Side 1/12

OWNER MANUAL

PROFESSIONAL ACTIVE

SPEAKER SYSTEMS

ENGLISH

ITALIANO

LANGUAGE

ENGLISH

Before connecting and using the ampliﬁer, please read this instruction manual carefully and keep it on hand for future reference. The manual

is to be considered an integral part of the product and must accompany the ampliﬁer when it changes ownership as a reference for correct

installation and use as well as for the safety precautions. RCF S.p.A. will not assume any responsibility for the incorrect installation and/or

use of the product.

WARNING: To prevent the risk of ﬁre or electric shock, never expose this equipment to rain or humidity.

1. All the precautions, in particular the safety ones, must be read with special attention, as they provide important information.

2. The power supply voltage of this equipment is sufﬁciently high to involve a risk of electrocution; therefore, never install or connect the

product with the power supply switched on.

Before powering up the ampliﬁer, make sure that all the connections have been made correctly and that the voltage of your power mains

corresponds to the voltage shown on the rating plate on the unit; if it does not, please contact your RCF dealer.

The metallic parts of the unit are earthed by means of the power cable. This is a Class I device and for its use it must be connected to a

grounded power source. To protect the power cable from damage, make sure that it is positioned so that it cannot be stepped on or crushed

by objects. To prevent the risk of electric shock, never open the ampliﬁer. There are no parts on the inside that the user needs to access.

Appliance coupler or PowerCon Connector® is used to disconnect device from MAIN power. This device shall remain readily accessible after

the installation.

3. Make sure that no objects or liquids can get into this product, as this may cause a short circuit. This apparatus shall not be exposed to

dripping or splashing. No objects ﬁlled with liquid, such as vases, shall be placed on this apparatus. No naked sources (such as lighted candles)

should be placed on this apparatus.

4. Never attempt to carry out any operations, modiﬁcations, or repairs that are not expressly described in this manual. Contact your authorized

service centre or qualiﬁed personnel should any of the following occur:

- the ampliﬁer does not function (or functions in an anomalous way);

- the power supply cable has been damaged;

- objects or liquids have got into the unit;

- the ampliﬁer has been subject to heavy impact.

5. When the ampliﬁer is not to be used for long periods of time, switch it off and disconnect the power cable.

6. If the ampliﬁer begins to emit any strange odours or smoke, switch it off immediately and disconnect the power supply cable.

7. Do not connect this product to any equipment or accessories not speciﬁed.

For suspended installation, only use the dedicated anchoring points and do not try to hang this product using HANDLES or elements that are

unsuitable or not speciﬁc for this purpose.

Also check the suitability of the support surface to which the product is anchored (wall, ceiling, structure, etc.), and the components used for

attachment (screw anchors, screws, brackets not supplied by RCF etc.), which must guarantee the security of the system/installation over time,

also considering, for example, the mechanical vibrations normally generated by the transducer.

To prevent the risk of falling equipment, do not stack multiple units unless this possibility is speciﬁed in the instruction manual.

8. RCF S.p.A. strongly recommends this product is installed by professional qualiﬁed installers (or specialised ﬁrms) who can ensure correct

installation and certify it according to the regulations in force.

THE ENTIRE AUDIO SYSTEM MUST COMPLY WITH THE CURRENT STANDARDS AND REGULATIONS REGARDING ELECTRICAL SYSTEMS.

9. SUPPORTS AND TROLLEYS

The equipment should only be used on trolleys or supports, where necessary, that are recommended by the manufacturer. The equipment/

support/trolley assembly must be moved with extreme caution. Sudden stops, excessive pushing force and uneven ﬂoors may cause the

assembly to overturn.

10. There are numerous mechanical and electrical factors to be considered when installing a professional audio system (in addition to those

which are strictly acoustic, such as sound pressure, angles of coverage, frequency response, etc.).

11. HEARING LOSS

Exposure to high sound levels can cause permanent hearing loss. The acoustic pressure level that leads to hearing loss is different from person

to person and depends on the duration of exposure. To prevent potentially dangerous exposure to high levels of acoustic pressure, anyone

who is exposed to these levels should use adequate protection devices. When a transducer capable of producing high sound levels is being

used, it is therefore necessary to wear ear plugs or protective earphones. See the technical speciﬁcations in the instruction manual for the

maximum sound pressure the loudspeaker is capable of producing.

SAFETY

PRECAUTIONS

Produkspesifikasjoner

Merke:	RCF
Kategori:	Høyttaler
Modell:	ART 735-A
Bredde:	437 mm
Dybde:	389 mm
Høyde:	708 mm
Bruksanvisning:	Ja
Bluetooth:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	AC
Pakkevekt:	20800 g
Antall per pakke:	1 stykker
Anbefalt bruk:	Scene
Høyttalerplassering:	Gulv
Basshøyttaler:	Ja
Peak Music Power Output (PMPO):	1400 W
Diskanthøyttaler:	Ja
AC-inngangsspenning:	220-240 V
Produktfarge:	Sort
Pakkedybde:	440 mm
Pakkehøyde:	750 mm
Pakkebredde:	500 mm
Pakketype:	Boks
Signal-til-støy-forhold (SNR):	132 dB
Kroppsmateriale:	Polypropylen (PP)
Lyd-utgang kanaler:	2.0 kanaler
RMS-rangert strøm/utgangseffekt:	700 W
Utjevner/frekvenskorrigerer:	Ja
Høyttaler type:	2-veis
Frekvensrekkevidde:	45 - 20000 Hz
Basshøyttalerens diameter:	381 mm
Diskant diameter:	35.6 mm
XLR i:	Ja
Diskanthøyttalerens diameter:	1.4 "
Basshøyttalerens diameter (imperisk):	15 "
Overgangsfrekvens:	900 Hz
Antall drivere til diskant:	1
Antall basshøyttalerdrivere:	1
6,35 mm (1/4 tommer) inngang:	1
