PD4 -amplied Active Speaker Series Bi

Ref. nr.:178.260 / 178.263 / 178.266

GEBRUIKSAANWIJZING

BEDIENUNGSANLEITUNG

MANUAL DE INSTRUCCIONES

MANUEL D'INSTRUCTIONS

V1.4

ENGLISH

Congratulations to the purchase of this Power Dy mics product. Please read this manual thoroughly prior to using the unit in na

order to benet fully from all features.

Read the manual prior to using the unit. Follow the instructions in order not to invalidate the warranty. Take all precautions to

avoid re and/or electrical shock. Repairs must only be carried out by a qualied technician in order to avoid electrical shock.

Keep the manual for future reference.

- Prior to using the unit, please ask advice from a

specialist. When the unit is switched o for the rst timen ,

some smell may occur. This is normal and will disappear

after a while.

- The unit contains voltage carrying parts. Therefore do

NOT open the housing.

- Do not place metal objects or pour liquids into the unit

This may cause electrical sho and malfunction. ck

- Do not place the unit near heat sources such as

radiators, etc. Do not place the unit on a vibrating

surface. Do not cover the ventilation holes.

- The unit is not suitable for continuous use.

- Be careful with the mains lead and do not dam e it. A ag

faulty or damaged mains lead can cause electrical shock

and malfunction.

- When unplugging the unit from a mains outlet, always

pull the plug, never the lead.

- Do not plug or unplug the unit with wet hands.

- If the plug and/or the mains lead are dam ed, they ag

need to be replaced by a qualied technician.

- If the unit is damaged to such an extent that internal

parts are visible, do NOT plug the unit into a mains outlet

and DO NOT switch the unit on. Contact your dealer.

- To avoid re and shock hazard, do not expose the unit to

rain and moisture.

- All repairs should be carried out by a qualied technician

only.

- Connect the unit to an earthed mains outlet (220-

240Vac/50Hz) protected by a 10-16A fuse.

- During a thunderstorm or if the unit will not be used for a

longer period of time, unplug it from the mains. The rule

is: Unplug it from the mains when not in use.

- If the unit has not been used for a longer period of time,

condensation may occur. Let the unit reach room

temperature before you switch it on. Never use the unit in

humid rooms or outdoors.

- To prevent accidents in companies, you must follow the

applicable guide lines and follow the instructions.

- Do not repeatedly switch the xture on and o. This

shortens the life time.

- Keep the unit out of the reach of children. Do not leave

the unit unattended.

- Do not use cleaning sprays to clean switches. The

residues of these sprays cause deposits of dust and

grease. In case of malfunction, always seek advice from

a specialist.

- Do not force the controls.

- This unit is with speaker inside which can cause

magnetic eld. Keep this unit at least 60cm away from

computer or TV.

- This unit is with built-in lead-acid rechargeable battery.

Please recharge the battery every 3 months if you are

not going to use the unit for a long period of time. Or the

battery may be damaged.

- If the battery is damaged please replace with same

specications battery. And dispose the damaged battery

environment friendly.

- If the unit has fallen, always have it checked by a

qualied technician before you switch the unit on again.

- Do not use chemicals to clean the unit. They damage the

varnish. Only clean the unit with a dry cloth.

- Keep away from electronic equipment that may cause

interference.

- Only use original spares for repairs, otherwise serious

damage and/or dangerous radiation may occur.

- Switch the unit o prior to unplugging it from the mains

and/or other equipment. Unplug all leads and cables

prior to moving the unit.

- Make sure that the mains lead cannot be damaged when

people walk on it. Check the mains lead before every use

for damages and faults!

- The mains voltage is 220-240Vac/50Hz. Check if power

outlet match. If you travel, make sure that the mains

voltage of the country is suitable for this unit.

- Keep the original packing material so that you can

transport the unit in safe conditions.

This mark attracts the attention of the user to high voltages that are present inside the housing and that are of sucient

magnitude to cause a shock hazard.

This mark attracts the attention of the user to important instructions that are contained in the manual and that he should

read and adhere to.

The unit has been certied CE. It is prohibited to make any changes to the unit. They would invalidate the CE certicate and

their guarantee!

NOTE: To make sure that the unit will function normally, it must be used in rooms with a temperature between 5°C/ °F 41 and

35 95°C/ °F .

Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local authorities or your

dealer about the way to proceed. The specications are typical. The actual values can slightly change from one unit to the other.

Specications can be changed without prior notice.

Do not attempt to make any repairs yourself. This would invalid your warranty. Do not make any changes to the unit. This would also invalid

your warranty. The warranty is not applicable in case of accidents or damages caused by inappropriate use disrespect of the warnings or

contained in this manual Power Dynamics cannot be held responsible for personal injuries caused by a disrespect of the safety .

recommendations and warnings. This is also applicable to all damages in whatever form.

CONTROLS AND FEATURES

1. BT Connection button

2. Volume control Channel 1

3. Volume control Channel 2

4. Input c nnel 2 3.5mm jack ha and RCA

5. Combo input c nnel 1 XLR and Jack ha

6.3mm

6. DSP mode

7. LED Indicator

Limit: audio reaches the dangereous

threshold for the transducers, LED

lights RED.

Signal: indicates the input signal ‘’XLR’’

LED lights GREEN

Power: indicates the system is “ON”

LED lights BLUE

8. Volume control BT

9. Output button, C ose input channel 1 only or MIX ho

10. Output XLR-connector

DSP SPEAKER MODE

In below schedule is the DSP frequency range of all four modes The black line in the middle is the zero. You can .

see the type frequency of each DSP speaker mode. of

Description:

RED = PA

BLUE = MONITOR

GREEN = SUB

YELLOW = SPEECH

PA mode:

This the default setting for the loudspeaker. Use this setting when your l dspeaker is being used on a speaker is ou

stand.

Monitor mode:

Use this setting when your loudspeaker is being used as a stage monitor.

Sub mode:

Use this setting when combined with a subwoofer -frequency filter out of speakers . Low is ed .

Speech mode:

Use this setting when your loudspeaker is being used for speech or presentations.

BT- CONNECTION

1. Turn the power , press the pair button for two seconds, the paired LED will ash. ON

2. 01 Enable BT on you device and select MIX -ER as the device. When paired successfully, the paired LED is

light solid.

Produkspesifikasjoner

Merke:	Power Dynamics
Kategori:	Høyttaler
Modell:	PD415A
Vekt:	19600 g
Bredde:	425 mm
Dybde:	365 mm
Høyde:	710 mm
Bluetooth:	Nei
Tilkoblingsteknologi:	Ledning & Trådløs
Impedans:	4 Ω
Høyttalerplassering:	Kan monteres på stativ
Basshøyttaler:	Ja
Forsterker:	Innebygget
Diskanthøyttaler:	Ja
Produktfarge:	Sort
Av/på-bryter:	Ja
Lyd-utgang kanaler:	- kanaler
RMS-rangert strøm/utgangseffekt:	350 W
Antall drivere:	2
Høyttaler type:	2-veis
Frekvensrekkevidde:	35 - 20000 Hz
Basshøyttalerens diameter:	381 mm
Diskant diameter:	34.29 mm
Sensitivitet/følsomhet:	125 dB
Diskanthøyttalerens diameter:	1.35 "
Basshøyttalerens diameter (imperisk):	15 "
Diameter på mellomtone-driver (imperisk):	35 "
Overgangsfrekvens:	2800 Hz
Forsterker, klasse:	D
Antall drivere til diskant:	1
Antall basshøyttalerdrivere:	1
Antall mellomtonedrivere:	1
