display function 85
Using the function button 86
Displaying test patterns 86
Using the status function 87
Setting ID number of the remote control 87
