Translation of the original operating instructions for path-

controlled tackers

SLIDER 4C-L50 SLIDER 4C-Z50

SLIDER 5C- Q67 SLIDER 5C- Z75

97517201

-EN

Foreword

These operating instructions will help you to operate the path-controlled tackers in the Slider 4C and Slider

5C series

 correctly in accordance with their intended use,

 safely and

 cost-effectively.

These tools are referred to simply as Sliders in these operating instructions.

We assume that every person using the Slider has knowledge of how to handle pneumatic tools. People who

do not have this knowledge must be instructed by an experienced user about how to operate the Slider.

These operating instructions are intended for the following persons:

 Persons who operate this Slider

 Persons who clean this Slider, and/or

 Persons who dispose of this Slider.

All of these persons must have read and understood the contents of these operating instructions.

These operating instructions are considered a part of the product. Always keep them near the Slider. Pass

on the operating instructions if you sell the Slider or hand it on in any other manner.
