PCE Instruments PCE-TWT 500 Bruksanvisning
PCE Instruments
måleinstrument
PCE-TWT 500
Les nedenfor 📖 manual på norsk for PCE Instruments PCE-TWT 500 (9 sider) i kategorien måleinstrument. Denne guiden var nyttig for 3 personer og ble vurdert med 5.0 stjerner i gjennomsnitt av 2 brukere
Side 1/9
User manuals in various languages (français, italiano, español, português, nederlands,
türk, polski) can be found via our product search on:
www.pce-instruments.com
PCE-TWT 500
USER MANUAL
ENGLISH
TORQUE WRENCH TESTER
2
PCE-TWT 500 torque wrench tester is a special instrument for checking the torque wrench and torque
screwdriver. It is mainly used for checking and calibrating the torque wrench, preset torque wrench, analog
torque wrench. Widely used in electrical manufacturing, machinery manufacturing, automotive light
industry, professional scientic research and testing industry. The torque value shows on digital display,
more accurate and intuitive.
» Three units for optional: N.m / kgf.cm / lbf.in
» Two measuring mode: Real-time and peak-value mode can switch into each other
» Upper limit and lower limit value setting: This instrument can set upper limited value and lower limited
value, when reach the value, it will buzzer alarm.
» Data storage function: The instrument can save 100 measurement data.
MAIN USAGE AND SCOPE OF APPLICATION
PRODUCT FEATURES
SPECIFICATIONS
Max. 500N.m
Min. resolution 0.01
Accuracy ±1%
Unit N.m / Kgf.cm / Lbf.in
Power Input: AC 220v
Output: DC 12V
Dimension 1142x553x360mm
Working temperature 5°C ... 35°C
Transport temperature -10°C ... 60°C
Relative humidity 15% ... 80%RH
Working environment No seismic source and corrosive media around
Weight (Kg) 43kg
