Side 1/4

PLVWH2

WIRELESS INFRARED TRANSMITTER AND

WIRELESS INFRARED STEREO HEADPHONE

The PLVWH2 is a true wireless headphone system which uses latest

high frequency modulation infrared technology. You can enjoy music

by simply connecting the supplied infrared transmitter to any of your

audio/video equipment through either a line output jack or a headphone

jack. This system is easy to set up within your car. It provides you with

ultimate personal listening freedom.

Features

An optical transmission system with high frequency modulation

guarantees excellent nd surround sound quality and wide effective

transmission range.

The well designed transmitter and headphone with built-in receiver are

omnidirectional in sending and receiving audio signals within a 7 meter

radius, which are generally not susceptible to be blocked by objects

between them.

True surround sound, elegant design and rich finish of the system add

into the beauty of your expesive automobile entertainment systems.

The signal input level is automatically adjusted by the built-in Automatic

Input Level control Circuit (ALC).

Since this system uses infrared ray, if the headphones/receivers are

placed too far from the transmitter, a hissing noise may increase. This is

a characteristic of infrared systems and does not mean that the system

is defective Do not use this system in the open air under direct sunlight as

the infrared system will not work properly.

Overview

INFRARED TRANSMITTER

Precautions

* Operate the transmitter on 12V 100mA. Operate the headphone

system on3V DC (size AAA batteries x 2).

* Turn off the power of the transmitter and the system is not in use.

* Do not open the cabinet. Refer servicing to qualified personnel

only.

* Do not leave the system in a location near heat sources such as

radiators or airducts, or in a place subject to direct sunlight,

excessive dust, moisture, rain, mechanical vibrantion, or shock.

* Do not use alcohol, benzine or thinner to clean the cabinet.

Headphone

1. Infrared sensors

2. Power Switch

3. Stereo / mono

4. Volume Controls

5. Battery Compartment Door

6. Ear pad

7. Adjustable headband

IR Stereo Headphone

1. Open the battery compartment door on the right of the

headphone.

2. Insert two size AAA batteries with correct polarity.

3. Close the battery compartment.

Transmitter

1. Infrared emitter

2. Audio input ( R)

3. Audio input ( L)

RED

WHITE

4. Power 12VDC (+)RED

(-)BLACK

Velcro for Mounting

IR Transmitter

Produkspesifikasjoner

Merke:	Pyle
Kategori:	hodetelefon
Modell:	PLVWH2
Produkttype:	Hodetelefoner
Vekt:	363 g
Tilkoblingsteknologi:	Trådløs
Volumkontroll:	Rotasjon
Impedans:	10000 Ω
3,5 mm-kontakt:	Ja
Batteriteknologi:	Alkalinsk
Batteritype:	AAA
Produktfarge:	Sort
Antall støttede batterier:	2
Batterispenning:	1.5 V
Slår seg automatisk av:	Ja
Av/på-bryter:	Ja
Rekkevidde trådløs ruter:	30 m
Bæremåte:	Hodebånd
Antall:	1
Øresammenkobling:	Circumaural
Automatisk kanalvelger:	Ja
Transmittertype:	DC 12VDC Hardwired
