SD card real time data recorder
with harmonic measurement
3 PHASE
Power Meter
Y
our purchase o
f
this 3 PHASE
POWER ANALYZE
R
marks a step
forward for you into
t h e f i e l d o
f
p rec isio n
measurement.
A
l t hough t h i s
POWER ANALYZE
R
is a complex and
delicate instrument,
its durable structure
will allow many
years of use i
f
proper operating
techniques are
developed. Please
read the following
i n str u c t i o n s
carefully and always
keep this manual
within easy reach.
OPERATION MANUAL
PCE-PA 8300
PCE Americas Inc.
711 Commerce Way
Suite 8
Jupiter
FL-33458
USA
From outside US: +1
Tel: (561) 320-9162
Fax: (561) 320-9176
info@pce-americas.com
www.pce-instruments.com/english
www.pce-instruments.com
PCE Instruments UK Ltd.
Units 12/13
Southpoint Business Park
Ensign way
Hampshire / Southampton
United Kingdom, SO31 4RF
From outside UK: +44
Tel: (0) 2380 98703 0
Fax: (0) 2380 98703 9
info@pce-instruments.com
Caution Symbol
Caution :
* Risk of electric shock !
* During the measurement,
do not open the cabinet.
Caution :
* Do not apply the overload
voltage, current to the input
terminal !
* Remove test leads before open
the battery cover !
* Cleaning - Only use the dry
cloth to clean the plastic case !
Environment Conditions
* Installation Categories III 600V.
* Pollution Degree 2.
* Altitude up to 2000 meters.
* Indoor use.
* Relative humidity 80% max.
TABLE OF CONTENTS
1. FEATURES................................................................1
2. SPECIFICATIONS.....................................................
.
2
2-1 General Specifications........................................
.
2
2-2 Electrical Specifications.......................................5
3. FRONT PANEL DESCRIPTION.....................................10
4. MEASURING PREPARATION ......................................13
4-1 The original screen.............................................
.
13
4-2 Entry the measurement Screen............................ 13
4-3 The summary description of keyboard.................. 15
4-4 SETUP KEY description........................................ 16
4-5 Setting function description before measuring....... 17
5. MEASURING PROCEDURES .......................................46
5-1 1Φ 2W ( one phase by two wires )
measurement..................................................... 46
5-2 1Φ 3W ( one phase by three wires )
measurement..................................................... 47
5-3 3Φ 3W ( three phase by three wires )
measurement..................................................... 49
5-4 3Φ 4W ( three phase by four wires )
measurement..................................................... 50
5-5 The CT and PT measurement...............................52
5-6 ZERO adjustment for Watt Hour...........................53
5-7 Harmonic Function Measurement ........................
.
54
5-8 Graphic Phasor Diagram...................................... 56
5-9 Voltage/Current Waveform..................................
.
58
5-10 Transient Capture ( Dips, Swells, Outage ).......... 60
5-11 Data Logger function.........................................63
5-12 Data Hold function............................................ 65
