Side 1/243

Vess A-Series

Storage Appliance for Video Surveillance

Vess A3340s / Vess A3340d

Vess A3340 PoE

Product Manual

Version 1.2

Vess A Class Storage Appliance for Video Surveillance Promise Technology

About this guide

This Product Manual includes instructions for setting up and operating the available hardware versions of the

Vess A3340 Storage Appliance for Video Surveillance. These models include the Vess A3340s, Vess A3340d and

Vess A3340 PoE. For convenience, these models are referred to as simply Vess A3340 when describing features

or operations common to all models. The specic model name is used only when it is necessary to distinguish

one model from the other available models.

Please pay special attention to the warnings, cautions, important notices and notes contained throughout this

guide. See the explanations of each below.

Also included are four levels of notices:

Warning

A Warning noties you of probable equipment damage

or loss of data, or the possibility of physical injury, and

how to avoid them.

Caution

A Caution informs you of possible equipment damage or loss of data and how to

avoid them.

Important

An Important message calls attention to an essential step or point

required to complete a task, including things often missed.

Note

A Note provides helpful information such as hints or alternative ways of

doing a task.

Produkspesifikasjoner

Merke:	Promise Technology
Kategori:	Sikkerhetskamera
Modell:	Vess A3340
Vekt:	- g
Bredde:	410 mm
Dybde:	446 mm
Høyde:	88.2 mm
Prosessorfrekvens:	3.6 GHz
Prosessorfamilie:	Intel® Xeon®
Antall USB 2.0-porter:	2
Antall HDMI-porter:	1
Sertifisering:	FCC / CE / VCCI / RCM / BSMI / Nemko
Internminne:	16 GB
Maksimalt internminne:	32 GB
Total lagringskapasitet:	32000 GB
Antall SSD-er installert:	1
SSD-kapasitet:	128 GB
Antall installerte harddisker:	8
HDD-grensesnitt:	SATA
RAID-støtte:	Ja
HDD-størrelse:	3.5 "
Lyd inn/ut:	Ja
VGA (D-Sub) utgangsporter:	1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	60 - 50 Hz
Prosessorkjerner:	4
Internminnetype:	DDR4
Strømforbruk (vanlig bruk):	250 W
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	5 - 40 °C
Intern harddisk:	4000 GB
Rack-kapasitet:	2U
RAID-nivåer:	0, 1,1+0, 1E, 3,5, 6,10, 30, 50, JBOD
Ethernet-grensesnittype:	Gigabit Ethernet
Chassis-type:	Rack (2U)
Krav til strømforsyning:	350 W
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	6
Antall støttede HDDer:	8
Boostfrekvens prosessor:	4 GHz
Prosessortråder:	8
