Les nedenfor 📖 manual på norsk for Radial Engineering Hot-British V9 (2 sider) i kategorien Ikke kategorisert. Denne guiden var nyttig for 24 personer og ble vurdert med 4.7 stjerner i gjennomsnitt av 12.5 brukere
Side 1/2
www.radialeng.com
True to the Music
Radial Engineering Ltd.
®
®
True to the Music
USER GUIDE
Radial Engineering Ltd.
Hot-British V9
™
Hot-British V9
™
FEATURES
RADIAL ENGINEERING 3 YEAR
TRANSFERABLE LIMITED WARRANTY
RADIAL ENGINEERING LTD. (“Radial”) warrants this product to be free from defects in
material and workmanship and will remedy any such defects free of charge according to the
terms of this warranty. Radial will repair or replace (at its option) any defective component(s)
of this product (excluding nish and wear and tear on components under normal use) for
a period of three (3) years from the original date of purchase. In the event that a particular
product is no longer available, Radial reserves the right to replace the product with a similar
product of equal or greater value. In the unlikely event that a defect is uncovered, please call
604-942-1001 or email service@radialeng.com to obtain an RA number (Return Authorization
number) before the 3 year warranty period expires. The product must be returned prepaid
in the original shipping container (or equivalent) to Radial or to an authorized Radial repair
center and you must assume the risk of loss or damage. A copy of the original invoice showing
date of purchase and the dealer name must accompany any request for work to be performed
under this limited and transferable warranty. This warranty shall not apply if the product has
been damaged due to abuse, misuse, misapplication, accident or as a result of service or
modication by any other than an authorized Radial repair center.
THERE ARE NO EXPRESSED WARRANTIES OTHER THAN THOSE ON THE FACE
HEREOF AND DESCRIBED ABOVE. NO WARRANTIES WHETHER EXPRESSED
OR IMPLIED, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL EXTEND
BEYOND THE RESPECTIVE WARRANTY PERIOD DESCRIBED ABOVE OF THREE
YEARS. RADIAL SHALL NOT BE RESPONSIBLE OR LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSS ARISING FROM THE USE OF
THIS PRODUCT. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU
MAY ALSO HAVE OTHER RIGHTS, WHICH MAY VARY DEPENDING ON WHERE YOU
LIVE AND WHERE THE PRODUCT WAS PURCHASED.
Hot-British V9
™
User Guide - Part# R870 1027 00 / 09-2016 All rights reserved.
Specications and appearance are subject to change without notice.
Radial Engineering Ltd.
1588 Kebet Way, Port Coquitlam BC V3C 5M5
tel: 604-942-1001 • fax: 604-942-1010
info@radialeng.com • www.radialeng.com
Circuit Type: Class-A discrete ..........................................................................
Frequency Response: Adjustable via tone and range controls ........................
Gain: ..........................................................................................................0dB
Mid Boost: 3-position switch boosts midrange by 0dB, +7dB, or +12dB.........
Footswitch: Latching bypass switch .................................................................
Power: 9VDC, adapter not included .................................................................
Radial Classic Specications
O V E R D R I V E - D I S T O R T I O N P E D A L
1. 9VDC POWER: Connection for 9 volt (center pin negative)
power adapter. Includes a cable clamp to prevent accidental
power disconnection.
2. OUTPUT: ¼” connection to your amplier.
3. INPUT: High-Z ¼” connection from your instrument.
4. LOW: Post-distortion EQ control for low frequencies.
5. HIGH: Post-distortion EQ control for high frequencies.
6. CONTOUR: Alters the character of the distortion, turn clockwise
for more high frequencies and counter-clockwise for a warmer
tone.
7. DRIVE: Used to adjust the overall amount of input gain and
distortion
8. MID BOOST: 3-position switch controls the midrange response.
9. BYPASS FOOTSWITCH: Latching switch bypasses the effects.
10. TOP END: 3-position switch controls the high frequency
response.
11. LEVEL: Sets the output volume of the pedal.
11
10 89
6
7
1 2 3
4
5
