FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and qualied
in pool equipment by the jurisdiction in which the product will be installed, where such state or local requirements
exist. In the event no such state or local requirement exists, the maintainer must be a professional with sufcient
experience in pool equipment installation and maintenance, so that all of the instructions in this manual can be
followed exactly. Improper installation and/or operation can create dangerous electrical hazards, which can cause
high voltages to run through the electrical system. Before installing this product, read and follow all warning
notices and instructions that accompany this product. Failure to follow warning notices and instructions may result
in property damage, personal injury, or death. Improper installation and/or operation will void the warranty.
If these instructions are not followed exactly, a re or explosion may result, causing property damage, personal
injury, or death.
ATTENTION INSTALLER: This manual contains important information about the installation,
operation and safe use of this product. This information should be given to the owner/operator of
this equipment.
WARNING
H0344400 REVD
Pressure Cleaner
Booster Pump
Installation and
Operation Manual
For Polaris PB4-60 Booster Pumps with Serial Numbers beginning with "PB"
and a manufacturing date on or after Dec 1, 2011.
ENGLISH
|
FRANÇAIS
Page 2
ENGLISH
Polaris® PB4-60 Booster Pump | Installation and Operation Manual
Table of Contents
Section 1. IMPORTANT SAFETY INSTRUC-
TIONS ............................................. 3
1.1 Safety Instructions ............................................ 3
1.2 Pool Pump Suction Entrapment
Prevention Guidelines ....................................... 5
Section 2. General Description ...................... 6
2.1 Introduction ....................................................... 6
2.2 Description ........................................................ 6
2.3 Preparation ....................................................... 6
Section 3. Installation ..................................... 6
3.1 Electrical Installation ......................................... 6
3.1.1 Voltage Checks ..................................... 6
3.1.2 Bonding and Grounding ......................... 6
3.2 Electrical ........................................................... 6
3.2.1 Electrical Wiring ..................................... 7
3.3 Plumbing ........................................................... 7
3.3.1 Requirements ........................................ 7
3.3.2 Pipe Sizing ............................................. 8
3.3.3 Pump Location ....................................... 8
3.3.4 Install the Pump ..................................... 9
3.3.5 Installation Recommendations .............. 9
3.3.6 Check the Water Flow ........................... 9
3.3.7 Conduct Pressure Test .......................... 10
Section 4. Operation ....................................... 10
4.1 Start-up ............................................................. 10
Section 5. Maintenance .................................. 11
5.1 Winterizing the Pump ........................................ 11
Section 6. Troubleshooting and Repair ........ 12
6.1 Troubleshooting ................................................ 12
6.2 Service Technician Maintenance ...................... 13
6.2.1 Blocked Impeller .................................... 13
6.2.2 Impeller Removal ................................... 13
6.2.3 Impeller Replacement ............................ 14
6.2.4 Mechanical Seal Replacement .............. 14
6.2.5 Motor Replacement .............................. 15
Section 7. Product Specications and Techni-
cal Data .......................................... 16
7.1 Replacement Parts List ..................................... 16
7.2 Polaris PB4-60 Booster Pump Exploded View . 16
7.3 Pump Dimensions ............................................. 17
7.4 Visual Identication of the New Polaris PB4-60
Booster Pump ................................................... 18
DATE OF INSTALLATION
INSTALLER INFORMATION
INITIAL PRESSURE GAUGE READING (WITH CLEAN FILTER)
PUMP MODEL HORSEPOWER
NOTES:
EQUIPMENT INFORMATION RECORD
