Side 1/20

PPA502 100V 2 Zone Mixer-Amplifier 50W

Ref. nr.: 952.084

INSTRUCTION MANUAL

GEBRUIKSAANWIJZING

BEDIENUNGSANLEITUNG

MANUAL DE INSTRUCCIONES

MANUEL D'INSTRUCTIONS

INSTRUKCJA OBSŁUGI

V1.2

ENGLISH

Congratulations to the purchase of this Power Dynamics product. Please read this manual thoroughly prior to using the unit in

order to benefit fully from all features.

Read the manual prior to using the unit. Follow the instructions in order not to invalidate the warranty. Take all precautions to

avoid fire and/or electrical shock. Repairs must only be carried out by a qualified technician in order to avoid electrical shock.

Keep the manual for future reference.

- Prior to using the unit, please ask advice from a

specialist. When the unit is switched on for the first time,

some smell may occur. This is normal and will disappear

after a while.

- The unit contains voltage carrying parts. Therefore do

NOT open the housing.

- Do not place metal objects or pour liquids into the unit

This may cause electrical shock and malfunction.

- Do not place the unit near heat sources such as

radiators, etc. Do not place the unit on a vibrating

surface. Do not cover the ventilation holes.

- The unit is not suitable for continuous use.

- Be careful with the mains lead and do not damage it. A

faulty or damaged mains lead can cause electrical shock

and malfunction.

- When unplugging the unit from a mains outlet, always

pull the plug, never the lead.

- Do not plug or unplug the unit with wet hands.

- If the plug and/or the mains lead are damaged, they

need to be replaced by a qualified technician.

- If the unit is damaged to such an extent that internal

parts are visible, do NOT plug the unit into a mains outlet

and DO NOT switch the unit on. Contact your dealer.

- To avoid fire and shock hazard, do not expose the unit to

rain and moisture.

- All repairs should be carried out by a qualified technician

only.

- Connect the unit to an earthed mains outlet (220-

240Vac/50Hz) protected by a 10-16A fuse.

- During a thunderstorm or if the unit will not be used for a

longer period of time, unplug it from the mains. The rule

is: Unplug it from the mains when not in use.

- If the unit has not been used for a longer period of time,

condensation may occur. Let the unit reach room

temperature before you switch it on.

- Never use the unit in humid rooms or outdoors.

- To prevent accidents in companies, you must follow the

applicable guide lines and follow the instructions.

- Do not repeatedly switch the fixture on and off. This

shortens the life time.

- Keep the unit out of the reach of children. Do not leave

the unit unattended.

- Do not use cleaning sprays to clean switches. The

residues of these sprays cause deposits of dust and

grease. In case of malfunction, always seek advice from

a specialist.

- Do not force the controls.

- This unit is with speaker inside which can cause

magnetic field. Keep this unit at least 60cm away from

computer or TV.

- If this product have a built-in lead-acid rechargeable

battery. Please recharge the battery every 3 months if

you are not going to use the product for a long period of

time. Otherwise the battery may be permanently

damaged.

- If the battery is damaged please replace with same

specifications battery. And dispose the damaged battery

environment friendly.

- If the unit has fallen, always have it checked by a

qualified technician before you switch the unit on again.

- Do not use chemicals to clean the unit. They damage the

varnish. Only clean the unit with a dry cloth.

- Keep away from electronic equipment that may cause

interference.

- Only use original spares for repairs, otherwise serious

damage and/or dangerous radiation may occur.

- Switch the unit off prior to unplugging it from the mains

and/or other equipment. Unplug all leads and cables

prior to moving the unit.

- Make sure that the mains lead cannot be damaged when

people walk on it. Check the mains lead before every use

for damages and faults!

- The mains voltage is 220-240Vac/50Hz. Check if power

outlet match. If you travel, make sure that the mains

voltage of the country is suitable for this unit.

- Keep the original packing material so that you can

transport the unit in safe conditions.

This mark attracts the attention of the user to high voltages that are present inside the housing and that are of sufficient

magnitude to cause a shock hazard.

This mark attracts the attention of the user to important instructions that are contained in the manual and that he should

read and adhere to.

The unit has been certified CE. It is prohibited to make any changes to the unit. They would invalidate the CE certificate and

their guarantee!

NOTE: To make sure that the unit will function normally, it must be used in rooms with a temperature between 5°C/41°F and

35°C/95°F.

Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local authorities or your

dealer about the way to proceed. The specifications are typical. The actual values can slightly change from one unit to the other.

Specifications can be changed without prior notice.

Do not attempt to make any repairs yourself. This would invalid your warranty. Do not make any changes to the unit. This would also invalid

your warranty. The warranty is not applicable in case of accidents or damages caused by inappropriate use or disrespect of the warnings

contained in this manual. Power Dynamics cannot be held responsible for personal injuries caused by a disrespect of the safety

recommendations and warnings. This is also applicable to all damages in whatever form.

UNPACKING INSTRUCTION

CAUTION! Immediately upon receiving the product, carefully unpack the carton, check the contents to ensure that all parts are

present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if

any parts appear damage from shipping or the package itself shows signs of mishandling. Save the package and all packing

materials. In the event that the product must be returned to the factory, it is important that the product be returned in the original

factory box and packing.

If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on immediately. The

arising condensation water might damage your device. Leave the device switched off until it has reached room temperature.

POWERSUPPLY

On the label on the backside of the product is indicated on this type of power supply must be connected. Check that the mains

voltage corresponds to this, all other voltages than specified, the light effect can be irreparably damaged. The product must also

be directly connected to the mains and may be used. No dimmer or adjustable power supply.

Always connect the device to a protected circuit (circuit breaker or fuse). Make sure the device has an appropriate

electrical ground to avoid the risk of electrocution or fire.

REPLACING THE FUSE

If the fuse is defective, replace the fuse with a fuse of the same type and value. Before replacing the fuse, unplug mains lead.

Procedure:

Step 1: Open the fuse holder on the rear panel with a fitting screwdriver.

Step 2: Remove the old fuse from the fuse holder.

Step 3: Install the new fuse in the fuse holder.

Step 4: Replace the fuse holder in the housing.

FRONT PANEL

1. SD CARD SLOT: Insert an SD card in this slot.

2. DISPLAY: The display shows multiple forms of information, for example current MODE, elapsed time, etc.

3. USB PORT: You can play media files from a USB device by connecting the device to this slot.

4. VU-METER: Indicates the level of master output.

5. POWER SWITCH: Turn the device ON or OFF.

6. BUTTON CLUSTER:

Mode button - Press to change modes between playing SD, USB, MP3 and BT.

Play/pause button - Press this button to start or pause play.

Folder button - Press this button to enter FOLDER selection.

Repeat button - Press the repeat button once to continually repeat ALL tracks, press repeat once more to repeat just the

current track.

Previous button - Press this button to go to the previous track. Press and hold to scan backwards within tracks.

Next button - Press this button to go to the next track. Press and hold to scan forwards within tracks.

7. MIC1 INPUT: Connect a microphone to the 6.3mm jack input.

8. MIC OUTPUT LEVEL CONTROL: Adjust the volume of both MIC1 & MIC 2 channels.

9. LINE OUTPUT LEVEL CONTROL: Adjust the volume of both LINE1 & LINE 2 channels.

10. MP3 OUTPUT LEVEL CONTROL: Adjust the volume of the MP3 channel.

11. BASS CONTROL: Adjust the low frequencies of the corresponding channel.

12. TREBLE CONTROL: Adjust the high frequencies of the corresponding channel.

13. ZONE VOLUME CONTROL: Adjust the volume for zone 1 and 2 separately.

14. MASTER VOLUME: Adjust the master volume.

Produkspesifikasjoner

Merke:	Power Dynamics
Kategori:	Mottaker
Modell:	PPA502
Innebygd skjerm:	Ja
Vekt:	3300 g
Bredde:	250 mm
Dybde:	350 mm
Høyde:	85.5 mm
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
AC-inngangsspenning:	100-240 V
AC-inngangsfrekvens:	50-60 Hz
Produktfarge:	Sort
Mikrofon, linje-inn-støpsel:	Ja
Fjernkontroll medfølger:	Ja
inngangsimpedans:	8 Ω
Signal-til-støy-forhold (SNR):	80 dB
Lyd-utgang kanaler:	2.0 kanaler
Frekvensrekkevidde:	50 - 18000 Hz
Tilkoblingstype høyttalere:	6.3 mm / RCA
Peak effekt per kanal:	50 W
