Pentax K-70 Bruksanvisning

Pentax fotokamera K-70

Les nedenfor 📖 manual på norsk for Pentax K-70 (156 sider) i kategorien fotokamera. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/156

RICOH IMAGING COMPANY, LTD.

1-3-6, Nakamagome, Ohta-ku, Tokyo 143-8555, JAPAN

(http://www.ricoh-imaging.co.jp)

RICOH IMAGING EUROPE

S.A.S.

Parc Tertiaire SILIC 7-9, avenue Robert Schuman - B.P. 70102,

94513 Rungis Cedex, FRANCE

(http://www.ricoh-imaging.eu)

RICOH IMAGING AMERICAS

CORPORATION

633 17th Street, Suite 2600, Denver, Colorado 80202, U.S.A.

(http://www.us.ricoh-imaging.com)

RICOH IMAGING CANADA

INC.

5520 Explorer Drive Suite 300, Mississauga, Ontario, L4W 5L1, CANADA

(http://www.ricoh-imaging.ca)

RICOH IMAGING CHINA CO.,

LTD.

23D, Jun Yao International Plaza, 789 Zhaojiabang Road, Xu Hui District,

Shanghai, 200032, CHINA

(http://www.ricoh-imaging.com.cn)

http://www.ricoh-imaging.co.jp/english

This contact information may change without notice.

Please check the latest information on our websites.

Operating Manual

To ensure the best performance from your

camera, please read the Operating Manual

before using the camera.

Introduction

Getting Started

Shooting

Playback

Sharing

Settings

SLR Digital Camera

Appendix

• Specifications and external dimensions are subject to change without notice.

R01DTD16 Printed in Japan

e_kb586_cover_7.4mm.fm Page 1 Friday, April 8, 2016 4:56 PM

We have paid close attention to the safety of this camera. When using this

camera, we request your special attention regarding items marked with the

following symbols.

Warning

• Do not disassemble or modify the camera. High voltage areas are

present inside the camera, with the risk of electric shock.

• If the camera interior is exposed due to dropping or otherwise damaging

the camera, never touch the exposed portion. There is a risk of electric

shock.

• Do not aim the camera at the sun or other strong light sources when

taking pictures or leave the camera sitting in direct sunlight with a lens

cap off. Doing so may cause the camera to malfunction or cause a fire.

• Do not look at the sun or other strong light sources through a lens. Doing

so may lead to a loss of eyesight or cause vision to be impaired.

• If any irregularities occur during use, such as smoke or a strange odor,

stop using the camera immediately, remove the battery or the AC

adapter, and contact your nearest service center. Continued use can

cause a fire or electric shock.

Caution

• Do not place your finger over the flash when discharging the flash. You

may burn yourself.

• Do not cover the flash with clothing when discharging the flash.

Discoloration may occur.

• Some portions of the camera heat up during use. There is a risk of low

temperature burns when holding such portions for long periods.

• Should the monitor be damaged, be careful of glass fragments. Also, be

careful not to allow the liquid crystal to get on your skin or in your eyes

or mouth.

• Depending on your individual factors or physical condition, the use of the

camera may cause itching, rashes or blisters. In case of any

abnormality, stop using the camera and get medical attention

immediately.

Warning

• Always use the battery charger and AC adapter exclusively developed

for this camera, with the specified power and voltage. Using a battery

charger or AC adapter not exclusive to this camera, or using the

exclusive battery charger or AC adapter with an unspecified power or

voltage can cause a fire, electric shock, or camera breakdown. The

specified voltage is 100 - 240V AC.

• Do not disassemble or modify the product. This can cause a fire or

electric shock.

• If the generation of smoke or strange odor from the product or other

abnormality occurs, immediately discontinue using and consult your

nearest service center. Continued use can cause a fire or electric shock.

• If water should happen to get inside the product, consult your nearest

service center. Continued use can cause a fire or electric shock.

• If you see a lightning flash or hear thunder during use of the battery

charger or AC adapter, unplug the power plug and discontinue using.

Continued use can cause damage to the product, fire or electric shock.

• Wipe off the power plug if it should become covered with dust.

Accumulated dust may cause a fire.

• To reduce the risk of hazards, use only CSA/UL certified power supply

cord set, cord is Type SPT-2 or heavier, minimum NO.18 AWG copper,

one end with a molded-on male attachment plug cap (with a specified

NEMA configuration), and the other is provided with a molded-on female

connector body (with a specified IEC nonindustrial type configuration) or

the equivalent.

Caution

• Do not place or drop heavy objects on or forcefully bend the AC plug

cord. Doing so may damage the cord. Should the AC plug cord be

damaged, consult your nearest service center.

For Using Your Camera Safely

Warning

This symbol indicates that ignoring this item could

cause serious personal injuries.

Caution

This symbol indicates that ignoring this item could

cause minor or medium personal injuries, or loss

of property.

About the Camera

About the Battery Charger and AC Adapter

Memo

e_kb586_cover_7.4mm.fm Page 2 Friday, April 8, 2016 4:56 PM

• Do not touch or short-circuit the terminal area of the AC plug cord while

the cord is plugged in.

• Do not handle the power plug with wet hands. This can cause an electric

shock.

• Do not drop the product, or subject it to violent impact. This can cause

the product to breakdown.

• Do not use the battery charger D-BC109 to charge batteries other than

the rechargeable lithium-ion battery D-LI109. Attempting to charge other

types of batteries may cause an explosion or heating, or may damage

the battery charger.

Warning

• If any leakage from the battery should come in contact with your eyes,

do not rub them. Flush your eyes with clean water and get medical

attention immediately.

Caution

• Only use the specified battery with this camera. Use of other batteries

may cause an explosion or fire.

• Do not disassemble the battery. Disassembling the battery may cause

an explosion or leakage.

• Remove the battery from the camera immediately if it becomes hot or

begins to smoke. Be careful not to burn yourself during removal.

• Keep wires, hairpins, and other metal objects away from the + and -

contacts of the battery.

• Do not short the battery or dispose of the battery in fire. This can cause

an explosion or fire.

• If any leakage from the battery should come in contact with skin or

clothing, it may cause irritation to the skin. Wash the affected areas

thoroughly with water.

• Precautions for D-LI109 Battery Usage:

- USE SPECIFIED CHARGER ONLY.

- DO NOT INCINERATE.

- DO NOT DISASSEMBLE.

- DO NOT SHORT CIRCUIT.

- DO NOT EXPOSE TO HIGH TEMP. (140°F / 60°C)

Warning

• Do not place the camera and its accessories within the reach of small

children.

1. If the product falls or is operated accidentally, it may cause serious

personal injuries.

2. Wrapping the strap around a neck may cause suffocation.

3. To avoid the risk of a small accessory such as the battery or memory

cards from being swallowed by mistake, keep them out of the reach

of small children. Seek medical attention immediately if an accessory

is accidentally swallowed.

About the Rechargeable Lithium-ion Battery

Keep the Camera and its Accessories out of the

Reach of Small Children

Produkspesifikasjoner

Merke:	Pentax
Kategori:	fotokamera
Modell:	K-70
Vekt:	628 g
Bredde:	125.5 mm
Dybde:	74 mm
Høyde:	93 mm
Berøringsskjerm:	Nei
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
GPS:	Ja
Videoopptak:	Ja
Strømkildetype:	Batteri
Fokus:	TTL
USB-versjon:	2.0
Bildestabilisator:	Ja
Maksimal bildeoppløsning:	6000 x 4000 piksler
Kameratype:	Kamerahus
Digital zoom:	- x
Optisk zoom:	- x
Blitsrekkevidde (tele):	- m
Maksimal videooppløsning:	1920 x 1080 piksler
Innebygd mikrofon:	Ja
Skjermoppløsning (numerisk):	921000 piksler
Hvitbalanse:	Auto, Cloudy, Daylight, Fluorescent H, Fluorescent L, Shade, Tungsten
Andre LCD-skjerm:	Nei
Videooppløsninger:	1280 x 720,1920 x 1080 piksler
HDMI:	Ja
Sideforhold:	3:2
Scenemoduser:	Backlight, Close-up (macro), Night, Night landscape, Night portrait, Panorama, Sunrise, Sunset, Landscape (scenery)
Fotoeffekter:	Black&White, Neutral, Sepia, Vivid
Minnespor:	1
USB-kontakt:	Micro-USB B
Søker:	Elektronisk
Batteriteknologi:	Lithium-Ion (Li-Ion)
Batteritype:	D-LI109
Kontrastjustering:	Ja
Histogram:	Ja
Sensortype:	CMOS
Støttede bildeformater:	JPEG XR, RAW
Produktfarge:	Sort
HD-type:	Full HD
Antall støttede batterier:	1
Minnekortenhet:	SD, SDHC, SDXC
Skjermdiagonal:	3 "
Batteriliv (maks.):	4.5 timer
Driftstemperatur (T-T):	-10 - 40 °C
Hurtigstartsguide:	Ja
Megapiksel:	24.24 MP
Justering av fokus:	Automatisk
Oppløsning ved innspillingshastighet:	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@60fps
Relativ luftfuktighet under drift (H-H):	0 - 85
Batterier medfølger:	Ja
Display:	TFT
Totale megapiksler:	24.78 MP
Videoformat som støttes:	H.264, MOV, MPEG4
Stillbildeoppløsning:	6000×4000, 6000×4000, 4608×3072, 3072×2048, 1920×1440
Støttede forhold:	4:3, 16:9
Objektivmonteringsgrensesnitt:	Pentax KAF, Pentax KAF2, Pentax KAF3
Bevegelig JPEG-bildehastighet:	60 fps
Kamelukkertype:	Elektronisk
Lysstyrkejustering:	Ja
Bildesensor størrelse:	- "
Stemmeinnspilling:	Ja
Bildeføler størrelse (BxH):	23.5 x 15.6 mm
Forsinkelse selvutløser:	2, 12 s
Fargemetningsjustering:	Ja
Kameraavspilling:	Movie, Single image, Slide show
Batteri levetid (CIPA-standard):	480 bilder
Normalt fokuseringsområde (tele):	- m
Normalt fokuseringsområde (vidvinkel):	- m
Autofokus (AF)-valg:	Automatisk
Autofokus (AF)-lås:	Ja
Autofokus (AF) assistanselys:	Ja
ISO-sensitivitet:	160,200,400,800,1600,3200,6400,12800,25600,51200,102400
Lyseksponeringsfunksjoner:	Aperture priority AE, Auto, Manual, Shutter priority AE
Lyseksponeringskontroll:	Program AE
Lyseksponeringskorreksjon:	± 5EV (1/2EV; 1/3EV step)
ISO-sensitivitet (min.):	100
ISO-sensitivitet (maks.):	102400
Raskeste lukkerhastighet:	1/6000 s
Tregeste lukkerhastighet:	30 s
Blitsmodusene:	Auto, Flash off, Flash on, Red-eye reduction, Slow synchronization
Blitsrekkevidde (bredde):	- m
Sykroniseringshastighet flash:	1/180 s
Blitseksponeringskorreksjon:	-2EV - +1EV (1/2 EV step)
Førblits:	Ja
Variant-vinkel LCD-skjerm:	Ja
