Side 1/36

Elise 100 Induction

Britain’s No.1 Range Cooker

USER GUIDE &

INSTALLATION INSTRUCTIONS

GUARANTEE

Rangemaster range cookers come with a 1 year parts & labour

guarantee. You will receive an additional FREE full 12 months

guarantee by registering your purchase using the FREEPOST

form provided. Alternatively, call free on 0800 587 5747, quoting

reference RMGX57A, or register online at www.rangemaster.co.uk.

CONSUMER SERVICE

If you have any product enquiries, or in the event of a problem

with your appliance once it has been installed, please

telephone 0870 789 5107.

CONSUMER SERVICE LINES OPEN:

Monday to Thursday 8am–6pm

Friday 8am–5pm

Saturday 9am–1pm

STANDARDS

Rangemaster cookers are designed and manufactured to a

recognised international quality standard, which meets the

requirements of BS EN ISO 9001, BS EN ISO 14001 and OHSAS 18001

for continually improving environmental procedures.

Rangemaster cookers comply with the essential requirements of the

appropriate European Directives, and carry the CE mark.

IF YOU HAVE A PROBLEM

If you experience a technical failure and require an engineer

to call, please contact Consumer Services on 0870 789 5107.

You will need to have your appliance serial number to hand

when you ring.

Please note:

If you request an engineer to visit and the fault is not the

responsibility of Rangemaster, we reserve the right to make a

charge.

Appointments not kept by you may be subject to a charge.

RANGEMASTER COOKWARE

Our range cookers are well known for providing the

best possible cooking performance and years of

faithful service. However, a great cooker alone cannot

guarantee perfect results every time. The other vital

ingredients are of course enthusiasm and quality

cookware.

We oer cookware to work perfectly with all fuel types

manufactured by Rangemaster, including induction

hobs. You can be assured of functionality with style, as

well as the quality and meticulous attention to detail

you expect from the pioneers of range cooking.

Visit: www.rangemastercookshop.co.uk

Ingredients

• Oil for greasing

• 100 g strawberries

• 100 g raspberries

• 100 g redcurrants

• 100 g blackberries

• or a 400 g mixture of any soft

fruits

• 2 medium eggs

• 30 g caster sugar

• 80 ml skimmed milk

• 2 tsp vanilla extract

• 60 g plain our (sifted)

• 1 tsp baking powder

• Icing sugar to dust

Method

1. Preheat the oven to 200 °C (for a conventional oven),

180

C (for a fan oven) or gas mark 6.

2. Lightly grease a dish 26 cm wide x 4 cm deep.

3. Thickly slice any large strawberries and place them with the

other fruits into an ovenproof dish, deep enough so the berries

are about 2 deep.

4. Whisk the eggs and caster sugar until pale and uy. Beat the

milk and vanilla extract into the mixture and then fold in the

sifted our and baking powder.

5. Pour the cake mix over the fruit and bake on the centre shelf

of the oven for 15-20 minutes, or until the mixture is cooked

through and golden on the top.

6. Dust with icing sugar and serve immediately with cream or

crème fraiche.

FRUITY BAKED PUDDING

Serves 4–6

CUSTOMER SERVICES

For more recipes visit: www.rangemaster.co.uk

iii

1. Before You Start... 1

Installation and Maintenance 1

Peculiar Smells 1

Ventilation 1

Personal Safety 1

Hob Care 3

Cooker Care 3

2. Cooker Overview 4

The Hob 4

The Glide-out Grill 8

The Ovens 8

Accessories 11

Main Oven Light 11

3. Cooking Tips 12

Using Your Induction Cooker 12

General Oven Tips 12

4. Cooking Table 13

5. Cleaning Your Cooker 14

Hob 14

Glide-out Grill 15

Control Panel and Doors 15

The Tall Oven 16

Cleaning Table 17

6. Troubleshooting 18

7. Installation 20

Dear Installer 20

Safety Requirements and Regulations 20

Provision of Ventilation 20

Location of Cooker 20

Positioning the Cooker 21

Moving the Cooker 22

Repositioning the Cooker Following

Connection 22

Levelling the Cooker 23

Electrical Connection 23

Final Checks 24

Final Fitting 24

8. Circuit Diagrams 25

Induction Hob 25

Oven 26

9. Technical Data 27

Connections 27

Dimensions 27

Hotplate Ratings 27

Hotplate Eciency 28

Oven Data 29

Contents

Elise 100 Induction G5 U110217-04

Produkspesifikasjoner

Merke:	Rangemaster
Kategori:	Komfyr
Modell:	Elise 100 Induction
Produkttype:	Frittstående komfyr
Innebygd skjerm:	Ja
Vekt:	124000 g
Bredde:	994 mm
Dybde:	595 mm
Høyde:	930 mm
Barnelås:	Ja
Støynivå:	- dB
Konveksjon matlaging:	Ja
Avrimingsfunksjon:	Ja
Antall brennere/kokesoner:	5
Ovn strømkilde:	Elektrisk
Antall ovner:	2
Kontrollposisjon:	Front
Innebygd lys:	Ja
AC-inngangsspenning:	230 - 400 V
AC-inngangsfrekvens:	50 Hz
Grill:	Ja
Høydejustering:	20 mm
Produktfarge:	Black, White
Kontrolltype:	Rotasjon
Antall elektriske kokesoner:	5
Rengjøringstype:	Katalytisk
Ovn nettokapasitet:	73 l
Benke type:	Sonebasert induksjon
Brenner / kokeområde 1 type:	Liten (fingerbøl)
Brenner / kokeområde 1 strøm:	2000 W
Brenner / kokeområde 2 type:	Medium
Brenner / kokeområde 2 strøm:	2500 W
Brenner / kokeområde 3 type:	Stor
Brenner / kokeområde 3 strøm:	3000 W
Energiforbruk (konvensjonell):	1.08 kWh
Samlet innvendig ovn kapasitet:	155 l
Samlet ovn strøm:	- W
Energiforbruk (tvunget konveksjon):	1.7 kWh
Normal matlaging:	Ja
Grillstyrke:	2300 W
Justerbare bein:	Ja
Ovn samlet kapasitet:	73 l
Tilkoplingsverdi (elektrisk):	14800 W
Ovnsstrøm:	- W
Energiforbruk (konvesionell):	3.888 MJ
Ovn 2 samlet kapasitet:	82 l
Ovn 2 konveksjonstilberedning:	Ja
