Side 1/2
8300 W. Good Hope Rd. • Milwaukee, WI 53223 • (800) 558-5592 • Fax: (414) 353-7069 • perlick.com
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without warning.
24” Signature Series
freezer
HP24FS-3 24” INDOOR MODEL
HP24FO-3 24” OUTDOOR MODEL
Form No.HP24F-3
Rev. 02.09.2017
C
US
• Available with solid stainless steel door, solid wood overlay
door, stainless steel drawers or wood overlay drawers
• Freezer equipped with automatic hot gas defrost for
maintenance-free defrosting
• Door models include two (2) full-extension pull-out
shelves
• Freezer temperature -10°- 10°F
• Zero-clearance hinging allows for abutment with
surrounding cabinetry
• Perlick’s commercial-grade, 390 Btu standard compressor
• Front-vented, RAPIDcool forced-air refrigeration system
• Commercial-grade stainless steel interior and exterior
• Industry Exclusive adjustable, full-extension pull-out
shelves; drawer models feature self-closing slides
• Stainless-steel ball-bearing glides provide smooth
movement of shelves
• Low E, UV-coated glass provides industry leading
insulation and protection.
• Adjustable Crisp White and Cool Blue LED lighting
• State-of-the-art digital control module
• Optional door locks and Industry-Exclusive drawer locks
(factory installed)
• Stacking kit available
• Indoor and outdoor models available
• Also available - 24” Refrigerator, Beverage Center, Wine
Reserve, Beer Dispenser, and Dual-Zone Wine Reserve
• 5.2 cubic feet of capacity
• Industry Best Three Year Warranty plus additional three
years on sealed system
general Signature Series
features
HP24FS-3/FO-3 features
Solid Door Model Drawer Model
8300 W. Good Hope Rd. • Milwaukee, WI 53223 • (800) 558-5592 • Fax: (414) 353-7069 • perlick.com
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without warning.
Form No.HP24F-3
Rev. 02.09.2017
Overall Width 23-7/8” (60.64 cm.)
Overall Height 34-1/4” (86.96 cm.)
Overall Depth 24” (60.96 cm.)
Opening Width 24” (60.96 cm.)
Opening Height 34-3/8” (87.31 cm.)
Opening Depth 24” (60.96 cm.)
Refrigerated Volume 5.2 cu. ft.
Door Swing Clearance 25” (63.5 cm.) minimum
Electrical 115V, 60Hz., 1 Phase, 2.3 amps
Plumbing None Required
Annual Energy Usage 443 kWh/yr
Shipping Weight 191 lbs (68.04 kg.)
product specifications indoor models
HP24FS-3-1L* Solid stainless steel door, hinge left
HP24FS-3-2L* Solid wood overlay door, hinge left
HP24FS-3-5 Stainless steel drawers
HP24FS-3-6 Wood overlay drawers
outdoor models
Door Models
Drawer Models
when fully extended.
*
- Leg levelers can add
3/4" to these dimensions
HP24FO-3-1L* Solid stainless steel door, hinge left
HP24FO-3-2L* Solid wood overlay door, hinge left
HP24FO-3-5 Stainless steel drawers
HP24FO-3-6 Wood overlay drawers
* Also available hinge right
