Side 1/5
www.avsl.com 160.495UK Manual
HZ-1500LED
LED HAZE MACHINE 1500W
Order ref: 160.495UK
User Manual
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
A high efficiency 1500W haze machine capable of producing 20,000 cu.ft per minute of haze
to rapidly fill larger venues. The haze effect can then be highlighted with an array of colours
from the 9 bright LED's housed in the front of the unit. The haze and light effects are easily
controlled using either the included keyfob-style RF wireless remote or by 6-channel DMX
connection. The 2.3 litre fluid bottle can be removed for easy refilling and there is a slot
window to indicate the current fluid level.
• 1500W haze vaporizer with around 20,000 cu.ft/min output
• Nine powerful 3W LEDs add a bright colourful light show to the haze effect
• 433Mhz keyfob-style RF wireless remote
• 6-Channel DMX connections
• Removable 2.3 litre fluid tank
• High grade haze fluid should be used with this machine (we recommend 160.591UK)
www.avsl.com 160.495UK Manual
In the box:
Please check the contents to ensure that the product has been received in good condition.
• HZ-1500LED Haze Machine
• RF Remote Control & transmitter
• UK/EU Mains Leads
• Mounting bracket & screws
• User guide
If you find any accessory is missing or the machine has arrived with damage, please contact
your local dealer at once. Do not try to fix this item yourself or you will invalidate the
warranty. Please keep the original packaging and invoice for any possible replacement or
return demands.
Warnings:
1. To prevent risk of fire or electric shock, do not expose electrical parts to rain or
moisture.
2. If liquids are spilled on areas other than inside the fluid tank, disconnect the mains,
allow the unit to dry out and have it checked by qualified personnel before use.
3. Avoid any impact, dropping or extreme pressure to the housing.
4. No user serviceable parts inside - do not open the case.
5. Allow the unit to acclimatise to room temperature before operating.
6. The HZ-1500LED has a built-in fluid container and should be operated in an upright
position. Ensure that the unit is positioned on a stable, non-slip surface.
Safety and Cleaning:
1. Check for correct mains voltage and condition of IEC lead before connecting to mains.
2. This unit must be earthed.
3. This unit uses a heating element – be aware that parts of the housing may be hot
during use!
4. Use a soft dry or slightly damp cloth to clean the casing.
5. Do not use strong solvents for cleaning the housing.
6. Clean the haze mechanism periodically by operating with distilled water.
7. It is also recommended to use fog machine cleaning fluid (160.670UK) periodically.
Recommended Fluids:
For the HZ-1500LED haze machine, we strongly recommend the following fluid which has
been specifically formulated to perform best with any heater-based haze machines.
QTX ref code
Description
Size
160.591UK
High quality professional haze fluid
5 Litre
160.596UK
Eco haze fluid
5 Litre
