Side 1/8
User manuals in various languages (français, italiano, español, português, nederlands,
türk, polski) can be found via our product search on:
www.pce-instruments.com
PCE-MTD 100
USER MANUAL
ENGLISH
METAL DETECTOR
2
With your metal detector, you can hunt for coins, relics, jewelry, gold, and silver just about anywhere. This
metal detector is versatile and easy to use. Features include:
Two Operation Modes: All Metal, Disc
» ALL METAL – Lets you search for all dierent types of metal with auto ground balance and high
sensitivity. It’s the best operation mode.
» DISC – Discriminates what kind of metal is being detected.
» Volume – To adjust the volume level of speaker and headphone.
» Earphone Jack – Lets you connect headphones (not supplied) to the detector.
» View Meter and Pointer – The meter pointer swings to the right if metal is found.
» Waterproof Search Coil – Lets you search for metal objects under shallow water.
Note: The search coil is waterproof, but the control housing is not.
» Adjustable Stem – Lets you adjust the detector’s length.
Operates on two 9V alkaline batteries (not supplied).
A few basic rules you should follow while using your detector.
» Always get permission before searching any site.
» Respect the rights and property of others.
» Observe all national, state and local laws when treasure hunting.
» Never destroy historical or archaeological treasures. If you are not sure about an object you have found,
contact a museum or historical society in your area.
» Leave the land vegetation as is, and ll in any holes you dig.
» Use the detector only in safe areas.
» Dispose of any junk you may nd, only in approved areas. Do not leave it for the next treasure hunter
nd.
FEATURES
TREASURE HUNTER’S CODE OF ETHICS
3
PARTS OF THE DETECTOR
1 - Arm rest
2 - Control box
3 - Adjustable Stem with Cable
4 - Search Coil
ASSEMBLING THE DETECTOR
Assembling the detector is easy and requires no special tools. Just follow these steps.
» Unscrew the knobs on the search coil and remove the knobs and the connector. Insert the smaller stem
and align the holes on the search coil bracket and the stem. Push the connector through the holes, then
replace and tighten the knobs.
» Loosen the stem’s lock nut (connected with the handle) in the direction of the arrow. Then insert the
smaller stem into the big stem connected with the handle. Turn the stem’s lock nut in the reverse
direction of the arrow to lock it in place.
» Insert the latch on the top of the handle into the assembly hole on the bottom of the control box. Then
slightly push the control box in the direction of IN on the handle to x the latch in place.
» Tighten the xing screw.
» Insert the search coil cable plug into the ve pin jack on the front control box’s housing.
» Lengthen or shorten the stem, so when you stand upright with the detector in your hand, the search coil
is level with and about 5 ... 2 inches / 1 ... 5cm above the ground. After that tighten the lock nut.
Caution: The search coil cable plug ts into the connector only one way. DO NOT force the plug or you
could damage it.
PREPARATION
