Side 1/124

S-3EX

http://www.pioneer.uk

(or http://www.pioneer.eu)

http://www.pioneer.fr

(ou http://www.pioneer.eu).

http://www.pioneer.de

http://www.pioneer.eu

http://www.pioneer.it

http://www.pioneer.eu

http://www.pioneer.nl - http://www.pioneer.be

(of http://www.pioneer.eu)

http://www.pioneer.es

http://www.pioneer.eu

http://www.pioneer.pt

http://www.pioneer.se

http://www.pioneer.eu

http://www.pioneer.dk

http://www.pioneer.eu

http://www.pioneer.no

http://www.pioneer.fi

(or http://www.pioneer.eu).

http://www.pioneer-rus.ru

http://www.pioneer.eu

Istruzioni di utilizzo

Handleiding /

Sistema de Colunas /

S-3EX_EN.book 1 ページ２００７年４月２３日　月曜日　午後５時１２分

If you want to dispose this product, do not mix it with general household waste. There is a separate collection system for used

electronic products in accordance with legislation that requires proper treatment, recovery and recycling.

Private households in the member states of the EU, in Switzerland and Norway may return their used electronic products free of charge to

designated collection facilities or to a retailer (if you purchase a similar new one).

For countries not mentioned above, please contact your local authorities for the correct method of disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery and recycling and thus prevent potential

negative effects on the environment and human health.

K058_A_En

Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model

properly. After you have finished reading the instructions, put them away in a safe place for future reference.

Contents

Before you start

What’s in the box

About the EX series

Technology behind the S-3EX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

CST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Ceramic Graphite Diaphragm. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Magnesium Alloy Diaphragm . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Bass Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Bass Enclosure Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Crossover Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Collaboration with Air Studios . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation and Placement

How to install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Mounting the Fall-Prevention Fastener . . . . . . . . . . . . . . . . . . . . . 6

Choosing Where To Place The Speaker Systems . . . . . . . . . . . . . 6

Connections

Connecting to an amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Connecting the cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Single-Wire Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Bi-Wire Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Bi-Amplification Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Other Information

Attaching/Removing the Grille Cover . . . . . . . . . . . . . . . . . . . . . . 11

Cleaning the speaker cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

S-3EX_EN.book 2 ページ２００７年４月２３日　月曜日　午後５時１２分

English

Before you start

• The nominal impedance of this speaker system is 6 Ω.

Connect the speaker system to an amplifier with a load

impedance ranging from 4 Ω to 16 Ω (a model with “4 Ω to 16

Ω” displayed on the speaker output terminals).

In order to prevent damage to the speaker system resulting

from input overload, please observe the following precautions:

• Do not supply power to the speaker system in excess of the

maximum permissible input.

• When using a graphic equalizer to emphasize loud sounds in

the high-frequency range, do not use excessive amplifier

volume.

• Do not try to force a low-powered amplifier to produce loud

volumes of sound (the amplifier’s harmonic distortion will be

increased, and you may damage the speaker).

Caution: installation

• When placing this unit, ensure that it is firmly secured and

avoid areas where it may be likely to fall and cause injury in the

event of a natural disaster (such as an earthquake).

• Do not attach these speakers to the wall or ceiling. They may

fall off and cause injury.

• Do not install your speakers overhead on the ceiling or wall. If

improperly attached, the speaker grille can fall and cause

damage or personal injury.

• Switch off and unplug your AV equipment and consult the

instructions when connecting up components. Make sure you

use the correct connecting cables.

Caution: in use

• Do not place the speaker on an unstable surface. It could

present a hazard if it falls, as well as damaging the equipment.

• Do not use the speaker to output distorted sound for long

periods of times. This can result in a fire hazard.

• Do not sit or stand on the speaker, or let children play on the

speaker.

• Do not put large or heavy objects on top of the speaker.

• Do not place magnetic objects such as screwdrivers or iron

parts near the tweeter or midrange. Since the speakers use

strong magnets, the objects may be attracted, causing injury

or damaging the diaphragm.

What’s in the box

Spike bases x3

Mounting pads 3 types, 2 each

Metal catch x1

Screw (for metal catch) x1

Grille x1

Operating instructions

CAUTION

hese speaker terminals carry HAZARDOUS LIVE

voltage. To prevent the risk of electric shock when

connecting or disconnecting the speaker cables,

disconnect the power cord before touching any

uninsulated parts.

D3-4-2-2-3_A_En

S-3EX_EN.book 3 ページ２００７年４月２３日　月曜日　午後５時１２分

Produkspesifikasjoner

Merke:	Pioneer
Kategori:	Høyttaler
Modell:	S-3EX-QL
Vekt:	48000 g
Utgangseffekt:	160 W
Impedans:	6 Ω
Dimensjoner (B x D x H):	350 x 541 x 1224 mm
Diskanthøyttaler:	Ja
Modell/Type:	Gulvstående høyttalere
Lyd-utgang kanaler:	3.1 kanaler
RMS-rangert strøm/utgangseffekt:	160 W
Frekvensrekkevidde:	30 - 100000 Hz
Basshøyttalerens diameter:	160 mm
Diskant diameter:	30 mm
Sensitivitet/følsomhet:	88.5 dB
Diameter på mellomtone-driver:	140 mm
