Side 1/12

DSP8.8 Manual

Digital Signal Processor

FEATURES

● 8-channel high level inputs with signal sense turn on and load resistors

● 6-channel low level inputs

● Aux input (3.5mm, high level for external NAVI/hands-free)

● USB input for uncompressed hi-res audio from iOS/Android smart devices/thumb drives up to 24bit/192kHz

● Wi-Fi input for wireless connectivity and uncompressed hi-res audio streaming up to 24bit/192kHz

● Toslink optical hi-res audio input up to 24bit/192kHz

● 8-channel 5 volt low level outputs

● Real time DSP tuning via DSP8.8 congurator app for iOS, Android, Mac and Windows PC

● 240 bands of 1/3 octave parametric EQ adjustment (30 bands per channel)

● DRC Included (Dash Mount Remote Control): multi-function remote for source select, volume, sub level, 6

selectable presets, and custom illumination

● DSP8.8 RC remote control app for iOS and Android phones/tablets for source select, volume, sub level, and

6 selectable presets

● Dimensions (WxHxD): 7.5” x 2” x 7.75” 190.5 x 51 x 197mm

DSP8.8 Set Manual

The DSP8.8 is a very sophisticated digital signal processor, that has been engineered to enhance the

acoustical performance of your audio system to its maximum capabilities. Zero compromises were made

to ensure that only the highest quality components were used to make such a technologically advanced

product. The heart of this high-resolution audio processor starts with a very powerful 64-bit DSP processor

chip, supported by high quality 24-bit AD & DA converters. System versatility can be optimized through

utilization of the 5 available audio source inputs. Lastly, what makes the DSP8.8 transcend above all

other automotive DSPs is that the DSP8.8 is the WORLD’S FIRST Wi-Fi streaming DSP for any device using

iOS, Android, Mac or Windows PC. This allows users full access of the most ergonomic, user friendly setup/

tuning interface to date that makes tuning the DSP8.8 a very simple and precise process no matter if

you’re using a computer running on Windows PC, Mac OS, tablets or smartphones running on iOS, or

Android operating systems.

General Safety Instructions

Before starting installation of the DSP8.8, disconnect the vehicle’s negative battery terminal to prevent

damage to the unit, or possible re and/or risk of injury. For the best performance and to ensure full

warranty coverage, we highly recommend getting this product installed by an authorized PHOENIX

GOLD dealer. Please only use the enclosed specied harnesses for proper installation of the DSP8.8. The

use of other harnesses could result in permanent unwarrantable damage of the processor, and/or the

source and connected high quality audio equipment. Mount the DSP8.8 using the supplied mounting

screws to a very solid, well-ventilated area in the vehicle that allows proper cooling and is free of moisture

and vibration.

Box Contents:

• 1- DSP8.8 Processor

• 1- DRC/Wi-Fi module (Dash Remote Control)

• 1- Power Harness (4-pin)

• 1- High Level Input Harness (16-pin)

• 1- Aux Input Harness (6-pin)

• 1- Micro-USB Cable 5m (Wi-Fi to DSP)

• 1- RJ11 Remote Control Cable 5m (RJ11)

• 4 - Mounting Screws

• Quick Start Guide

1. Product Overview

2. General Safety Instructions

3. Box Contents

4. DSP Features

5. Technical Specications

6. Technical Data

7. Device Connections

8. Connecting Wi-Fi module/PC/iOS and Android Devices

9. Connecting Analog Sources

10. Connecting Digital Sources

11. Installing Software and Apps

12. Windows Installation for XP, 7, 8, 10

13. Mac App Installation

14. Establishing a Connection

15. Conguration Screen

16. Using the Conguration Screen

17. DRC Functions

718. DSP RC App

19. Troubleshooting

Table of Contents DSP8.8 Product Overview DSP8.8

DSP8.8 Set Manual

Analog Devices 64Bit Sigma Digital Signal Processor Chip

High Resolution Compatibility up to 24 bit/192kHz

Burr Brown High Quality Analog to Digital Convertors

Burr Brown High Quality Digital to Analog Convertor

Burr Brown High Quality Operational Ampliers

Burr Brown High Quality Differential Rectiers

WIMA High Quality Polyester Output Capacitors

ELNA High Quality RFS SILMIC II Miniature Silk Audio Capacitors

Resonance Conversion Power Supply that Supports Start-Stop Vehicles

Signal-to-noise ratio (S/N) RCA input: >103 dBA

Signal-to-noise ratio (S/N) AUX input: >103 dBA

Signal-to-noise ratio (S/N) Toslink input: >110 dBA

Signal-to-noise ratio (S/N) USB/Wi-Fi input: >110 dBA

Channel separation digital inputs: >95 dBA

Channel separation analog inputs: >72 dBA

THD digital: 0.003%

THD analog: 0.01%

Frequency Response: 15 Hz – 25 kHz

Input impedance high level: 33 ohm

Input voltage high level: max. 20 Vrms

Input impedance RCA: >47 ohm

Input voltage RCA 0dB Attenuation: max. 4 Vrms

Input voltage RCA MAX Attenuation: max. 8 Vrms

Output impedance RCA: 50 ohm

Output voltage RCA: max. 5 Vrms

USB input streaming bitrate: 24bit/192kHz

Wi-Fi input streaming bitrate: 24bit/192kHz

Toslink input bitrate: 24bit/96kHz

Toslink output up-sampling bitrate from

analog inputs: 24bit/48kHz

Operating voltage: 6.5V - 16V DC

Current draw: <400mA

Remote output current: max 1.3 A

Dimensions: W x H X D 7.5” x 2” x 7.75”

190.5 x 51 x 197mm

Weight: 2.15 lbs. 1326 kg

DSP Features DSP8.8 Technical Specications DSP8.8

Technical Data

Wi-Fi Functionality

2.4 GHz Wi-Fi Module built into the DRC

Real time DSP conguration over Wi-Fi with smart device app for iOS and Android

Real time DSP conguration over Wi-Fi with Mac OS software

Real time DSP conguration over Wi-Fi with Windows PC software

Audio streaming from Mac OS using Airplay

Audio streaming from iOS using Airplay*

Audio streaming from Android devices using casting apps that UPnP/DLNA formats*

*Hi-Resolution audio streaming apps required for 24-bit/92-196kHz audio les

Micro-USB

Real time DSP conguration through Windows PC software

Uncompressed hi-res audio streaming from Windows PC

Uncompressed hi-res audio streaming from iOS device with iOS Camera Connection Kit

Uncompressed hi-res audio streaming from Android device with OTG adapter

APP/Software Features

30 band parametric equalizer per channel

Selectable crossovers: High/Low/Band-Pass slopes 0 – 30dB, Butterworth/Bessel/Linkwitz Riley

Time delay: automatic or manual setup 0 to 5 meters or 14.6ms adjustable in 0.01ms steps

Large setup overview page for fast check of current system settings

DSP conguration les can be saved, imported, exported, copied and reloaded

Autoremote for customizable thresholds and timing for system on and off

Input Vu Meters for RCA and high level sources

Software controllable analog attenuation on preamp and high level inputs

Customizable name/alias on each preset and output channel

DRC backlight color customization through app and conguration software

INPUTS

6 RCA preamp inputs

8 High level inputs w/ load resistors

1 Stereo aux input 3.5mm jack

1 Telephone/navigation input

1 Micro-USB input

1 SPDIF optical input

OUTPUTS

8 RCA preamp outputs

1 SPDIF optical output
