Side 1/4
Encore™ PSW3-1000
Wash Stand with Wheels
Technical Information
POLYJOHN
USA
PolyJohn Enterprises Corp
2500 Gaspar Ave.
Whiting, IN 46394
Phone: 800-292-1305
Fax: 219-659-0625
www.polyjohn.com
info@polyjohn.com
POLYJOHN
WORLDWIDE
PolyJohn (UK) Ltd.
Equinox 1 Audby Lane
Wetherby, England LS22 7RD
Phone: 44 (0) 1937-583333
Fax: 44 (0) 1937-583322
www.polyjohn.co.uk
sales@polyjohn.co.uk
PSW3-1000 - Encore
August - 2020
Page 1 of 4
POLYJOHN
CANADA
PolyJohn Canada
P.O. Box 2300
199 Forest Plain Rd.
Orillia, Ontario LV3 6S2
Phone: 800-465-9590
Fax: 705-325-8250
www.polyjohncanada.ca
info@polyjohncanada.ca
All materials, including resin, pigments
and additives used to make the plastic
components as well as the plumbing
components that come in contact with
the fresh water are U.S.
FDA food grade
compliant.
General Overview
The ™ sink is easily Encore transportable
with a built-in handle and lightweight
rubber tread wheels. Designed for use
where convenient hand washing is desired
or required, such as o ices, classrooms,
construction sites, festivals, food service
locations, etc., to be used indoors or out. The
compact design allows it to be used most
anywhere. Ideal where space is limited. Shipped
fully assembled.
Specications
Height 62 in 157.5 cm
Width 18 in 45.5 cm
Depth 20 in 50.8 cm
Fresh Water Capacity 15.5 gal 58.7 L
Gray Water Capacity 19 gal 72 L
Pump Capacity 59.14 ml (per stroke) 2 oz
Soap Dispenser Capacity 887 ml30 oz
Number of Single Dispenses 992 992
Paper Towel Capacity
1 Roll or 500 Single Fold
(2 packs - Georgia Pacic 23504)
Weight Empty 47 lb 21.3 kg
Weight Full 177 lb 80 kg
Fresh Water Drain
Emptying Fresh Water
Drain the fresh water by unscrewing the
plug located at the bottom of the sink by
1/4 turn. Tighten the plug when nished.
Emptying Gray Water
Wheel the sink to a proper and approved
drain location. Pull the hose out from the
rib on the back of the holding tank, remove
the hose cap and empty the gray water. Replace
the cap when nished.
Filling with Fresh Water
Unscrew the ll plug located at the top, left hand
side of the wash basin by pushing down and turning
counter clockwise 1/4 turn. Insert a standard 3/4”
garden or similar type hose and ll with a few gallons
of fresh water to perform a system check. Depress
the pump a few times to “prime” it (the pump has a
built-in check valve that will hold a prime between uses).
If needed, continue lling to the top (which is the 15.5
gallon water level capacity). Tighten the plug when
nished.
Operation Directions
Paper Towel Dispenser
These dispensers are designed to accept towels that are no wider than 9-1/2” wide,
whether using single, multi-fold, or a roll towel. The recommended towels are the
Georgia Pacic #23504 - single fold towel or the Baywest Ecosoft #46200 - roll towel.
Opening the Paper Towel Dispenser
Position your hands on both sides of the
dispenser cover While pulling (as shown).
out on both sides lift up the cover and pull
down towards yourself .
Filling the Dispenser
Filling with Fold Towels: Place the package
of towels on the towel tray with the fold of the
towel facing downward. Pull the rst towel through the
middle opening of the paper towel tray. Close the cover.
Filling with a Roll of Towels: Place the roll of towels on the spindle with the roll of
towel
s coming off towards you with the arrow end of the spindle facing towards the
right. Place the spindle into the right side o the dispenser rst. Place the left side
of the spindle into the groove on the left side of the dispenser and push down in
place. Feed the roll of towels over the front of the paper towel tra . Close the y
cove . r
PSW3-1000 - Encore
August - 2020
Page 2 of 4
Fresh Water
Fill Plug
PSW3-1000 - Encore
August - 2020
Page 3 of 4
Parts Drawing - Exploded View
Soap Dispenser
To ll the soap dispenser, open it by turning the lid counter
clockwise and lift up. Fill with 30 uid ounces (or desired
amount) of liquid soap, place the lid back on, and turn clock-
wise to lock the lid in place. To remove the dispenser for
cleaning, remove the lid, and locate the tab on the middle
of the mounting plate at the rear of the dispenser. Push
in on it, and slide the dispenser up, and off. The lid can be
secured back on the dispenser for storage.
Winterizing
• Drain all water from the tanks.
• Flush tank with a solution of chlorine and water.
• Depress the foot pump to run the clorine solution through the lines.
• Drain all water from the tanks and while the drains are open, continue to pump
the foot pumps to clear all of the liquids from the lines.
PC-000415
1/4” Uniseal
PC-100420P
Fill Plug
PC-000205M
Lock
PC-100420B
Fill Plug Body
PC-100420T
Fill Plug Tether
PC-000581P
Sink Tap
PC-000339
Elbow
PC-000107
Rivet
CH38-046
3/8” x 46” Tube
PC-000351
Plastic Clamp
CH075-037
3/4” x 37” Drain Hose
PS2-0002
Sink Bowl
PC-000418
1” Uniseal
PC-100421B
Drain Plug Body
PC-100421P
Drain Plug
PC-000241
O-ring
PC-000106
Washer
PC-000600
Baby Foot Pump
CT38-0065
3/8” x 6.5” Tube
PC-000107
Rivet
PS2-0001
Sink Body
PC-000416
1/2” Uniseal
PC-000106
Washer
