Side 1/20
Quick Start
© 2009 All rights reserved
Unpacking and Setup 3
Loading the Label Stock 4
Loading the Container 10
Applying the Label 13
Label Path Diagram 16
Troubleshooting and Maintenance 17
Specications 19
Notices: The information in this document is subject to change without notice. NO WARRANTY OF ANY KIND IS MADE WITH REGARD
TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. No liability is assumed for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this material. This document contains proprietary information that is protected by copyright. All rights are
reserved. No part of this document may be photocopied, reproduced, or translated into another language without prior written consent.
Trademark Acknowledgments: Windows is a registered trademark of Microsoft Corporation. All other trademarks are the property of their
respective owners.
Printing History
Edition 1.4, #021214, Copyright 2009, All rights reserved.
FCC Compliance Statement: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
For Users in the United States: This product is intended to be supplied by a UL listed Direct Plug-In Power Supply marked "Class 2"or a UL listed ITE
Power Supply marked "LPS" with output rated 12VDC, 4.5A or higher. This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC Rules. In a domestic environment this product may cause radio interference, in which case the user
may be required to take adequate measures. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Re-orient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cables is required to comply with the Class A limits of Part 15 of the FCC Rules. You are cautioned that any changes or
modifications not expressly approved in this manual could void your authority to operate and/or obtain warranty service for this equipment.
For Users in Canada: This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out on the Radio Interference
Regulations of the Canadian Department of Communications. Le present appareil numerique n'emet pas de bruits radioelectriques depassant les
limites applicables aux appareils numeriques de la class A prescrites dans le Reglement sur le brouillage radioelectrique edicte par le ministere des
Communications du Canada.
General Safety Information.
Note: Notes are used to notify of installation,operation, or maintenance information that is important but not safety related.
Caution: Caution is used to indicate the presence of a hazard, which if ignored may result in damage to the unit.
Warning: Warning means that a potential safety hazard exists and indicates procedures that must be followed exactly to avoid serious personal injury.
WARNING!
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE. TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE EXTERIOR PANELS. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL. OPERATE THE UNIT WITH ONLY THE PROPER ELECTRICAL SPECIFICATIONS AS LABELED
ON THE PRINTER AND AC ADAPTER.
WARNING!
DO NOT WEAR LOOSE FITTING CLOTHING SUCH AS NECK TIES OR LOOSE LONG SLEEVES WHEN OPERATING THE AP360/362.
THE MOTOR IS VERY POWERFUL AND THE LINEr DRIVE ROLLER COULD CATCH THE CLOTHING WHILE THE LABELS ARE
BEING APPLIED.
!
!
Thank you for purchasing the AP360 or AP362 Label Applicator (hereafter referred to as "Label
Applicator"). Bottles, cans etc. will collectively be referred to as "containers." This manual applies
to two label applicator models. The AP362 has a Control Panel that allows you to count labels and
apply two labels to the same container. The AP360 does not have a Control Panel or two-label
capability.
The Label Applicator includes a Power Cord, 12 volt Power Adapter and the parts shown in
Figure 1-1. The Roll Bar, Roll Guides and Roll Drag Arm are located in the supply box along with
the Power Cord. You will need to assemble them as shown in Figure 1-1. Attach the Power Cord
and switch on the power as shown in Figure 1-2. Feed the Foot Switch and Foot Switch cord out
through the front of the Label Applicator. Remove the tape securing the Container Rollers.
Section 1: Unpacking and Setup
Figure 1-2.
Figure 1-1.
Roll Bar
Roll Guides
Label Sensor Flag
Label Sensor Bracket
Container Guides
Container Idler
Roller
Container Drive
Roller
Container Pressure Arm
Liner Idler Roller
Liner Drive Roller
Control Panel
(AP362 only)
Foot Switch
Peel Edge
Power Switch
Power Input 12V
Roll Bar
Roll Guides
Feed Area
(under grey bar)
AP360/362 Label Applicator 3
Power Cord
Roll Drag Arm
Power Adapter
